Presentation Transcript
objectives
Objectives
  • At the end of this module, you will be able to:
    • Understand the basic Process for the mandantory Upgrade of BW to the lastest Version available (7.30)
    • Explain the main Options for transfering the existing NetWeaver BW system running on anyDB to the SAP HANA database.
      • fresh system installation
      • system migration (w/o transfer system)
      • comination of both options
    • Find additional ressources within SAP to understand the complete picture surrounded by the new created e2e Guide for BW on HANA migration
business example
Business Example

With BW 7.30 SP05 it is now possible to move an existing BW system from anyDB to the new In-Memory database HANA.Tom is a SAP basis administrator who has to set up and implement the new BW system into the landscape and provide the Pilot/PoC environment in his company. Therefore he needs to familiarize himself with the upgrade, systemcopy (homogeneous / heterogeneous) and basis tasks of the current SAP NetWeaver BW release 7.30.

agenda sap bw on hana migration
Agenda – SAP BW on HANA Migration

System preparation

  • Upgrade NetWeaver 7.30 - ABAP

System migration

  • homogeneous systemcopy
  • heterogeneous systemcopy

System finalizing

  • systemcopy - post work
  • implementing BI-JAVA 7.30
  • conversion of DataStore Objects and InfoCubes

Further resources

  • operations, sizing
  • LES session, CW, online training
upgrade to bw 7 30 abap
Upgrade to BW 7.30 - ABAP
  • NetWeaver Java 7.30 is now shipped together with BW 7.30. Mandatory you should separate the Java Stack prior to the Upgrade of the ABAP Backend, if not already done. The new split/deinstallation tool for the Java Stack is expected to be available November 2011. If you are already in the process, consider the manual deinstallation of the Java Add-In until it’s availability.
  • The BICS are moving to the upcoming SAP BusinessObjects Application Platform BI 4.x, which is also a prerequisite for the full usage of the BEx successor - Analysis -
  • The Java component BW-IP modeler is redeveloped for BW 7.30 in ABAP HTTP, so the Java Server will not be used anymore for the BW-IP infrastructure in the future after BW 7.30
  • The new BI Authorization concept is now mandantory. Despite the fact that you either create a 7.0x System beforehand to migrate the old BW Authorization, a potential Upgrade from BW 3.5 to 7.30 would be possible.
  • Note 1641432 - SAP Product Master Releases
  • Some technology facts and updates
upgrade to bw 7 30 abap1
Upgrade to BW 7.30 - ABAP
  • Note 1532805 - Add-On Compatibility of SAP NetWeaver 7.3
  • There is a SEM Add-On available with BW 7.30. The SEM (6.34) Add-On is available since end of Q1/2011 for all Customers. See Notes 1539356 and 1531022 for more details.SEM 6.34 is HANA enabled, see Note 1648413 for more Details.
  • There is also the BPC 10.0 Add-On available with BW 7.30 which is currently in Rampup (GA expected for November 2011). With NetWeaver Version there is no Windows Server necessary anymore (web based maintenance). See Notes 1585589 and 1620027 for details. It is planned with SP06 (CPMBPC 800) to be HANA enabled
  • Add-On´s GRC or DMIS are not enabled for the Upgrade to NetWeaver 7.30
  • Decision about installed Add-On´s
upgrade to bw 7 30 abap2
Upgrade to BW 7.30 – ABAP

Choose your NetWeaver BW Start Release

  • SEM Add-On Implications

BW 7.0/SEM 6.0

Upgrade to

  • NetWeaver 7.30
  • SEM 6.34
  • Not possible!

BW 7.02/SEM 6.05

Upgrade to

  • NetWeaver 7.30
  • SEM 6.34
  • Not possible!

BW 7.0/SEM 6.0

Upgrade to

  • NetWeaver 7.01
  • SEM 6.04
  • possible!

BW 7.01/SEM 6.04

Upgrade to

  • NetWeaver 7.30
  • SEM 6.34
  • possible!

