structural and behavioral design style registers counters and testbenches

Structural and Behavioral Design StyleRegisters, Counters, and Testbenches

ECE 449 – Computer Design Lab

resources
Resources
  • Sundar Rajan, Essential VHDL: RTL Synthesis
  • Done Right
  • Chapter 4, Registers and Latches
  • Chapter 5, Counters and Simple
  • Arithmetic Functions
  • Stephen Brown and Zvonko Vranesic,
  • Fundamentals of Digital Logic with VHDL
  • Chapter 7, Flip-flops, Registers, Counters,
  • and a Simple Processor

ECE 449 – Computer Design Lab

slide3

Structural Design Style

ECE 449 – Computer Design Lab

slide4

Structural VHDL

Major instructions

  • component instantiation (port map)
  • generate scheme for component instantiations
  • (for-generate)
  • component instantiation with generic
  • (generic map, port map)

ECE 449 – Computer Design Lab

slide5

Structural VHDL

Major instructions

  • component instantiation (port map)
  • generate scheme for component instantiations
  • (for-generate)
  • component instantiation with generic
  • (generic map, port map)

ECE 449 – Computer Design Lab

structural example
Structural Example:

in1

nand_out

in2

in1

Component NAND2 Instantiated Four Time

ECE 449 – Computer Design Lab

slide7

Structural VHDL

Major instructions

  • component instantiation (port map)
  • generate scheme for component instantiations
  • (for-generate)
  • component instantiation with generic
  • (generic map, port map)

ECE 449 – Computer Design Lab

generate example block diagram
Generate Example Block Diagram

xor_tmp(0)

xor_tmp(1)

xor_tmp(2)

xor_tmp(3)

xor_tmp(4)

xor_tmp(5)

xor_tmp(6)

xor_tmp(7)

ECE 449 – Computer Design Lab

slide9

Architecture with for-generate

architecture STRUCTURE of PARITY is

component XOR2

port(

A : in STD_LOGIC;

B : in STD_LOGIC;

Y : out STD_LOGIC

);

end component;

signal xor_tmp: std_logic_vector (0 to 7);

begin

xor_tmp(0) <= parity_in(0);

G: for i in 0 to 6 generate

C: XOR2 port map(A=>xor_tmp(i),

B=>parity_in(i+1),

Y=>xor_tmp(i+1));

end generate;

parity_out <= xor_tmp(7);

end STRUCTURE;

ECE 449 – Computer Design Lab

slide10

Structural VHDL

Major instructions

  • component instantiation (port map)
  • generate scheme for component instantiations
  • (for-generate)
  • component instantiation with generic
  • (generic map, port map)

ECE 449 – Computer Design Lab

n bit parity generator entity declaration
N-bit Parity Generator – Entity declaration

entity PARITY is

generic(N: positive);

port(

parity_in : in STD_LOGIC_VECTOR(N-1 downto 0);

parity_out : out STD_LOGIC

);

end PARITY;

ECE 449 – Computer Design Lab

n bit parity generator architecture
N-bit Parity Generator – Architecture

architecture STRUCTURE of PARITY is

component XOR2

port(

A : in STD_LOGIC;

B : in STD_LOGIC;

Y : out STD_LOGIC

);

end component;

signal xor_tmp: std_logic_vector (0 to N-1);

begin

xor_tmp(0) <= parity_in(0);

G: for i in 0 to N-2 generate

C: XOR2 port map(A=>xor_tmp(i),

B=>parity_in(i+1),

Y=>xor_tmp(i+1));

end generate;

parity_out <= xor_tmp(N-1);

end STRUCTURE;

ECE 449 – Computer Design Lab

slide13

Behavioral Design Style

ECE 449 – Computer Design Lab

slide14

Behavioral VHDL (subset)

Major instructions

Sequential statements

General

  • process statement (process)
  • sequential signal assignment ()

Registers, counters, shift registers, etc.

  • if-then-else statement

State machines

  • case-when statement

Testbenches

  • loops (for-loop, while-loop)

ECE 449 – Computer Design Lab

anatomy of a process
Anatomy of a Process

OPTIONAL

[label:] process[(sensitivity list)]

[declaration part]

begin

statement part

end process;

ECE 449 – Computer Design Lab

what is a process
What is a PROCESS?
  • A process is a sequence of instructions referred to as sequential statements.

