oracle forms 10g forms look and feel project agenda
Oracle Forms 10g – Forms Look and Feel project-Agenda

Day, Date, 2004

time p.m. ET

Teleconference Access:

North America: xxxx

International: xxxx

Password: Advisor

Wednesday,

December 3rd, 2008

Teleconference Access:

International Dial In:

+44 (0) 1452 555 566

US / Canada Dial-in:

( 877 ) 500 - 9108

Int'l / Local Dial-In:

( 706 ) 902 - 1863

9:00 am GMT

Conf ID - 63410683

17:00 pm GMT

Conf ID - 63516479

Advisor Webcast Feedback:

Karin.Haeussler@oracle.com

  • Presentation – approximately 60 minutes
  • There will be no Q&A Session at the end
    • Instead, please send an email tof.degrelle@free.fr
attention audio information
ATTENTION – AUDIO INFORMATION

If you encounter any audio issues, please call

INTERCALL (Audio Conferencing).

International Dial In: +44 (0) 1452 555 566

US / Canada Dial-in:     ( 877 ) 500 - 9108

Int'l / Local Dial-In:     ( 706 ) 902 - 1863

Conf ID - 63410683 (9:00 am GMT)

Conf ID - 63516479(17:00 pm GMT)

We would like to encourage attendees with sufficient

Internet bandwith to listen through VoiceStreaming to

continue to use this audio source rather than the

Teleconferencing option.

Thank you.

safe harbor statement
Safe Harbor Statement

The following is intended to outline our general product direction. It is intended for information purposes only, and may not be incorporated into any contract. It is not a commitment to deliver any material, code, or functionality, and should not be relied upon in making purchasing decision. The development, release, and timing of any features or functionality described for Oracle’s products remains at the sole discretion of Oracle.

advisor webcast oracle developer forms
Advisor Webcast: Oracle Developer Forms

Reminder:

  • This presentation was created by the Engineer presenting it and is based on his/her own research.  This presentation has not been reviewed by the Development, Quality Assurance, or Product Management staff.
oracle forms 10g forms look and feel project
Oracle Forms 10g – Forms Look and Feel project

Day, Date, 2004

time p.m. ET

Teleconference Access:

North America: xxxx

International: xxxx

Password: Advisor

Upcoming live Forms webcasts (Note 423317.1):

(if possible each first Wednesday of a Month at 9:00 GMT and 17:00 GMT)

December 3, 2008: Oracle Forms 10g – Forms Look and Feel project

February 11, 2009: Troubleshooting the generic FRM-9210x errors

Wednesday,

December 3rd, 2008

Teleconference Access:

International Dial In:

+44 (0) 1452 555 566

US / Canada Dial-in:

( 877 ) 500 - 9108

Int'l / Local Dial-In:

( 706 ) 902 - 1863

9:00 am GMT

Conf ID - 63410683

17:00 pm GMT

Conf ID - 63516479

Advisor Webcast Feedback:

Karin.Haeussler@oracle.com

oracle forms 10g forms look and feel project7

Oracle Forms 10g – Forms Look and Feel project

Francois Degrelle

Consultant

Netsource Network Solutions

slide9
Introduction
  • What is it ?
  • How it works ?
  • How to implement in a new module?
  • How to update existing modules ?
  • How to maintain the CSS file ?
  • Where to download the project ?

December 2008

slide10
Introduction
    • Change easily the look of the Forms application.
    • Have a more « HTML » look.
    • Externalize the graphical information.
    • Add some missing functions.

December 2008

slide11

Draw gradient backgrounds, images, shapes and strings on the canvas

  • Change easily the look of the Forms application

Change the look

of the GUIs’ elements

Change the look

of the Forms’ containers

Give table-blocks

an  « HTML » style

December 2008

slide12
Externalize the graphical information

Most of the graphical information is read from an external CSS file.

The painting is made at runtime by reading the required tags, then applying the changes through the Java Bean.

canvasEbay {

type:canvas

gradient-colors:r255g255b204,r255g255b255

gradient-vcycle:/2

gradient-hcycle:0

image1:/ebay.jpg,10,1,.8

image2:/ebay_line.jpg,30,74,.6,560,5

}

tableHeaderEbay {

type:header

font-family: Arial;

font-size:12

font-weight:bold

frame-color:r250g83b12

inside-color:r255g204b0

font-color:r0g0b204

shade-color:r255g255b204

frame-width:2

frame-rounded-border: 10

transparency:.8

text-align:left

text-align-offset:5

}

December 2008

slide14
Add a few new functions
    • Handle menus at runtime (add, enable, disable, show, hide, remove options).
    • Handle frames at runtime (add, move, modify, hide).
    • Play pre-loaded sounds.
    • Receive external asynchronous messages.
    • Draw texts anywhere on the screen.
    • Display input dialog boxes.
    • JColorChooser.

December 2008

slide15
What is it ?
    • a PL/SQL library

That contains the functions and the procedures to read the tags

from the CSS file and paint every object.

    • a JAR file

That contains the Java Bean and the PJCs.