Consider Notes 1531022 and 1539356

Additional option: Upgrade BW 7.02/SEM 6.05 to BSi2011/BW 7.31/SEM 7.36(Application Innovation merge with NetWeaver 7.02 and 7.31)

n ew bi 4 0 installation for sap bw customers

… (*)

LCM Client

ABAP 7.30

EP

BICS

BEx Web

J2EE 7.01

J2EE 7.30

ABAP 7.01

ABAP 7.0

J2EE 7.0

EP (opt)

BICS

BEx Web

BI Launch Pad

New BI 4.0 Installation for SAP BW Customers

SAP BW 7.01

SAP BW 7.0

SAP BW 7.30

  • Platform View - Proposal

Split

BI Web Apps

BI Web Tier

BI Java

BI Java

EP

XI Reporting & Infrastruc. Services

EP

EP

BOE XI Web Tier

BI Java

Physical Server (optional)

BO XI 3.1

SAP NetWeaver

BI 4.x

SAP NetWeaverFunctions

Migr.

SAP Usage Type and

SAP BusinessObjectsTiers, Apps, Services

BI Reporting & Infrastructure Services

The XI 3.1/BI 4.0 Java apps can deployed either on an existing SAP J2EE 7.0x or 7.30 Engine, or ideally capsulated with BI with Tomcat. Consider the SAPJVM 4.1. A JVM switch toll is available as well

j2ee options for bi 4 0 together with bw 7 30
J2EE Options for BI 4.0 together with BW 7.30

BI 4.0

  • use the recommendation with the BI 4.0 inbuilt Java Server

SAP NetWeaver J2EE 7.30

Other J2EE

(see PAM)

BI 4.0 SP? Only

BICS

BEx Web

BI 4.0 SP?

Usage Type EP

Usage Type BI Java(BICS, BEx Web)

BI 4.0

BICS

BEx Web

Install

Upgrade from BW 7.0x

Install

  • BEx Web Limitations*
  • No Broadcasting (Portal/KM)
  • No Documents (Portal/KM)
  • No Xcelsius BW Connection
  • BEx Web Limitations*
  • No Broadcasting (Portal/KM)
  • No Documents (Portal/KM)
  • No Xcelsius BW Connection

*Broadcasting is either a direct ABAP process (Excel) or an ABAP HTTP process publishing in a separate SAP EP Distinguish between 3.x and 7.x Web templates. 3.x Web template to not require BI - JAVA 7.x

doublestack options prior to the upgrade bw 7 30
Doublestack Options prior to the Upgrade BW 7.30

BW 7.0x Doublestack

  • separation of ABAP and JAVA easies the upgrade process

Deinstall JAVA Add-In

Use Split tool

Deinstall JAVA 7.0x Stack

Single ABAP 7.0x Stack

Deinstall JAVA 7.0x Stack

Fresh Install of

JAVA 7.30 (without ADS)

Upgrade

to JAVA 7.30*

Upgradeto BW 7.30 ABAP

BW 7.30ABAP Stack

NetWeaver 7.30JAVA Stack (with ADS)

  • JAVA 7.30 Upgrade limitation*
  • no automatic file system 7.x
  • no automatic SAPCryptoLib
  • disable SNC configuration

ADS = Adobe Document Services (obsolete with NetWeaver 7.30 BI-Java)

accelerated upgrade to netweaver bw 7 30 your single source for all pre and post upgrade steps
Accelerated Upgrade to NetWeaver BW 7.30Your single source for all pre and post upgrade steps

Lower your TCO and time efforts

by Managing your Upgrade with innovative tools

  • Complete Business Suite 7 connectivity (with EhP1):
    • abap - java connection (available) for connection BW-IP, EP, ESS/MSS, etc.
    • abap - abap (with EhP1) for backend connection e.g. ERP, CRM, BW, PI, etc.
    • java - java (upcoming) for frontend connection e.g. FPM, etc.
    • Note 1178800

2. CTC for BW-Java

automatic connection between Abap and Java(Note 983156)

1. ASU toolbox (incl. BW Content)

one single truth for all pre/post Upgrade Steps(Note 1000009)

  • Use the predefined content for:
    • upgrade to NetWeaver 7.x BW
    • upgrade to ERP 6.0 EhPx (upcoming)
    • upgrade to any SAP Product based on the NetWeaver 7.x Platform (upcoming)
    • create/modify own content (XML based)