The Keyword PROCESS

  • A process can be given a unique name using an optional LABEL
  • This is followed by the keyword PROCESS
  • The keyword BEGIN is used to indicate the start of the process
  • All statements within the process are executed SEQUENTIALLY. Hence, order of statements is important.
  • A process must end with the keywords END PROCESS.

TESTING: process

begin

TEST_VECTOR<=“00”;

wait for 10 ns;

TEST_VECTOR<=“01”;

wait for 10 ns;

TEST_VECTOR<=“10”;

wait for 10 ns;

TEST_VECTOR<=“11”;

wait for 10 ns;

end process;

ECE 449 – Computer Design Lab

process with a sensitivity list
List of signals to which the process is sensitive.

Whenever there is an event on any of the signals in the sensitivity list, the process fires.

Every time the process fires, it will run in its entirety.

WAIT statements NOT ALLOWED in a processes with SENSITIVITY LIST.

label: process (sensitivity list)

declaration part

begin

statement part

end process;

PROCESS with a SENSITIVITY LIST

ECE 449 – Computer Design Lab

processes in vhdl
Processes in VHDL
  • Processes Describe Sequential Behavior
  • Processes in VHDL Are Very Powerful Statements
    • Allow to define an arbitrary behavior that may be difficult to represent by a real circuit
    • Not every process can be synthesized
  • Use Processes with Caution in the Code to Be Synthesized
  • Use Processes Freely in Testbenches

ECE 449 – Computer Design Lab

slide19

Use of Processes

in the Synthesizable Code

ECE 449 – Computer Design Lab

component equivalent of a process
All signals which appear on the left of signal assignment statement (<=) are outputs e.g. y, z

All signals which appear on the right of signal assignment statement (<=) or in logic expressions are inputse.g. w, a, b, c

All signals which appear in the sensitivity list are inputs e.g. clk

Note that not all inputs need to be in the sensitivity list

Component Equivalent of a Process

clk

y

w

priority

a

z

b

c

priority: PROCESS (clk)

BEGIN

IF w(3) = '1' THEN

y <= "11" ;

ELSIF w(2) = '1' THEN

y <= "10" ;

ELSIF w(1) = c THEN

y <= a and b;

ELSE

z <= "00" ;

END IF ;

END PROCESS ;

ECE 449 – Computer Design Lab

slide21

Registers

ECE 449 – Computer Design Lab

slide22

Q

D

Clock

D latch

Truth table

Graphical symbol

Q(t+1)

Clock

D

Q(t)

0

0

1

0

1

1

1

Timing diagram

t

t

t

t

1

2

3

4

Clock

D

Q

Time

ECE 449 – Computer Design Lab

slide23

Q

D

Clock

D flip-flop

Truth table

Graphical symbol

Q(t+1)

Clk

D

0

0

1

1

Q(t)

0

Q(t)

1

Timing diagram

t

t

t

t

1

2

3

4

Clock

D

Q

Time

ECE 449 – Computer Design Lab

slide24

Q

D

Clock

D latch

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY latch IS

PORT ( D, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC) ;

END latch ;

ARCHITECTURE Behavior OF latch IS

BEGIN

PROCESS ( D, Clock )

BEGIN

IF Clock = '1' THEN

Q <= D ;

END IF ;

END PROCESS ;

END Behavior;

ECE 449 – Computer Design Lab

slide25

D flip-flop

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY flipflop IS

PORT ( D, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC) ;

END flipflop ;

ARCHITECTURE Behavior_1 OF flipflop IS

BEGIN

PROCESS ( Clock )

BEGIN

IF Clock'EVENT AND Clock = '1' THEN

Q <= D ;

END IF ;

END PROCESS ;

END Behavior_1 ;

Q

D

Clock

ECE 449 – Computer Design Lab

slide26

D flip-flop

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY flipflop IS

PORT ( D, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC) ;

END flipflop ;

ARCHITECTURE Behavior_2 OF flipflop IS

BEGIN

PROCESS

BEGIN

WAIT UNTIL Clock'EVENT AND Clock = '1' ;

Q <= D ;

END PROCESS ;

END Behavior_2 ;

