Presentation Transcript
Introduction to the arcgis pipeline data model apdm version 4 0 l.jpg

Introduction to the ArcGIS Pipeline Data Model (APDM)Version 4.0

Peter Veenstra

ESRI Petroleum User Group Conference - 2006


Introduction l.jpg
Introduction

Presentation about …

  • Introduction to the APDM

  • Overview of APDM Version 4.0


Arcgis pipeline data model apdm l.jpg
ArcGIS Pipeline Data Model (APDM)

Who: Industry consortium of ESRI, pipeline vendors and operators

PUG  PIG  Steering Committee, Technical Committee

What:Geodatabase model for transmission pipelines

Where:www.apdm.net

When: PUG, ESRI User Conference, GITA Oil & Gas

Why: Passionate about ESRI technology


Overview of the apdm l.jpg
Overview of the APDM

  • ESRI Geodatabase model for …

    • gas and/or liquids, onshore/offshore, gathering, transmission, or distribution pipeline systems

    • Focused on pipelines that use stationed position AND XY coordinates to locate positions of features on or along the pipeline

  • APDM  ESRI Object Model Template to handle …

    • multiple forms of linear referencing

      • ESRI route and measure technology

    • hierarchical/geographical organization of pipeline features

    • Feature behavior during centerline editing operations

    • Links to external systems – ERP, Document Management, Work Order MS

  • Core Feature\Object Classes

  • Abstract Classes


  • Overview of the model l.jpg
    Overview of the Model

    • APDM is the intellectual property of ESRI

      • Managed in trust by the Pipe Interest Group (Petroleum User Group)

    • Version 1.0 Build the model

      • Focus on the technology, the core and conceptual classes in the model.

  • Version 2.0 – 3.0 Link to the Enterprise

    • Refine the conceptual model, expand the core

      • Activities, External Documents, OwnerOperator, EventID

  • Version 4.0 Metadata

    • Data content

    • Schema Description and Management

    • Object behavior

    • Best Practices  Interoperability


  • Apdm steering and technical committees l.jpg
    APDM Steering and Technical Committees

    • APDM 4.0 Steering Committee

      ·Robert Brook, New Century Software, rob.brook@newcenturysoftware.com

      ·Chris Elmer, Sempra Utilities, celmer@semprautilities.com

      ·Greg McCool, Enbridge Energy Company, greg.mccool@enbridge.com

      ·David Nemeth, Panhandle Energy, dbnemeth@panhandleenergy.com

      ·Debra Rohrer, Columbia Gas, drohrer@nisource.com

      ·Mark Warner, Questar Pipeline, mark.warner@questar.com

      ·Edward Wiegele, GE Energy, edward.wiegele@ge.com

      ·Craig Wilder (Chairperson), El Paso Corporation, craig.wilder@elpaso.com

      ·Chad Zamarin, Colonial Gas, CZamarin@colpipe.com

      ·Andrew Zolnai, ESRI, azolnai@esri.com

      ·David Frye, ESRI, dfrye@esri.com

    • APDM 4.0 Technical Committee

    • ·John Alsup, ESRI, jalsup@esri.com

    • · Jannette Jensen, Questar Gas Company (Secretary), jannette.jensen@questar.com

    • ·Theo Lawrence, Great Lakes Gas Transmission, tblawrence@glgt.com

    • ·Todd Murphy, Panhandle Energy Corporation, temurphy@panhandleenergy.com

    • ·Buddy Nagel, El Paso Corporation, buddy.nagel@elpaso.com

    • ·Jeff Puuri, Advantica, Jeff.Puuri@Advantica.biz

    • ·Fred Spickler, Photoscience Inc, fspickler@photoscience.com

    • ·Tracy Thorleifson, Eagle Information Mapping, jtt@eaglemap.com

    • ·Peter Veenstra, GE Energy (Chairperson), peter.veenstra@ge.com


    Apdm version 4 0 l.jpg
    APDM Version 4.0

    • Abstract Classes (Core Attributes and Relationships)

      • Centerline Objects, Facility Objects, Online/Offline Objects

      • Response to editing the centerline

      • Auditing feature/object edits

  • Core Classes

    • ControlPoint, StationSeries, AltRefMeasure, Lineloop, Subsystem, SubsystemHierarchy, LineloopHierarchy, Product, OwnerOperator, SubsystemRange, Site, Activity, ActivityHierarchy, ExternalDocument

