orange county s water story regional water issues and the import supply

Orange County’s Water Story:Regional Water Issues and the Import Supply

Stan Sprague

General Manager

Municipal Water District of Orange County

Santiago Canyon College Managerial Issues Class

chapter 1
Chapter 1

Water supply development in Orange County

Once upon a time...

at the turn of the last century the turn of the last century,
  • Early settlements near surface water streams
  • Later development depended on groundwater
  • By turn of the century, settlers were outpacing nature’s ability to replenish
la turns to owens valley
…LA turns to Owens Valley
  • Development of L.A. Aqueduct
  • Access for others came at the price of annexation to Los Angeles
others turn to the colorado
Others turn to the Colorado...
  • Metropolitan Water District formed in 1928 to provide imported water to Southern California
    • Anaheim, Santa Ana, Fullerton were original members
    • Coastal MWD formed in 1941
    • MWD of Orange County formed in 1951
meanwhile orange county shores up rights on the santa ana river
Meanwhile, Orange County shores up rights on the Santa Ana River
  • Orange County Water District (OCWD) formed in 1933 to file lawsuit to litigate rights vs. upstream diverters
  • Availability of import water leads to agency taking preeminent role in groundwater management
eventually we all look north
Eventually, we all look north
  • SWP authorized by voters in 1960
  • First water delivered in early ‘70s
  • Contractually agreed to 2 MAF/year to Southern California

Where Southern CaliforniaGets its Water Today

Transfers & Storage

Local Supplies

LA Aqueduct

Colorado River Aqueduct

SWP Entitlement

Local Supplies

Groundwater & Recycling



chapter two
Chapter Two

Who is the Municipal Water District of Orange County?

mwd of orange county is
MWD of Orange County is...
  • Wholesale water supplier for Orange County
  • Governed by 7-member elected board
  • 30 retail agencies
  • Among the largest of Metropolitan’s member agencies
  • Service area of 600 square miles
  • Service area population of 2 million
  • Four (4) directors appointed to Metropolitan board
mwd of orange county exists to
MWD of Orange Countyexists to...
  • Coordinate and plan local water management programs in Orange County
  • Secure a reliable supply of imported water
  • Represent local retail agencies that provide water directly to homes and businesses
mwd of orange county as planner
MWD of Orange Countyas Planner…
  • Initiated and Manages South Orange County Reliability Study
    • Will make recommendations for both system and supply reliability improvements
    • Implementation will be cooperative effort
  • Analyzes data and trends and coordinates projects and programs with retail providers throughout the county
mwd of orange county as advocate
MWD of Orange Countyas Advocate…
  • Represents water agencies and cities
  • Influences and helps develop policies
    • at Metropolitan
    • at local government level
    • at State & Federal levels
  • Works with other Orange County water providers
  • Helps to secure funding for local agency projects
mwd of orange county as service provider
MWD of Orange Countyas Service Provider…
  • Water-Use Efficiency Programs
  • School Education
  • Water Emergency Response Orange County (WEROC)
  • Water-related legislative tracking, analysis and advocacy
chapter three
Chapter Three

Traditional Imported

Sources Challenged

our county s supplies
Our County’s Supplies
  • Orange County depends on imported water for almost half of its total supply
    • 48% groundwater
    • 46% imported through Metropolitan from Colorado River Aqueduct and State Water Project (Northern California)
    • 4% recycled water
    • 2% local surface water
challenges for orange county s traditional imported water sources
Challenges for Orange County’s traditional imported water sources...
  • Questions about water rights and surplus availability
  • Increasing environmental regulations and restrictions
  • Water quality concerns, i.e. impacts of salinity and organic compounds require greater treatment levels, and hamper recycling and groundwater uses