Q

D

Clock

ECE 449 – Computer Design Lab

slide27

D flip-flop with asynchronous reset

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY flipflop IS

PORT ( D, Resetn, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC) ;

END flipflop ;

ARCHITECTURE Behavior OF flipflop IS

BEGIN

PROCESS ( Resetn, Clock )

BEGIN

IF Resetn = '0' THEN

Q <= '0' ;

ELSIF Clock'EVENT AND Clock = '1' THEN

Q <= D ;

END IF ;

END PROCESS ;

END Behavior ;

Q

D

Clock

Resetn

ECE 449 – Computer Design Lab

slide28

D flip-flop with synchronous reset

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY flipflop IS

PORT ( D, Resetn, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC) ;

END flipflop ;

ARCHITECTURE Behavior OF flipflop IS

BEGIN

PROCESS

BEGIN

WAIT UNTIL Clock'EVENT AND Clock = '1' ;

IF Resetn = '0' THEN

Q <= '0' ;

ELSE

Q <= D ;

END IF ;

END PROCESS ;

END Behavior ;

Q

D

Clock

Resetn

ECE 449 – Computer Design Lab

slide29

8

8

Resetn

D

Q

Clock

reg8

8-bit register with asynchronous reset

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY reg8 IS

PORT ( D : IN STD_LOGIC_VECTOR(7 DOWNTO 0) ;

Resetn, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC_VECTOR(7 DOWNTO 0) ) ;

END reg8 ;

ARCHITECTURE Behavior OF reg8 IS

BEGIN

PROCESS ( Resetn, Clock )

BEGIN

IF Resetn = '0' THEN

Q <= "00000000" ;

ELSIF Clock'EVENT AND Clock = '1' THEN

Q <= D ;

END IF ;

END PROCESS ;

END Behavior ;`

ECE 449 – Computer Design Lab

slide30

N

N

Resetn

D

Q

Clock

regn

N-bit register with asynchronous reset

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY regn IS

GENERIC ( N : INTEGER := 16 ) ;

PORT ( D : IN STD_LOGIC_VECTOR(N-1 DOWNTO 0) ;

Resetn, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC_VECTOR(N-1 DOWNTO 0) ) ;

END regn ;

ARCHITECTURE Behavior OF regn IS

BEGIN

PROCESS ( Resetn, Clock )

BEGIN

IF Resetn = '0' THEN

Q <= (OTHERS => '0') ;

ELSIF Clock'EVENT AND Clock = '1' THEN

Q <= D ;

END IF ;

END PROCESS ;

END Behavior ;

ECE 449 – Computer Design Lab

slide31

N

N

N-bit register with enable

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY regn IS

GENERIC ( N : INTEGER := 8 ) ;

PORT ( D : IN STD_LOGIC_VECTOR(N-1 DOWNTO 0) ;

Enable, Clock : IN STD_LOGIC ;

Q : OUT STD_LOGIC_VECTOR(N-1 DOWNTO 0) ) ;

END regn ;

ARCHITECTURE Behavior OF regn IS

BEGIN

PROCESS (Clock)

BEGIN

IF (Clock'EVENT AND Clock = '1' ) THEN

IF Enable = '1' THEN

Q <= D ;

END IF ;

END IF;

END PROCESS ;

END Behavior ;

Enable

Q

D

Clock

regn

ECE 449 – Computer Design Lab

slide32

Counters

ECE 449 – Computer Design Lab

slide33

2

Clear

Q

upcount

Clock

2-bit up-counter with synchronous reset

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

USE ieee.std_logic_unsigned.all ;

ENTITY upcount IS

PORT ( Clear, Clock : IN STD_LOGIC ;

Q : BUFFER STD_LOGIC_VECTOR(1 DOWNTO 0) ) ;

END upcount ;

ARCHITECTURE Behavior OF upcount IS

BEGIN

upcount: PROCESS ( Clock )

BEGIN

IF (Clock'EVENT AND Clock = '1') THEN

IF Clear = '1' THEN

Q <= "00" ;

ELSE

Q <= Q + “01” ;

END IF ;

END IF;

END PROCESS;

END Behavior ;

ECE 449 – Computer Design Lab

slide34

Enable

4

Q

Clock

upcount

Resetn

4-bit up-counter with asynchronous reset (1)