Check out the success story from the German Customer Karcher: http://service.sap.com/~sapidp/011000358700000162292010E/

solution manager pre requisites incorrect stack xml can create unwanted follow up errors
Solution Manager pre requisitesincorrect stack.xml can create unwanted follow up errors
  • In order to successfully work with the Solution Manager to create necessary stack.xml, which is a new requirement in NetWeaver based upgrades the following checks had to be fullfilled prio to the cration of the stack.xml.
      • Suffient privelidges for the s-user, which is connected to the Service Market Place (SMP)
      • Updated PPMS data, to ensure the correct processing of the desired Upgrade Target‘s
      • Latest SP‘s/correction/Notes for the correct usage of the Solution Manager applications
  • For more information about the Maintenance Optimizer, see SAP Support Portal at
      • http://service.sap.com/solman-mopz
post activites after upgrade to bw 7 30 additional notes so far
Post Activites after Upgrade to BW 7.30Additional Notes (so far):
  • Note 1610259 - Controlling 'Returncode' behavior in update rules
  • Note 1489064 - DataSource problems after BW upgrade from 7.0 to 7.3
  • Note 1633303 - RSMDATASTATE inconsistencies after upgrade from 7.0x to 7.3x
  • Note 1632284 - Program RSCOMPCONS should generate warning messages
  • Note 1635588 - Problems with Start / End routine created at BW 7.0+ Release
postwork after 7 30 upgrade existing
Postwork after 7.30 upgrade - existing
  • Get everything which is needed here:
    • Managing your Upgrade with Innovative Toolshttp://www.sdn.sap.com/irj/sdn/edw-ops
    • The „upgradeBible“  frompage 52http://www.sdn.sap.com/irj/sdn/go/portal/prtroot/docs/library/uuid/60ecc07d-3a4b-2b10-ef83-c988e6ecabf6
  • Check the generic post upgrade steps from here
agenda sap bw on hana migration1
Agenda – SAP BW on HANA Migration

System preparation

  • Upgrade NetWeaver 7.30 - ABAP

System migration

  • homogeneous systemcopy
  • heterogeneous systemcopy

System finalizing

  • systemcopy - post work
  • implementing BI-JAVA 7.30
  • conversion of DataStore Objects and InfoCubes

Further resources

  • operations, sizing
  • LES session, CW, online training
system copy use cases considering the initial system copy case
System Copy Use Casesconsidering the “Initial System Copy” case

Initial System Copy

Execution of post copy activities with Post Copy Automation

SourceABAP-System

PROD

Export und Import of tables with Post Copy Automation

SAP NetWeaver ABAP 7.0 or higher

System copy with SAPInst / DB-Tools

System Copy with SAPinst / DB-Tools

Export

TargetABAP-System

Execution of post copy activities

TST

TST

Import

System Copy Refresh

TargetABAP-System

TST

SourceABAP-System

TST

PROD

SAP NetWeaver ABAP 7.0 or higher

option1 fresh installation of bw on hana copy only parts of your existing productive system
Option1: Fresh Installation of BW on HANA  copy only parts of your existing productive system

*

Fresh Install “ORANGE” (7.30)

UC enabled

transport only parts of the system

Note 1090842 - Composite note: Transport across several releases

Note 454321 - Transports between Basis Release 6.* and 7.0

Note 1273566 - Transports between Basis Release 700/701 and >=702

Production

BWP

ORANGE

Development

Consolidation

BWx

BWD

BWQ

*

BW

Transport

Transport

BW 7.0/7.0x7.30

BW 7.30SP05+

ALE / RFC

ALE / RFC

ALE / RFC

ALE / RFC

Transport

Transport

ERP

alternate PoC scenarioduring ramp-up!

Development

Consolidation

Production

R3D

R3Q

R3P

option2 system copy with bw on hana poc system creation via production copy safe side
Option2: System Copy with BW on HANA  PoC System creation via Production copy (“safe side”)

copy of Production (7.x)

homogeneous systemcopy

Upgrade NetWeaver 7.30

copy to “ORANGE” (7.30)

heterogeneous systemcopy

UC migration included

ORANGE

Production

BWx

BWC

Production

BWP

BW

Transport

BW 3.57.0/7.0x7.30

BW 7.30SP05+

BW 7.30SP05+

add. preparation

data cleansing

ALE / RFC

ALE / RFC

Transport

ERP

Production

R3P

preferred PoC scenarioduring ramp-up!

