Tree Topology Network is a combination of the bus and the Star Network

Tree Topology Network is a combination of the bus and the Star Network. More than one-star networks can be connected together using a bus network. Different branches, as it is what the star networks look like in a Tree Topology Network, are connected on a bus network at different points on a specific distance and this bus network channel resembles the root of a tree.<br>

thenationaltv
Download Presentation

Tree Topology Network is a combination of the bus and the Star Network

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. TECH Tree Topology Network is a combination of the bus and the Star Network   BY SANJEEV- SEP 05, 2019 14:54 

  2. Tree Topology Network is a combination of the bus and the Star Network. More than one-star networks can be connected together using a bus network. Different branches, as it is what the star networks look like in a Tree Topology Network, are connected on a bus network at different points on a specific distance and this bus network channel resembles the root of a tree. Because it’s a combination of star and bus networks, a tree network is often called Star Bus Typology. It is used most of the time when scalability or hierarchal communication is needed. Advantages: 1. In the networks, if neither of the star and bus topologies can be implemented, tree topology is the best alternative that remains. 2. Extension of the network is easy as the whole readymade branches can be attached to the main cable channel that is bus network. It is specially designed for the expansion of the network. 3. Not only in the appearance but the branches of the tree network is divided into the functionality as well. Each of the segments or branches can be managed separately. 4. Because of the divided roles, responsibilities and functions, error detection and is easy and the issue can be resolved easily without much implication. 5. Each of these branches is connected with the base cable channel with a separate point to point wiring which means the damage to one branch will not affect the functioning of the other branches. Disadvantages: 1. Even though one branch cannot harm the other, the network still relies entirely ok on the main bus cable channel which is called the hub. In case the hub breaks down, the entire system can come crashing down to pieces. 2. Maintenance cost increases with the number of nodes or branches as long networks and wires are added with each of the addition.

  3. 3. Tree Topology Network is difficult to put together given how complicated and wide is its’ structure. 4. Despite being designed for an extended network with the purpose of expanding it more, it has a hard and long procedure if you wish to add more branches or nodes in an already set up Tree Network. 5. Last but not the least and perhaps the biggest advantage of this network is the simple fact that it is a combination of two other networks, which also makes it unique. Talking about example , Tree topology is used in the building where the hub is installed vertically and branches are spread each on a floor. TAGS:TREE TOPOLOGYNEWSSTAR NETWORKNEWS