Colorado River issues

  • Metropolitan has high priority entitlement to approximately 700,000 AF
  • Additional 500,000 AF annually comes from surpluses
  • Arizona & Nevada now taking full shares, other states wary, drought conditions continue to worsen
  • Interior Secretary declares no surplus water in 2003
immediate concerns
Immediate concerns …
  • California’s inability to agree to a plan to reduce its take of surplus water over 15 years
  • Immediate cutbacks on surplus supplies eliminated “soft landing” option
  • Southern California will now only receive an 800,000 AF allocation in 2003
long term concerns
Long-term concerns …
  • Over allocation
  • Growth in other basin states
  • Native American lawsuits
  • Mexico
  • Water quality concerns
    • Perchlorate
    • Moab tailings
    • Salinity
challenges to northern california water
Challenges to Northern California water




  • San Francisco Bay/ Sacramento-San Joaquin River Delta
    • Hub of State’s water system
    • Degraded ecosystem
    • Poor water quality
    • Supply impacted by endangered species
    • Early 90s drought, regulatory actions create crisis


San Francisco

Los Angeles Aqueduct

Colorado River Aqueduct

Los Angeles

challenges to northern california water26
Challenges to Northern California water
  • Struggle is to maintain what we have
  • Historical annual supplies to exporters from the Bay-Delta have been cut by 25% due to federal actions
  • Future regulatory actions threaten to cut supplies by another 25%
  • This year, State can only promise 45% (approximately 900,000 AF)
calfed bay delta program
CALFED Bay-Delta Program
  • CALFED Bay-Delta Program to the rescue
    • Joint state-federal consortium formed in 1994
    • California Bay-Delta Authority created in January 2003
      • Collaborative, non-regulatory process to fix problems in the Delta
      • Implementation of Record of Decision
      • Reduce conflict among stakeholders

Chinook Salmon

1989 - Winter-Run Threatened

1994 - Winter-Run Endangered

1999 - Spring-Run Threatened


1998 - Threatened

Sacramento Splittail

1999 - Threatened

Green Sturgeon

2001 - Petitioned for listing

Endangered Species Act

Protected Species in the Delta

Delta Smelt

1993 - Threatened


CALFED’s Ecosystem Accomplishments

  • Status:
  • 382 new projects
  • $398 million
  • 100,000 acres new wetlands
  • 17 new fish screens
  • 10 diversion dams removed

Delta Smelt

Nearing Recovery!

Environmental Gains Fishery Recovery – It’s Working!

Delta Smelt Fall Midwater Trawl Index


New fish ladder

Dam removed

Environmental Gains Fishery Recovery – It’s Working!


Spring-run Chinook Salmon -- Butte Creek


3 new fish screens & ladders

3 dams removed

# of Fish









Winter Run Chinook Salmon Adult Female Spawner Escapement

Winter-Run Chinook Salmon

Current take limit is 15 times higher than initially

Environmental Gains Fishery Recovery – It’s Working!

what calfed could mean to orange county s future
What CALFED could mean toOrange County’s future
  • Hope for some long-term regional relief
    • Improved water quality
    • More certainty = Better local resource managementand planning
  • Expansion of local projects
    • CALFED won’t necessarily result in more water
    • Limited imported supplies means local agency projects will become increasingly critical
chapter four
Chapter Four

The Local Story

where does this leave us
Where does this leave us?
  • Current total demand on Metropolitan is 2.0 MAF per year
  • Expected to marginally increase over next 10 years
  • Supply reliability to So. Cal. projected to be fairly stable over next 10 years (if no surprises)
local reliability issues emerge
Local reliability issues emerge
  • South County - 500,000 residents - depend on two major pipelines and single treatment plant for 90% of their water service
  • One of two main MWD pipelines feeding South County damaged in December 1999
  • OCWD proposes lowering pumping percentage to deal with overdraft of groundwater basin
  • Reliability of the water supply and delivery network is a top priority for all
orange county s population growth north and south
Orange County’s Population GrowthNorth and South


Population (millions)

1990: 1.89

2000: 2.18

2010: 2.30

2020: 2.36





Santa Ana

Population (millions)

1990: 0.51

2000: 0.68

2010: 0.79

2020: 0.87

20-Year Growth:

0.18 (8%)