option3 system copy with bw on hana new system direct creation when bw 7 30 sp5 is live
Option3: System Copy with BW on HANA  new System direct creation when BW 7.30 SP5+ is live

copy to “ORANGE” (7.30)

heterogeneous systemcopy

UC migration included

Production

BWP

ORANGE

Development

Consolidation

BWx

BWD

BWQ

BW

Transport

Transport

BW 7.30SP05+

BW 7.30SP05+

ALE / RFC

ALE / RFC

ALE / RFC

ALE / RFC

Transport

Transport

ERP

Development

Consolidation

Production

R3D

R3Q

R3P

go live system copy with bw on hana complete bw landscape transformation

distributed (ABAP/DB)

heterogeneous systemcopy

using existing App Servers

UC migration included

Go-Live: System Copy with BW on HANA complete BW Landscape transformation

Development

Consolidation

Production

BWD

BWQ

BWP

Transport

Transport

BW

Consolidation

Production

Development

BHQ

BHP

BHD

Transport

Transport

BW on HANA

agenda sap bw on hana migration2
Agenda – SAP BW on HANA Migration

System preparation

  • Upgrade NetWeaver 7.30 - ABAP

System migration

  • homogeneous systemcopy
  • heterogeneous systemcopy

System finalizing

  • systemcopy – pre/post work
  • implementing BI-JAVA 7.30
  • conversion of DataStore Objects and InfoCubes

Further resources

  • operations, sizing
  • LES session, CW, online training
checklist prior to the import to sap in memory db
Checklist - prior to the import to SAP In-Memory DB
  • Check binaries for SAPInst, R3*, import/export tools
  • Run report RSUPGRSUM, if needed use „repair InfoObjects“ to repair Objects from RSD1
  • Check DBACOCKPIT for missing indexes and run SAP_INFOCUBE_INDEXES_REPAIR
  • Check SE14 for unfinished table conversion
  • Run Report SAP_DROP_TMPTABLES and RSAN_UT_RESULT_DROP_RESULTS (interim) to delete all kind of BW specific temporary tables beforehand.
  • Clean/delete the messages for error logs (Note 1095924)
    • Check: RSB_ANALYZE_ERRORLOG
    • Clean: RSBM_ERRORLOG_DELETE
  • Check ODS objects in RSA1 for correct activation (RSDS_DATASOURCE_ACTIVATE_ALL)
  • Optionally: stop any deamon‘s and process chains with report RS_SYSTEM_SHUTDOWN before you stop all batch processes with BTCTRNS1
  • Run Report SMIGR_CREATE_DDL before export (SP5 or higher version needed), check as well for the latest correction prior to it´s execution.
    • Choose target database „SAP In-Memory DB“, unicode and the target directory
  • Run option export from SAPInst from transfer system (export preparation/table splitting)
    • Choose target database „HDB“ (in-Memory DB)
    • Choose „little endian“ (for OS linux) and unicode option
slide24
Check for the biggest Tables before the export creationReport SMIGR_BIG_ROW_STORE_TABS (for row store tables)
  • <export>/ABAP/DB/HDB/rowstorelist.txtNote 1659383 - RowStore List for SAP Netweaver on SAP HANA Database
slide25
Check for the biggest Tables before the export creationTransactionDBACOCKPIT/DB02(for row/column store tables)
  • consider table splitting for export/import for the „top50“ largest tables
  • house keeping jobs, cleaning, reduction of data in the largest tables to consider prior to th export
bw system copy post steps
BW system copy post steps
  • Crosscheck the availability of the following files prior to the import into HDB:
      • The DDLHDB.TPL file in <export>/ABAP/DB (Note 1639744)
      • The (correct) *.SQL files with report SMIGR_CREATE_DDL in <export>/ABAP/DB/HDB (Note 1600929)
      • The updated rowstorelist.txt in <export>/ABAP/DB/HDB (Note 1659383)
  • Run BTCTRNS1 to prevent the unwanted start of batch job’s
  • BDLS (check for corrections)  Test Run and Productive run
  • RSA1  source systems  BW system  restore
      • run in background
      • optional: check for RFC GTADIR_SERVER and Note 1586248  remove RFC connection
      • run RSAR_PSA_NEWDS_MAPPING_CHECK in advance
      • check the partner profiles in WE20 for the systems, and check IDoc ports in WE21 for the systems.
  • Report RS_BW_POST_MIGRATION (run in Background with Variant SAP&POSTMGRHDB)
  • RSSGPCLA  reset programs for ODS and DTP
  • Optional: Report RSUPGRCHECK (check for inactive objects overall)
  • Report RUTMSJOB  use the transaction above to solve inconsistencies
  • Run report RS_SYSTEM_SHUTDOWN to restart all process chains and deamon´s again
report rs bw post migration run in background with variant sap postmgrhdb
Report RS_BW_POST_MIGRATION run in Background with Variant SAP&POSTMGRHDB
  • The Report is intend to run directly in Background with the Variant for HDB,updated with Note 1657995
  • However the reset of ODS Objects are still necessary (next page)
bw system copy post in memory conversion steps
BW system copy post In-Memory conversion steps

for the visualization of the transaction RSMIGRHANADB you can add the following RSADMIN parameter ENBL_HDB_MIGR_DSO = X

Run ONLY for selected Cubes and DSOs

hana optimized infocube design in bw
HANA optimized InfoCube Design in BW

HANA can work with “flat” structures and doesn’t need E- and F-fact tables!

