Presentation Transcript
what does the respiratory system do
What Does The Respiratory System Do?

The respiratory system takes in oxygen to circulate around the body for many uses such as creating ATP, supplying systems with oxygen for smelling and speaking.

Also, includes that fibers that filter particles from the outside air to and from the lungs

Encompasses the whole process by which oxygen is delivered to the cells and used to break down glucose from food, releasing energy.

the lungs
The Lungs

They are covered by fluid-filled double transparent membrane called thepleura. Beneath the pleura is a dome shaped muscle structure called the diaphragm which contracts and relaxes to expand and relax the lungs.

the bronchial tree
The Bronchial Tree

The bronchial tree consists of branched air passages that lead from the trachea to the airs sacs.

nasal cavity
Nasal Cavity

The nasal concha divide the nasal cavity into passageways and help increase the surface area of the mucous membrane. The mucous membrane with hairlike projections called cilia, lines the nasal cavity and moistens, filter and warms incoming air. Particles caught in mucous is carried away to the pharynx as a result of the ciliary action, and are eventually swallowed.

nasal cavity1
Nasal Cavity

The mucous traps invading germs with antibacterial enzymes, cilia then allows for mucous to be swallowed.

pharynx
Pharynx

Behind nasal nasal cavity, oral cavity, and larynx

Passageway for air and food

Consists of nasopharynx, oropharynx, and larynopharynx

larynx
Larynx

Conducts air and helps prevent foreign objects from entering the trachea

Composed of muscles and cartilages

Lined with mucous membrane

trachea
Trachea

Covered with a ciliated mucous membrane

Cilia move mucus and trapped foreign matter to the pharynx

bronchioles
Bronchioles

Bronchus branches from the lower trachea and carry air to the lungs.

They divide into smaller branches called segmental bronchial , and subdivide smaller and smaller into bronchioles.

alveoli
Alveoli

Approx 600 million Alveoli sacs exist on the tips of bronchioles.

Capillaries in the walls of Alveoli absorb oxygen, and release Co2 and H2O to be exhaled.

breathing mechanism
Breathing Mechanism

The action of breathing in and out is due to changes of pressure within the thorax, in comparison with the outside

When you inhale, intercostals muscles move rib cage upwards and out

Increase in size and decreases internal pressure and air from outside rushes into the lungs to equalize the pressures

breathing mechanism1
Breathing Mechanism

When you exhale, the diaphragm and intercostal muscles relax and return to their resting positions

Reduces size of Thoracic cavity, increasing pressure and forcing air out of the lungs

the pathway of air
The Pathway of air

With each breath...

Person clinches diaphragm, making a vacuum that air is drawn into

The air enters trachea moving through one of the two bronchial tubes

They branch into smaller into smaller bronchioles ending in alveoli (small sacs)

Alveoli contain capillaries in the walls. Red blood cells that carry carbon dioxide from the body trades the carbon for oxygen in air by diffusion

the pathway of air cont
The Pathway of Air (cont.)

Oxygenated blood travels all over the body, supply oxygen when needed

Diaphragm relax, carbon dioxide rushes out of the alveoli, through bronchioles and bronchial tubes, out of the trachea and out of the body

respiratory center of the brain
Respiratory Center of The Brain

Groups of neurons scattered through the pons and Medulla Oblongota make up the respiratory center of the brain.

The Medullary Rhythmycity area have two neuron groups: Dorsal and Ventral that extend the length of the Medulla Oblongota

dorsal respiratory
Dorsal Respiratory

This controls the basic rhythms of inspiration. Neurons emit bursts of impulses that signal the Diaphragm and the other breathing muscles to contract.

ventral respiratory
Ventral Respiratory

This group usually is very quiet when breathing normally, but if you are more active and have more forceful breathing, like in exercise, this group is activated.

respiratory membrane
Respiratory Membrane

The respiratory membrane is absorbent tissue where gases are exchanged between alveolar air and the blood

4 layers of the respiratory membrane
4 Layers of the Respiratory Membrane

Alveolar epithelial wall

Alveolar epithelial basment membrane

Capillary basement membrane

Endothelial cells of capillaries

gas exchange
Gas Exchange

Blood that is low in oxygen is pumped from the right side of the heart, through pulmonary veins

External respiration

Carbon dioxide fuses from the Pulmonary Capillaries into the alveoli, oxygen diffuses from the alveoli into the pulmonary capillaries

internal respiration
Internal Respiration

Internal Respiration

Oxygen-rich blood is pumped through the systemic circuit to tissues throughout the body.

Internal respiration occurs within tissues, as oxygen diffuses from the systemic capillaries into the cells, and carbon dioxide diffuses from the cell and into the systemic circuit.

external respiration
External Respiration

Each breath draws down through the bronchi and bronchioles into the alveoli. Here, in the air sacs, occurs the central process of external respiration.

how oxygen diffuses
How Oxygen diffuses

Usually, air is about 78% Nitrogen, 21% oxygen, and 0.04% Carbon Dioxide

When air is inhaled, the gas molecules are filtered through, come into the Alveoli, and dissolve into the blood stream and diffuse with the stream in areas of differentiating pressure.

98% of oxygen binds to the Iron in Hemoglobin, and is pumped through the body by the heart. The other 2% of Oxygen dissolves into the plasma

oxygen increase
Oxygen Increase

Oxygen is released faster over time as the Carbon Dioxide concentration increases, the environment becomes more acidic, or as blood temperature increases. This is why you breathe harder to bring in more oxygen when exercising

Blood flow picks up Carbon Dioxide and transported in three different forms.

Some dissolves into plasma, some attach to Hemoglobin and makes its way back out to the lungs, and the third becomes Bicarbonate ions.

CO2 bonds to the amino acids in Hemoglobin, and can be carried out on Hemoglobin with Oxygen already on it.

bicarbonate ions
Bicarbonate Ions

The Bicarbonate ions are when CO2 react with H2O to create a carbonic acid, then results in the ions. This then travels out with the blood stream, through capillaries of the lungs, dissolves in the alveoli, and exhaled.

rate of diffusion depends on
Rate of Diffusion depends on

Partial pressure difference

Large surface area of alveoli

Diffusion distance (Membrane thickness)

factors that affect breathing1
Factors that affect breathing

Asthma: Narrowed airways caused by an allergic reaction (i.e Dust, Pollen, Smoke). Infections or a large amount of physical activity can cause an attack.

Whooping Cough: Attacks the Bronchi, inflame lung tissues, and create thick fluid to weaken breathing.

factors that affect breathing2
Factors that affect breathing

Tuberculosis: Bacterial infection of the lung cavities, and potentially fatal.

Bronchitis: Inflammation of Bronchi and coughing of yellow mucosa fluid.

Pneumonia: Inflammation of lungs from infection. Parts of lungs fill with fluid and become airless.

the end
The End

You have five to ten minutes to study before taking the quiz.
