Presentation Transcript
Slide1 l.jpg

Where In The World?

GPS Instruction For Teachers

By: Krissy Vaux & Mark McBride

Tri-Valley H.S.

Downs, IL

STARS April 8, 2005


About the gps satellites l.jpg
About The GPS Satellites

  • There are 24 different satellites in space

  • They orbit the Earth every 12 hours in 6 different planes

http://www.ozebiz.com.au/beacon/etrek.html


About the gps satellites3 l.jpg
About The GPS Satellites

  • A minimum of 4 satellite signals must be received by the GPS unit to determine a 3-D position

  • GPS units can determine your latitude, longitude and altitude


About the gps satellites4 l.jpg
About The GPS Satellites

  • Most GPS units have an accuracy of <15 meters using the 24 satellites

  • The Garmin eTrex Legend uses the 24 satellites AND 25 ground stations to increase the accuracy to <3 meters

    -This is called the WAAS

    system

    (Wide Area Augmentation System)

http://www.garmin.com/aboutGPS/waas.html


How do gps units work l.jpg
How Do GPS Units Work?

  • GPS units DO NOT transmit satellite signals. They passively receive them

  • They measure the distance between the GPS unit and the satellites

http://tsc.wes.army.mil/gps/dgps.htm


Garmin e trex legend l.jpg

Garmin eTrex Legend


Power and light button l.jpg
Power and Light Button

  • Press and hold the Power Button to turn the unit on/off

  • Press and release the Power Button and the light will come on

  • You will see this page appear


Page button l.jpg
Page Button

  • Press the Page Button several times. You will see the display cycle through the main pages that look like this

Satellite Page

Map Page

Navigation Page

Trip Computer

Main Menu

At any time you can press the Page Button and return to one of the Main Pages


Satellite page l.jpg
Satellite Page

  • Press the Page Button until you see the Satellite Page

  • The Satellite Page provides a visual

    of the satellites being tracked

  • The black circles indicate which satellite signals are being received

  • The bars at the bottom show

    signal strength

    -Black bars indicate a

    stronger signal than a grey bar

    -4 black bars are required for a proper

    signal


Satellite page10 l.jpg
Satellite Page

  • For the best satellite signal you should…

    -Be outdoors

    -Have a clear view of the sky

    -Hold the GPS unit flat and out away from your body


Satellite page11 l.jpg
Satellite Page

  • The bottom of the Satellite Page also shows your GPS location and elevation (After you have 4 bars)

  • -The N or S line shows Latitude

  • -The E or W line shows Longitude


Satellite page12 l.jpg
Satellite Page

How many satellites are being used?______

How many bars of signal strength do you have?____

What is the GPS location of the Buzzard Hall?

(The building we were all in) _______________

_______________

What is the elevation?_______________


Map page l.jpg
Map Page

  • Press the Page Button 1 time or until you see the Map Page

  • The Map Page displays your movements, waypoints, latitude & longitude

  • The black arrow shows your location

  • Press the Up & Down Buttons to zoom in and out on the map

  • The numbers in the lower left show how much area is visible on that map


Map page14 l.jpg
Map Page

  • Zoom in until you are at 3 miles.

  • What towns are visible? _____________

    __________________________________

  • Zoom in until you are at120ft.

  • Walk around.

  • What happens?_____________________


Navigation page l.jpg
Navigation Page

  • Press the Page Button 1 time or until you see the Navigation Page

  • Walk from Buzzard Hall toward the Green House across the street

How fast were you walking?_______________

What direction were you walking?___________


Trip computer page l.jpg
Trip Computer Page

  • Press the Page Button 1 time or until you see the Trip Computer page

  • Move the Click Stick up/down or left/right until the single sheet of paper in the top right corner is highlighted and press strait in

    (Not the picture of several sheets of paper)


Trip computer page17 l.jpg
Trip Computer Page

  • A screen will drop down

  • Select Reset and press strait in

  • Select Apply and press strait in

  • Select OK and press strait in

  • This resets your Trip Computer


Trip computer page18 l.jpg
Trip Computer Page

  • Walk around until the Moving Time reads at least 2 minutes

    What does the Trip Odometer read?______

    What does the Max Speed read?_________


Main menu page l.jpg
Main Menu Page

  • Press the Page Button 1 time or until you see the Main Menu

  • Walk to a point you wish to mark as a Waypoint (A Waypoint is a stored location in your GPS unit)

  • Move the Click Stick up/down or left/right until the Mark icon is highlighted and press strait in

  • The screen will change to the Mark Waypoint Page


Mark waypoint page l.jpg
Mark Waypoint Page

  • This page comes up when you press the Click Stick strait in on the Mark icon

  • You have marked this spot as a Waypoint

  • A Waypoint is a stored location in your GPS unit

  • Move the Click Stick up/down or left/right until the number in the flag is highlighted and press strait in


Mark waypoint page21 l.jpg
Mark Waypoint Page

  • When you press the click stick strait in an alphabet screen will pop up

  • Name your Waypoint by Moving the Click Stick up/down or left/right until the correct letter is highlighted and press strait in

  • Do this until you have completed the name

  • When you are finished naming your Waypoint click on OK


Mark waypoint page22 l.jpg
Mark Waypoint Page

  • Choose at least 3 other waypoints you would like to mark

  • Be sure to mark and name them


Slide23 l.jpg

Main Menu Page:

  • Press the Page button until you are back to the Main Menu Page

  • Move the Click Stick up/down or left/right until the Find icon is highlighted and press strait in

  • The Find screen will pop up

  • Select Waypoint

  • Select By Name

    What Waypoints did you list in your GPS?