  • Metadata Classes

    • Formal definition to describe behavior of reference modes

      • Units, Basis, Type

    • Listing and APDM categorization of classes within geodatabase

      • Each class in the APDM will inherit from one of the APDM Abstract Classes

    • Online Locations for Offline Features

      • Listing of offline/online class pairs

      • Listing of calculation methods for determining derivation of online locations

  • Inline History and Auditing

  • Facilities and Non-Geometric representation of features


  • Arcgis pipeline data model apdm8 l.jpg
    ArcGIS Pipeline Data Model (APDM)

    • APDM Logical Model Poster – shows abstract classes, metadata classes, core classes and example concrete classes



    Abstract classes10 l.jpg
    Abstract Classes

    • Object based abstract classes showing centerline objects, facility objects and non-facility objects


    Abstract classes11 l.jpg
    Abstract Classes

    • Feature based abstract classes showing centerline objects, online/offline objects, facility objects and ‘online’ location objects


    Abstract classes inheritance l.jpg
    Abstract Classes- Inheritance

    • Example showing how a ‘concrete’ class is derived via inheritance from the APDM abstract classes


    Core classes l.jpg
    Core Classes

    • Represent the core classes within the model that must be implemented

    • These classes represent critical parts of a pipeline reflecting centerline editing and integration with other enterprise systems

      • ControlPoint – known points of XY and station value location for a given reference mode

      • StationSeries – a route feature built from control point for a given reference mode

      • AltRefMeasure – stores alternate reference mode information for online features

      • Lineloop – a series of connected station series forming a ‘line’ or ‘route’

      • LineloopHierarchy – ability to categorize lineloops into logical groupings

      • Subsystem – an area or zone along the pipeline used to break it up into logical regions

      • SubsystemHierarchy – ability to categorize subsystems into logical groupings

      • SubsystemRange – the ‘online’ location of a subsystem along the centerline

      • Product – the product transported by the pipeline

      • OwnerOperator – owner and operator information for the assets of a pipeline

      • Site – any site boundary on or along the pipeline

      • Activity – things that ‘happen’ during the operation and maintenance of a pipeline

      • ActivityHierarchy – ability to categorize activities into logical groupings

      • ExternalDocument – reports, regulatory and source documents that specifiy or document assets and events on or along the pipeline


    Metadata classes l.jpg
    Metadata Classes

    • Describes the internal structure of the model for validation and verification


    Implementing apdm l.jpg
    Implementing APDM

    • APDM is built for the geodatabase

      • It is an object model

      • It describes feature editing behavior

      • It provides meta-data or meta-models that can be integrated with other data models

      • APDM Core  APDM Tables  Add/modify classes and attributes

      • APDM Core  PODS Business/Feature/Event Tables  Add/modify classes and attributes

      • APDM Core  ISAT Business/Feature/Event Tables  Add/modify classes and attributes

      • APDM Core  Any pipeline data model business tables …  Add /modify classes and attributes

      • Implement APDM Abstract Tables and Core Tables


    Compliance and interoperability l.jpg
    Compliance and Interoperability

    • The purpose of APDM is to capture the ‘behavior’ of pipeline events, features and objects within an geodatabase object model

    • The purpose of APDM 4.0 abstract, metadata and core classes is to provide a standard for judging APDM compliance to allow true interoperability between vendor applications and data models

    • Interoperability could be assessed by development of a standard set of editing, reporting and analysis applications that could be applied to any APDM geodatabase


    Current status of the apdm l.jpg
    Current Status of the APDM

    • Yearly cycle

      • Accrual of ideas and feedback – ESRI UC  Gita Oil & Gas (Summer to Fall)

      • Technical Committee develop new aspects of model (Fall through Winter  ESRI PUG)

      • Model Release (Spring  ESRI UC)

  • Planned Events

    • APDM Pre-Conference Workshop – Saturday, August 12th

    • http://www.esri.com/events/uc/sessions/uc_precons.html

  • Scheduled release of proposed changes (V4.0)

    • Logical Model Poster, Physical Model UML (Visio 2002 format) available from www.apdm.net/downloads.htm

    • White paper will be released in sections over the next 2-3 weeks for review up until 05/2006


  • Contact information l.jpg
    Contact Information

    • Online Resources (APDM)

      • www.apdm.net

        • APDM Model and white paper, UML, XMI, logical model

      • www.esri.com\datamodels

    • APDM Technical and Steering Committees

      • Andrew Zolnai azolnai@esri.com

      • Craig Wilder craig.wilder@elpaso.com

      • Peter Veenstra peter.veenstra@og.ge.com