Rancho Santa Margarita


Huntington Beach


20-Year Growth

0.37 million (13%)

Newport Beach

20-Year Growth:

0.19 (28%)

Laguna Niguel

San Clemente


Orange County’s Water ConsumptionNorth and South


Water Use (acre-feet)

2002: 549,000

2025: 634,000

Additional Demand: 85,000 (15%)




Santa Ana

Rancho Santa Margarita


Huntington Beach


Water Use (acre-feet)

2002: 134,000

2025: 180,000

Additional Demand:

46,000 (34%)

Newport Beach


Additional Demand

131,000 (19%)

Laguna Niguel

San Clemente

where will additional supplies come from
Where will additional supplies come from?
  • Santa Ana River/Groundwater Basin
  • Groundwater Replenishment System (GWRS)
  • Metropolitan Import / Water Transfers
  • Water Use Efficiency
  • Water Recycling
  • Colored water treatment (MCWD, IRWD)
  • Other local supplies
  • Ocean desalination
orange county reliability study
Orange County Reliability Study
  • Started looking at system & supply reliability
    • Focus on South Orange County
      • How to meet demands with major facility/system outages
      • Evaluate alternative supply options, including ocean desalination
  • Second Phase to be completed July 2003
    • Highlights projects/programs for system and supply reliability
      • Ocean Desalination
      • Central Pool Augmentation
      • Regional Storage
      • Water Use Efficiency
      • Expanded interconnections
where are we headed
Where are we headed?
  • Water Reclamation:
    • Dual plumbing systems (IRWD)
      • Expanding usage from agricultural to urban
        • Irrigation of medians, open space, etc.
    • Brackish water desalination
      • Upstream Santa Ana River Watershed
      • Irvine Ranch Water District
      • City of Tustin
      • San Juan Basin
      • South Coast Water District
what have we been doing
What have we been doing?
  • Water Use Efficiency:
    • $6-7 million spent on WUE programs annually
    • Collaborative partnerships between:
      • MWDOC, OCWD, OCSD, MWD & Local retail agencies
      • U.S. Bureau of Reclamation & EPA
      • County of Orange
      • State of California
what have we been doing44
What have we been doing?
  • Water Use Efficiency:
    • 300,000 ULFT toilets have been installed (10,000 AF/year savings)
    • 270,000 showerheads have been installed (1,500 AF/year savings)
    • 3,250 clothes washers have been installed (43 AF/year savings)
    • Computer controlled irrigation system retrofits (8,500 AF/year savings)
    • Weather Based Controllers (Estimated 37-57 GPD savings)
      • 5,000 controllers will be installed beginning in summer 2003
      • Funding through Proposition 13, Metropolitan and local agencies
    • Overall WUE savings = 10-15%
  • *Savings based on lifespan of fixtures/controllers
what have we been doing45
What have we been doing?
  • Water Use Efficiency:
    • Industrial Water Use
      • MWD overseeing rebate/retrofit programs ($500,000/year)
      • Studies needed to determine how to recapture industrial processed water for reuse (cooling towers, recycling systems in die plants, etc.)
    • Landscape Performance Certification Program
      • Develop landscape irrigation budgets for more than 12,000 landscape meters
      • Technical workshops offered
      • Annual water savings of 12,000–24,000 AF ($5.4–$10.8 million)
ocean desalination in orange county
Ocean Desalinationin Orange County
  • Pre-development work for Ocean Desalination Plant in Dana Point
    • Submitted to Metropolitan on June 28, 2002
  • Poseidon Ocean Desalination Plant in Huntington Beach - 50 MGD
    • EIR is being completed by HB
    • MWDOC is assisting two of its agencies, Santa Margarita WD and Southern California WC with implementation of necessary agreements to access water
coming full circle
Coming full circle
  • Struggle to maintain current imported supply means we must make the most of what we have
  • Local options:
    • Water Recycling
    • Water Transfers
    • Conjunctive Use
    • Water Conservation
    • Desalination
  • Local delivery network must be reliable

Stan Sprague(714) 963-3058
