  1. Presents “The World in Motion” to:

  2. 111 NE 1st St, 4th Floor Miami, Fl 33132 Tel (305) 579-9911 Fax (305) 579-9186

  3. QVision’s Mission is to lead the evolution of change in Advertising Media.

  4. Our Objective is to offer cutting edge technologies that Change the way Advertisers promote their products from Static to Motion.

  5. QVision, through an Exclusive Partnership develops and manufactures: QBoards - Large Scale Full Motion LED Billboards QDimension - 3D Motion Backlit Panels & Displays QReflection - Backlit Mirror Displays

  6. Where Traditional Static Structures advertise a Single Message, our Technology utilizes Motion to generate Visual Impact.

  7. QVision Team Ariel Quiros Chairman Howard Anders CEO/President Alan Amdur Chief Operating Officer Nicole Quiros Director of Finance William Kelly Director

  8. QVision Media Group Jackie Fernandes InterGroup, LLC Carol Joy

  9. QBoard Our Large Scale Full Motion LED Billboard, is manufactured, installed, and managed by QVision. QBoard was developed by implementing 15+ years of LED engineering & manufacturing expertise.

  10. QBoard Advantages • Minimal Service & Maintenance • Minimal Additional Media Production Costs • No Down Time • On-line PC located in the Miami Operations Center • Automated Brightness Adjustment • Perfect Visibility • Excellent Color and Resolution

  11. Audio/Video Sources Video Display Console TEXT DISPLAY PAL NTSC Control Panel AC Display Control PC Power Distribution Panel Operating PC QBoard System Configuration

  12. QBoard by QVision

  13. QBoard by QVision

  14. ITEM LED VIDEO & TEXT DISPLAY BOARD QBoard Technical Specifications VIDEO DISPLAY TEXT DISPALY Display Size (W)11.52M x (H)8.64M (W)12M x(H)0.6M LED pixel LED lamp composition Color Gradient Step Red 5, P.Green 3, Blue 2 4,096 steps/color Red 4, Y.Green 16, Blue 3 Module Unit Drive Method Power Dissipation Viewing Angle Viewing Distance Static Drive max. 200W, avr. 100W hor. :70 Deg, ver. :30 Deg 30 - 700 m Static Drive max.340W, avr. 170W hor. :70 / ver. :30 Degrees 40 - 600 m Display Board Display Area(Screen Size) Screen Aspect Ratio Frame Frequency Video Input Format 11.52M x 8.64M = 100(㎡) 4 : 3 60 Frame/sec. NTSC/PAL 11.2x0.56=6.3(㎡) Brightness Brightness Control Approx. 7,000cd/㎡ (NIT) 16 steps Approx. 5,500cd/㎡ (NIT) (at White Peak) Power Consumption Electrical Power Max. 90KW, Avr. : 45KW AC 220/380V 3Phase, 60(50)Hz Max.7KW, Avr.4KW Weight(LED Board only) Approx. 7,000Kg - Operating Temperature Operating Humidity -4 F to 140 F 20% ∼ 95%RH -4 F to 140 F 20% ∼ 95%RH Half Bright Degradation 50,000 hours 50,000 hours Housing Size (W)12.5M x (H)10M x (D)1.5M -

  15. LED Advantages over Traditional Billboards • Capitalize on creative adaptability by translating broadcast campaigns into persuasive outdoor clips. • Use directional support by providing proximity messages to roadside advertisers and local businesses. • Convey promotional reminders about a product or service moment before a purchase decision is made. • Solicit direct response support by communicating Website addresses, telephone numbers or other advertiser contact information.

  16. QDimension QDimension is an innovative display product and 3D medium. It is created by using AVS Technology, a unique process that produces 3D visual displays of extraordinary depth, distance and motion on a flat surface; as well as displaying images of unprecedented clarity and resolution.

  17. QDimension Effects ZOOM FLIP 3D

  18. QDimension Effects ANIMATION MORPH

  19. Advantages of QDimension • QDimension offers an innovative opportunity to display advertising. • Offers space maximization by including 5X more information. • The effects give a fun and exciting reflection on the advertised brand. • QDimension Display has a life of approximately 60,000 hours. • The brightness is kept at an optimum level of 8,000 lux.

  20. QDimension NL & L Components ①3D Picture : After processing the photo data, 3D source, 2D data with digital design and 3D, the picture is printed digitally.②A-PET : Transparent material that enables prism effect, depth and refraction to be visualized.③Prism film : Digital film, the film that controls digital accumulated picture and shows each part of the subject by an optical illusion.

  21. QDimension NL & L Components ▼ Composition : 3D Picture + A-PET + Prism film

  22. QDimension Effects • Zoom – Allows subjects to be viewed through a smaller to larger perspective. • Flip – Allows the transformation of images in a two-phase to three-phase sequence. • 3D – Allows innovative depth and sense of distance. • Animation – Allows series of still pictures to be displayed as motion. • Morph – Allows two subjects to transform into each other displaying a different image.

  23. QDimension Display Technology

  24. QDimension Display Technology

  25. Accumulating Visual Technology • AVS is the most advanced 3D media production technology in the world that displays images of innovative depth and distance in high clarity and resolution on a flat surface. 3D Photography Digital AV System Digital 3D Software Strong Adhesion With No Heat AVS Technology + + + =

  26. AVS Technology • 3D Photography – After calculating three different distance ranges, camera focus, track movement interval and camera movement time, 3D pictures are taken from more than 10 different angles. • Digital AV System – Creates 10-20 accumulated images that has 3D and 2D depth by dividing the layers of the subject. • Digital 3D Software – Compresses and combines 10-20 accumulated images into one 3D picture. • Strong Adhesion with No Heat – Adheres and transcripts 3D picture and prism film to A-PET with no heat.

  27. QReflection QReflection is a unique new advertising concept and medium. It is a lighted mirror box that can transform any ordinary mirror into a bright full color display advertisement. Wall mounted or freestanding, the box contains a motion sensor that can detect any object approaching the mirror and display a backlit full color advertisement. If an object detection is not what an advertiser want, a time setting can be set to vary the length of the display.

  28. QReflection

  29. QReflection

  30. ▼Lenticular lens + 3D Picture QD Cards Composition

  31. QDimension Vending Machines POP Refrigerators/Coolers Fountain Dispensers Delivery Trucks/Buses Promotional Tools QReflection Restaurants/Bars Entertainment Venues Hotels/Resorts Supermarkets/Convenience Areas of Application

  32. Thanks