    ________________________________________


Main menu page returning to a waypoint l.jpg
Main Menu Page:Returning To A Waypoint

  • To Return to a Waypoint that you have already entered in your GPS unit repeat the previous page of instructions

  • Next use the alphabet page to type the name of the Waypoint that you wish to return to

  • Press OK when finished

  • When your Waypoint is displayed, press Go To

  • The Navigation Page will appear directing you to the Waypoint that you selected


Main menu page go to a known gps location l.jpg
Main Menu Page:Go To A Known GPS Location

  • To go to a GPS location that you have not been to before use the Page button to return to the Main Menu page

  • Select Mark

  • Use the Click Stick to highlight the Location box and press the Click Stick strait in

  • Use the Alphabet page to type in

    N 39°____________ W 088°___________

  • Select OK


Main menu page go to a known gps location26 l.jpg
Main Menu Page:Go To A Known GPS Location

  • Use the Click Stick to highlight the Elevation box and press the Click Stick strait in

  • Use the Number page to type in ______ft

  • Select OK


Main menu page go to a known gps location27 l.jpg
Main Menu Page:Go To A Known GPS Location

  • Use the Click Stick to highlight the Go To box and press the Click Stick strait in

  • The Navigation Page will pop up and direct you to the location

  • Which location did that GPS coordinate take you to? (Circle the correct picture)

Old Main Booth Library MLK Student Union


Map page continued measuring distance l.jpg
Map Page continued(Measuring Distance)

  • Press the Page button until you are back at the Map Page

  • Press the up and down buttons on the side of your GPS unit to zoom in close enough on your map to see all your waypoints


Map page continued measuring distance29 l.jpg
Map Page Continued(Measuring Distance)

  • Move the Click Stick up/down or left/right until the single sheet of paper in the top right corner is highlighted (Not the picture of several sheets of paper) and press strait in

  • A screen will drop down

  • Choose Measure Distance


Map page continued measuring distance30 l.jpg
Map Page Continued(Measuring Distance)

  • Use the Click Stick to move the white Reference Arrow to one of your Waypoints

    -When a box appears around the name

    of your Waypoint, you know you are

    on the correct spot

  • Push the Click Stick strait in to select the Waypoint

    (Notice that you can see the name and location of your Waypoint and you are 0.0 ft from it)


Map page continued measuring distance31 l.jpg
Map Page Continued (Measuring Distance)

  • Now move the Click Stick to a 2nd Waypoint

    (Remember that you know when you are in the correct location if a box forms around the name of the Waypoint)

  • This time DO NOT press the Click Stick strait in.

    (Notice that you can see the name and location of this 2nd Waypoint and its distance and direction from the first Waypoint)


Math application area calculation l.jpg
Math Application:Area Calculation

  • You can use this feature to calculate Area

    **For those of us who don’t want to use our brains to calculate ANYTHING… See the Area Calculation Via the Main Menu page**


Area calculation via the main menu l.jpg
Area Calculation Via The Main Menu

  • If you want to calculate Area WITHOUT math…

    • Press the Page button to return to the Main Menu page

    • Move the Click Stick up/down or left/right until the Accessories icon is highlighted and press strait in

    • Choose Area Calculator


Area calculation via the main menu34 l.jpg
Area Calculation Via The Main Menu

  • It will appear that you have returned to the Map Page, but if you notice it is labeled Area Calculation page

  • Walk to one street corner

  • Press the Click Stick strait in to Start

  • Walk to the next corner and turn


Area calculation via the main menu35 l.jpg
Area Calculation Via The Main Menu

  • Continue doing so until you make a complete circle around the block and end up at the same location you began

  • Press the Click Stick strait in to Stop

  • The area is calculated for you!!!!

  • What is the area of the land that block covers? _______________


Main menu page36 l.jpg
Main Menu Page

  • Press the Page button to return to the Main Menu page

  • Move the Click Stick up/down or left/right until the Find icon is highlighted and press strait in


Main menu page37 l.jpg
Main Menu Page

  • The Find screen will pop up

  • Choose Cities

  • Choose By Name

  • Type in the name of your favorite city

    How far is it from here? (Distance)________

    What direction?________________


The end l.jpg
THE END

  • Hold the Power button until the GPS turns off


Helpful hints l.jpg
Helpful Hints…

  • You can move the Click Stick up/down or left/right until the picture of several sheets of paper in the top right corner is highlighted and press strait in

  • This allows you to choose which page you want to go directly to instead of using the Page Button to cycle through all the pages


Helpful hints40 l.jpg
Helpful Hints…

  • Go to the Satellite page

  • Move the Click Stick up/down or left/right until the single sheet of paper in the top right corner is highlighted and press strait in

  • A screen will drop down

  • Choose Use With GPS Off

  • This will allow you to use the GPS unit without getting a signal

  • THIS SAVES BATTERIES and works great when you practice using the unit without needing a signal to get actual locations


Helpful hints41 l.jpg
Helpful Hints…

  • Check out www.geochaching.com

  • Geocaching is a fun way to practice using your GPS unit.

  • People all over the world have left GPS locations for their cache in hopes of you finding them!!!

    (I live in a town of 1200 people and there are 8 caches within 5 miles of my house)

  • Type in your zip code to find a cache that already exists or you can create your own for others to find!!!


Contact us with any questions l.jpg
Contact Us With Any Questions…

Krissy Vaux [email protected]

Mark McBride [email protected]

There is a link to this power point on our webpage:

http://www.tri-valley.k12.il.us/hs/classes/kvaux

Feel free to use it and manipulate it

for your own classroom use.