    • a CSS file

That contains the tags’ sections.

December 2008

slide16
The PL/SQL library (laf.pll)

It contains the functions and the procedures needed to open the CSS file,

read the tags from it, then perfom the drawing job through the

associated Java Bean’s methods.

    • Open and read the CSS file.

PKG_LOOK_AND_FEEL.Open_Css()

    • Draw objects on the canvas.

PKG_LOOK_AND_FEEL.Paint_Canvas()

    • Decorate the given table-block.

PKG_LOOK_AND_FEEL.Paint_Block()

    • Set global properties for every GUIs widgets.

PKG_LOOK_AND_FEEL.Set_GUI_Properties()

December 2008

slide17
The JAR file (laf.jar)

It contains a Java Bean to perform all the graphical operations,

and some PJCs to overload the common Forms widgets.

- The Java Bean allows to manage the following aspects:

    • Drawing shapes on the current canvas (images, lines, rectangles and strings).
    • Loading and playing sounds.
    • Dynamically handling menus - add, remove, enable, disable, show and hide menu options at runtime.
    • Dynamically handling frames – add, remove, modify, move, show and hide frames at runtime.
    • Display single or multi-line input dialog box.
    • Transform the Forms into a Socket Server, able to receive external asynchronous messages.
    • Display texts anywhere on the canvas during a given time.
    • Change fonts and colors for menu bar, window caption, status bar and tabs.
    • Pick a color from a JColorChooser.
    • Turn simple images into sensitive areas you can click on.

December 2008

slide18
- The PJCs tend to give a more « Windows XP » look with the use of gradients.

They also extend the standard functions of the common Forms items:

  • Buttons with mixed text and image, and mouse-on, mouse-over events.
  • Text items that allow sending events to the Forms (last key typed with key char, key code and key modifier) via the Tom Cleymans dispatching feature.
  • Blinking text items.
  • Hyperlink sort of text items.
  • Extended lists (multiple selection – sorted lists).

December 2008

slide19
The CSS file

It contains the different tags, grouped in five different section’s types:

    • type:canvas

That contains tags to decorate a canvas

    • type:title

That contains tags to draw a table-block title area

    • type:header

That contains tags to draw a table-block header area

    • type:body

That contains tags to draw a table-block body area

    • type:gui

That contains tags to manage the common GUIs elements

December 2008

slide20

Header section’s tags

Body section’s tags

Title section’s tags

December 2008

slide21
How it works?
    • The Forms side

Read the CSS file, then decorate the elements by calling

the Java methods - Set_Custom_Property().

    • The Java side

Use the Java methods to paint the Forms elements.

setProperty() and getProperty()

December 2008

slide22
The Forms side

When-Timer-Expired trigger

December 2008

slide23
The Java side
      • When-Timer-Expired trigger

Colorize widgets

Draw shapes

Draw images

Re-draw

buttons

Paint gradients

December 2008

slide24
L&F Demo

December 2008

slide25
How to implement the L&F in a new module?
    • a Forms Object Library (laf.olb)

That contains all the required objects to implement the L&F features.

    • a Forms template (LAF_TEMPLATE.fmb)

To create a « fully equiped » new module from scratch.

    • attach the laf.pll library, compile and run !

 Forms template demonstration

December 2008

slide26
How to implement the L&F in existing modules?

The JDAPI_LAF tool

    • Written in Java to use the Oracle Forms JDAPI feature.
    • It Uses a XML configuration file to upgrade existing modules

in a massive way.

    • It runs directly from the command line.

 JDAPI_LAF demonstration

December 2008

slide27
How to maintain the CSS file?

The css_updater.fmb Forms’ sample dialog

    • Updates any tag in any section of any CSS file.
    • Displays immediately any change done in any property.

 css_updater.fmb demonstration

December 2008

slide28
Some links
  • Oracle Forms Look and Feel project home page

http://sheikyerbouti.developpez.com/forms-pjc-bean/LAF/doc/Oracle_Forms_Look_and_Feel_project.htm

  • Forms Java Beans and PJCs’ library

http://forms.pjc.bean.over-blog.com/

  • Francois Degrelle’s blog

http://fdegrelle.over-blog.com/

  • White papers on OTN Forms section
    • Dynamic Color Customization
    • Generic LOVs

http://www.oracle.com/technology/products/forms/techlisting10g.html

December 2008

where to find additional information
Where to find additional information
  • Log in to Metalink
      • Click on Knowledge tab
      • Under Tools and Training on the left side of screen click on Training (Web Seminars)
      • Click on Advisor Webcast Program
  • Forms Advisor webcast scheduling:
    • Metalink Note 423317.1
  • Please submit your comments:
    • Karin.Haeussler@oracle.com
  • Please suggest webcast topics:
    • Karin.Haeussler@oracle.com
  • Forms Advisor webcasts scheduling:
    • Metalink Note 423317.1
slide30

?

Questions

  • There will be no Q&A Session at the end
    • Instead, please send an email tof.degrelle@free.fr
    • During the Q&A session your question will be read and an answer will follow.
thank you
THANK YOU
