egate 100 channelized ethernet gateway product overview update version 2 60

Egate-100Channelized Ethernet Gateway Product Overview & Update(version 2.60)

Author: Shoval Bolotin,

PLM, Ethernet Access over PDH/SONET/SDH Solutions

shoval_b@rad.com

Updated: December 2007

general
General
  • Channelized Ethernet gateway for interconnecting packet networks via PDH/SDH/SONET access
  • Aggregates and switches Ethernet traffic to a single STM‑1/OC-3 port, or to three channelized T3 ports
  • Connects up to 84 remote LANs over E1/T1 or 60 bonded nxE1/T1 lines, or 126 remote LANs over fractional E1 or T1 lines
market problem profitable ethernet services over sdh sonet
Market Problem– Profitable Ethernet Services over SDH/SONET
  • Ethernet Services are relatively lower cost services
  • Native Ethernet does not reach all locations
  • SDH/PDH/SONET networks are widely available, and can be used to deliver carrier class Ethernet services
  • The challenge:
    • Carriers providing low cost Ethernet services over the available access networks, while maintaining profitability and generating new profits
    • Enterprises and Utilities can utilize the available SDH/SONET for new Ethernet based applications
    • Leasing low cost transmission from 3rd party in order to reach more customers - extend the reach of existing services
ethernet over pdh
Ethernet over PDH

Provider’s Node

Customer Premises

RICi-E1/T1

E1/T1

Ethernet

  • Remote solution - Different RICi models provide solution ranging from single E1/T1 to nxE1/T1
  • Centeral site solution – Egate terminating SDH into the PSN network
  • NxE1/T1 bonding based on MLPPP

Customer Premises

Egate-100

STM-1/OC-3

(APS)

3*DS3

RICi-4/8E1/T1

SDH/

SONET

GbE

PSN

Eth/IP/MPLS

N*E1/T1

Ethernet

PSN

Customer Premises

RICi-E1/T1

Ethernet

FE1/FT1

Customer Premises

RICi-4/8E1/T1

N*E1/T1

Ethernet

main value preposition
Main Value Preposition
  • Complete solution with RAD’s CLEs (RICi-nXE1/T1, FCD)
  • Reduces equipment costs compared to alternative solutions (Single box solution)
  • Reduces operation costs:
    • Flexible service provisioning: 64kbps to n*E1/T1
    • One management system
    • Ethernet diagnostics and monitoring
    • Lower space (1U) and power requirements
  • VLAN stacking/stripping at customer Edge or provider Edge:
    • Ensures transparency to customer LAN settings
    • Secured separation of customer and management traffic
  • QoS based on user VLAN Priority (802.1p), DSCP and IP Precedence marking:
    • Enables differentiated services according to Ethernet or IP marking
ip dslam wimax backhauling over pdh sonet sdh

Subscribers

POP 1

RICi-4/8

E1/T1

IP DSLAM

n x E1/T1

Ethernet

xDSL

POP 2

WiMAX

RICi-

E1/T1

SDH/

SONET

POP

STM-1/OC-3 (APS)

3*DS3

Egate-100

Ethernet

GbE

E1/T1

IP DSLAM & WiMAX Backhauling over PDH/SONET/SDH

Subscribers

IP DSLAM

xDSL

Internet

Metro

Ethernet

  • Generate new revenues by:
    • Expanding customer base
    • Offering new services on existing infrastructure
  • A variety of bandwidths offered to the customer
  • Simple Layer 2 technology
ethernet service over sdh sonet on net

TLS

TLS

TLS

TLS

Internet

Internet

Internet

Internet

VoIP

VoIP

VoIP

VoIP

Internet Traffic

FE/GE

TLS Traffic

Branch D

TLS Traffic

ETX

Ethernet Service over SDH/SONET“on-net”

Branch A

WWW

RICi-8

  • Switching is done by the Egate-100

Headquarters

8 x E1/T1

Branch B

CH.STM-1/OC-3c

(APS)

or 3 x DS-3

Egate-100

RICi-16

PSN

ETH/IP/MPLS

GE

16 x E1/T1

SDH/SONET

Branch C

RICi-4

4 x E1/T1

  • Secured traffic separation using VLANs
  • Different services can be provided with different QoS
  • Headquarters and branches connected as if on the same LAN
out of footprint ethernet connectivity
Out-of-Footprint Ethernet Connectivity

POP

Customer Premises

Customer Premises

CH.STM-1/OC-3c

(APS)

or 3 x DS-3

n x E1/T1

Bonding

PSN

ETH/IP/MPLS

Network

SDH/

SONET

GbE

FE

FE/GbE

  • Alternative carriers increasing service reach with leased lines
  • End-to-end service control and SLA measurements using Ethernet service OAM
  • Different services over a single line
  • Rate versatility – from E1/T1 to to STM-4/OC-12
  • Bonding solution – 16 x E1/T1 to bridge the bandwidth gap between E1/T1 and E3/T3

Egate-100

RICi-4

RICi-8

RICi-16

ETX-102/

ETX-201/

ETX-202

LAN

LAN

Transport Provider

Service Provider

remote management
Remote Management

Remote Site

RICi-E1/T1

CPE

  • Using widely deployed SDH/SONET infrastructure to provide management services
  • Reduced OPEX by managing remote devices when in-band management is not available
  • Low cost, small footprint

