  1. Cabinet Types To improve availability of a cabinet configuration that more closely matches a need, we plan to stock several different cabinet types as standard cabinets. We have detailed the different types in this presentation. We should have stock for these new ‘standards’ as of September. We are reviewing the possible addition of a “make to order” program for 2008.

  2. Cabinet Types Standard Insert Special Job Shop Production We plan to stock these configurations Special Configurations will be special ordered. For 2008, we are reviewing implementation of a local build to order program.

  3. 196 bins (48x56mm – 100mm deep) 10 packs (common size) STANDARD CABINET (461 bins) 8 Drawers – Master or Add-On 98 bins (48x56mm – 50mm deep) single insert, screws, hardware, misc small tools 49 bins (98x56mm – 50mm deep) Square Packs, Picco, extractors, small tools 7 bins (98x56 – 50mm deep) Square Packs, Picco, extractors, small tools 28 bins (148x56 – 50mm deep) medium length SCD/SCM 7 bins (98x56 – 50mm deep) Square Packs, Picco, extractors, small tools 21 bins (198x56 – 50mm deep) Longer tools D100-1 D100-1 7 bins (98x56 – 75mm deep) small tools, adaptor blades 28 bins (148x56 – 75mm deep) large insert packs, medium length SCD/SCM D50-1 D50-2 D50-3 2 bins 148x56 – 75mm deep medium length SCD/SCM 2 bins 198x56 – 75mm deep tool holders 8 bins 148x88 – 75mm deep tool holders, Indexable Drills & Endmills 8 bins 198x88 – 75mm deep CAT40 Adaptors, Larger Tooling D50-4 D75-3 D75-6

  4. INSERT CABINET (511 bins) 7 Drawers – Master or Add-On 98 bins (48x56mm – 50mm deep) single insert, screws, hardware, misc small tools D50-1 D50-2 49 bins (98x56mm – 50mm deep) Square Packs, Picco, extractors, small tools D100-1 294 bins (48x56mm – 100mm deep) 10 packs (common size) D100-1 14 bins (98x56 – 75mm deep) small tools, adaptor blades 56 bins (148x56 – 75mm deep) large insert packs, medium length SCD/SCM D100-1 D75-3 D75-3

  5. PRODUCTION CABINET (441 bins) 7 Drawers – Master Only 294 bins (48x56mm – 100mm deep) 10 packs (common size) 49 bins (98x56mm – 50mm deep) Square Packs, Picco, extractors, small tools D100-1 D100-1 14 bins (98x56 – 75mm deep) small tools, adaptor blades 56 bins (148x56 – 75mm deep) large insert packs, medium length SCD/SCM D100-1 D50-2 D75-3 7 bins (98x56 – 50mm deep) Square Packs, Picco, extractors, small tools 21 bins (198x56 – 50mm deep) Tool holders D75-3 D50-4

  6. 98 bins (48x56mm – 100mm deep) 10 packs (common size) JOB SHOP CABINET (384 bins) 8 Drawers – Master Only 49 bins (98x56mm – 50mm deep) Square Packs, Picco, extractors, small tools 98 bins (48x56mm – 50mm deep) single insert, screws, hardware, misc small tools 7 bins (98x56 – 50mm deep) Square Packs, Picco, extractors, small tools 28 bins (148x56 – 50mm deep) medium length SCD, SCM 7 bins (98x56 – 50mm deep) Square Packs, Picco, extractors, small tools 21 bins (198x56 – 50mm deep) Tool holders D50-1 7 bins (98x56 – 50mm deep) Square Packs, Picco, extractors, small tools 14 bins (248x56 – 50mm deep) very long SCD, indexable drills & end mills D100-1 7 bins (98x56 – 75mm deep) small tools, adaptor blades 28 bins (148x56 – 75mm deep) large insert packs, medium length SCD/SCM D50-2 D50-3 D50-4 D50-5 2 bins 148x56 – 75mm deep medium length SCD/SCM 2 bins 198x56 – 75mm deep tool holders 8 bins 148x88 – 75mm deep tool holders, indexable drills & end mills 8 bins 198x88 – 75mm deep CAT40 Adaptors, Larger Tooling D75-3 D75-6

  7. SPECIAL CABINET Delivery 18-20 weeks Assemble to custom specification based on customer requirement ?

  8. Special For the special cabinets, we are constrained only by the vertical height of total drawer space opening in the front of the cabinet. We can mix and match any drawer height/bin configuration provided we are within the total space height limitation. Total Vertical Drawer Space Opening Drawers come in 50, 75 and 100mm heights Drawers can have one of several bin combinations 100mm 50mm 75mm