  • Physical schema of BW InfoCube tailored towards traditional RDBMS

MD

MD

MD

MD

D

E

Conversion / New

F

F

Facts

Facts

D

MD

MD

MD

MD

Benefits:Fast data loads (no DIMIDs)  up to 80% time reductionDimensions not physically present  simpler modeling and faster structural changesAll processes, all Queries and MultiProviders can remain unchanged

in memory optimized datastore objects overview and design
In-Memory Optimized DataStore ObjectsOverview and Design

Change Log

Active Data

Delta calculation completely integrated in InMemDB– no data processing in ABAP

Using in-memory optimized data structures for faster access

No roundtrips to application server needed

View

View

History Index(column based)

Main Index(column based)

Delta Index(column based)

Activation triggered by BW, performed byInMemDB

conversion steps and log overview
Conversion Steps and Log Overview
  • Create temporary fact table with “flat” structure Z0<InfoCube>
  • Read data out of the original fact tables dissolving the starschema and save data in temporary fact table
  • Rename package dimension database table TP<InfoCube>Rename validity table (in case inventory mgmt InfoCube) TL<InfoCube>
  • Empty the InfoCube tables
  • Set InfoCube subtype to “flat”
  • Activate the InfoCube - As it is empty the structures and their DDIC description can be adjusted
  • Delete Fact DB-table and rename the temporary one
  • Delete PDIM and rename the temporary one
  • Delete validity table and rename the temporary one
  • Delete temporary DDIC objects
  • Create logical index(This can be done with transaction RSMIGRHANADB)
agenda sap bw on hana migration3
Agenda – SAP BW on HANA Migration

System preparation

  • Upgrade NetWeaver 7.30 - ABAP

System migration

  • homogeneous systemcopy
  • heterogeneous systemcopy

System finalizing

  • systemcopy – pre/post work
  • implementing BI-JAVA 7.30
  • conversion of DataStore Objects and InfoCubes

Further resources

  • operations, sizing
  • LES session, CW, online training
detailed description in the e2e bw on hana guide http help sap com nw73bwhana section2
detailed description in the e2e BW on HANA guidehttp://help.sap.com/nw73bwhana#section2
notes to consider for sizing tools dbsl etc
Notes to consider for sizing, tools, DBSL, etc.
  • Note 1600929 - SAP BW powered by SAP inMemory DB – Information
  • Note 1600066 - Available DBSL patches for NewDB
  • Note 1639744 - heterogenious systemcopy NetWeaver 7.30 to HANA target DB
  • Note 1657994 - SAP BW 7.30 powered by HANA - Special SP06
  • Note 1514966 - SAP HANA 1.0: Sizing SAP In-Memory Database
  • Note 1637145 - SAP BW on HANA: Sizing SAP In-Memory Database
  • Note 548016 - Conversion to Unicode
  • Note 551344 - Unicode Conversion Documentation
  • Note 1589175 - System Copy: Task Content for Task Manager
  • Note 1589145 - Task Manager for Technical Configuration
  • Installation/Operational Guides: http://help.sap.com/nw73bwhana
main landing page one stop and e2e guide http www sdn sap com irj sdn edw ops
Main Landing Page – „one stop“ and e2e Guidehttp://www.sdn.sap.com/irj/sdn/edw-ops
internal collaboration workspace bw on hana https community wdf sap corp sbs docs doc 94307
Internal Collaboration Workspace – BW on HANAhttps://community.wdf.sap.corp/sbs/docs/DOC-94307
summary
You should now be able to

to understand the possible impacts regarding upgrade BW 7.30

to disdinguish between the different migration option

to phrase the steps of the in-memory conversion

and finally: If you don‘t unterstand any of these, you are capable to point into the right direction/resources for internal/external guidance on „BW on HANA – migration“

Summary