E1/T1

FE

Headquarters

Remote Site

Egate-100

CH.STM-1/OC-3c

(APS)

or 3 x DS-3

RICi-E1/T1

CPE

Service

Network

SDH/

SONET

GbE

E1/T1

FE

PSN

Remote Site

Management

Station

RICi-E1/T1

CPE

E1/T1

FE

main additional features
Main Additional Features
  • GbE redundancy –link aggregation protocol 802.3ad
  • Support of up to 60 remote LANs over bonded n  E1/T1 lines-(previous versions supported up to 42)
  • Split Horizon
  • Management Features:
    • User defined access authorization
    • Management access control
    • SYSLOG (RFC 3164)
gbe redundancy
GbE redundancy
  • Link Aggregation (802.3ad) compliant
  • Two GbE ports can be used as a single aggregated port upon configuration
  • The link aggregation standard provides inherent, automatic redundancy on point-to-point links. In case of a link fail, network traffic is dynamically redirected to flow across the second GbE link
  • The link aggregation adds robustness to the system
    • Connection is maintained and the data flow is not interrupted in spite of a single link fail
split horizon
Split horizon
  • Support DSLAM aggregation application for Internet services
  • Prevents local switching between remotes sites, to avoid network congestion
  • two operation modes:
    • Full: local switching between logical ports is disabled for all VLANs
    • Per VLAN: disable local switching for certain VLANs and allow local switching for other VLANs
slide15

CPE

CPE

CPE

CPE

CPE

CPE

DSL

DSL

DSL

DSL

DSL

DSL

IP-DSLAM

IP-DSLAM

IP-DSLAM

IP-DSLAM

IP-DSLAM

IP-DSLAM

N x T1

RIC

CPE

CPE

CPE

CPE

CPE

CPE

ETH

DSL

DSL

DSL

DSL

DSL

DSL

Broadcast

Broadcast

VLAN A

VLAN A

CPE

CPE

CPE

CPE

CPE

CPE

IP/Eth Network

DSL

DSL

DSL

DSL

DSL

DSL

VLAN A

VLAN A

BRAS

Broadcast

Broadcast

GBE

N x T1

RIC

Broadcast

SDH/SONETNetwork

ETH

Egate-100

Broadcast

VLAN A

VLAN A

Split Horizon

N x T1

RIC

Broadcast

ETH

VLAN A

VLAN A

Split Horizon

N x T1

RIC

ETH

IP/Eth Network

BRAS

GBE

N x T1

RIC

SDH/SONETNetwork

ETH

Egate-100

N x T1

RIC

ETH

management features
Management Features
  • User defined access authorization:
    • Authorized user can define:
      • 'Login name' and 'Password'
      • Different authorization levels for different users
  • Log file records login of each user name
  • Management access control
    • only allowed stations can access the device
  • SYSLOG
    • Forwarding device alarms and events according to pre-defined criteria to the network
product overview
Product Overview
  • Two CH-STM1/OC-3 optical interfaces:
    • SFP pluggable interface
    • 1+1 APS
  • Three channelized T3 ports
    • BNC
  • Two GbE, optical or electrical interface:
    • SFP pluggable interface for optical interfaces
    • Electrical 10/100/1000BaseT
    • GbE port redundancy (link aggregation- per 802.3ad)
    • One can be used for OOB management
  • Fully managed:
    • SYSLOG - RFC3164
    • Configuration and fault management (active alarms,traps, log file).
    • WEB, Telnet, RAD's RVlite management
  • DB9 for control
  • 1U 19” box
  • Two power supplies (AC/DC), hot swappable
bridge features
Bridge Features
  • Bridging function between Ethernet over PDH remotes and GbE.
  • Host is an internal bridge port for inband management
  • Up to 128 ports
  • Bridge modes:
    • VLAN unaware mode
    • Full VLAN aware mode
  • Per port optional tag stacking/Double tagging ( 802.1q tunneling or Q in Q)
  • Support for 64,000 MACs and 1024 VLANs
  • Per port ingress filtering Enable/Disable
  • Per port egress tag/untag
  • Per port MAC learning limitation
management
Management
  • In band management
  • Out of band management
  • SNMP fault management
  • Management options
    • RADview Lite SNMP Network fault management
    • Telnet, Web browser
    • Terminal
  • Local management via craft port (RS-232)
  • Remote software and configuration download
slide21
QoS
  • Enables support for high priority and delay sensitive applications
  • Four strict priority queues
  • Priority mapping according to one of the following:
    • VLAN priority tag. Original priority is duplicated to outer VLAN
    • IP precedence field (ToS)
    • IP DSCP (Tos)
  • Priority setting per the entire bridge
security
Security
  • SSL/SSH coding of management traffic
  • RADIUS Password authentication
  • Preventing access from/to management station via user port
  • Management traffic can be blocked from user port (Dedicated VLAN channel and filter)
  • Manager access control list:
    • Only specific IP addresses will be allowed to manage the device; up to 10 managers can be defined
  • Read/ Write Communities mechanism:
    • Define specific communities authorized for Read/Write actions
  • Hard coded user names:
    • Super user can define up 16 Users with authorization of read only or read/write
thank you
Thank You

Shoval Bolotin,

PLM, Ethernet Access over PDH/SONET/SDH Solutions

shoval_b@rad.com

www.rad.com