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

USE ieee.std_logic_unsigned.all ;

ENTITY upcount IS

PORT ( Clock, Resetn, Enable : IN STD_LOGIC ;

Q : OUT STD_LOGIC_VECTOR (3 DOWNTO 0)) ;

END upcount ;

ECE 449 – Computer Design Lab

slide35

Enable

4

Q

Clock

upcount

Resetn

4-bit up-counter with asynchronous reset (2)

ARCHITECTURE Behavior OF upcount IS

SIGNAL Count : STD_LOGIC_VECTOR (3 DOWNTO 0) ;

BEGIN

PROCESS ( Clock, Resetn )

BEGIN

IF Resetn = '0' THEN

Count <= "0000" ;

ELSIF (Clock'EVENT AND Clock = '1') THEN

IF Enable = '1' THEN

Count <= Count + 1 ;

END IF ;

END IF ;

END PROCESS ;

Q <= Count ;

END Behavior ;

ECE 449 – Computer Design Lab

slide36

Shift Registers

ECE 449 – Computer Design Lab

shift register
Shift register

D

D

D

D

Q

Q

Q

Q

Q(1)

Q(0)

Q(2)

Q(3)

Sin

Clock

Enable

ECE 449 – Computer Design Lab

shift register with parallel load
Shift Register With Parallel Load

D(0)

D

D

D

D

Q

Q

Q

Q

Load

D(3)

D(1)

D(2)

Sin

Clock

Enable

Q(3)

Q(2)

Q(1)

Q(0)

ECE 449 – Computer Design Lab

slide39

4

4

Enable

D

Q

Load

Sin

shift4

Clock

4-bit shift register with parallel load (1)

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY shift4 IS

PORT ( D : IN STD_LOGIC_VECTOR(3 DOWNTO 0) ;

Enable : IN STD_LOGIC ;

Load : IN STD_LOGIC ;

Sin : IN STD_LOGIC ;

Clock : IN STD_LOGIC ;

Q : BUFFER STD_LOGIC_VECTOR(3 DOWNTO 0) ) ;

END shift4 ;

ECE 449 – Computer Design Lab

slide40

4

4

Enable

D

Q

Load

Sin

shift4

Clock

4-bit shift register with parallel load (2)

ARCHITECTURE Behavior_1 OF shift4 IS

BEGIN

PROCESS (Clock)

BEGIN

IF Clock'EVENT AND Clock = '1' THEN

IF Load = '1' THEN

Q <= D ;

ELSIF Enable = ‘1’ THEN

Q(0) <= Q(1) ;

Q(1) <= Q(2);

Q(2) <= Q(3) ;

Q(3) <= Sin;

END IF ;

END IF ;

END PROCESS ;

END Behavior_1 ;

ECE 449 – Computer Design Lab

slide41

4

4

Enable

D

Q

Load

Sin

shift4

Clock

4-bit shift register with parallel load (3)

ARCHITECTURE Behavior_2 OF shift4 IS

BEGIN

PROCESS

BEGIN

WAIT UNTIL Clock'EVENT AND Clock = '1' ;

IF Load = '1' THEN

Q <= D ;

ELSIF Enable = ‘1’ THEN

Q(3) <= Sin;

Q(2) <= Q(3) ;

Q(1) <= Q(2);

Q(0) <= Q(1) ;

END IF ;

END PROCESS ;

END Behavior_2 ;

Incorrect!!!

ECE 449 – Computer Design Lab

slide42

Enable

N

N

D

Q

Load

Sin

shiftn

Clock

N-bit shift register with parallel load (1)

LIBRARY ieee ;

USE ieee.std_logic_1164.all ;

ENTITY shiftn IS

GENERIC ( N : INTEGER := 8 ) ;

PORT ( D : IN STD_LOGIC_VECTOR(N-1 DOWNTO 0) ;

Enable : IN STD_LOGIC ;

Load : IN STD_LOGIC ;

Sin : IN STD_LOGIC ;

Clock : IN STD_LOGIC ;

Q : BUFFER STD_LOGIC_VECTOR(N-1 DOWNTO 0) ) ;

END shiftn ;

ECE 449 – Computer Design Lab

slide43

Enable

N

N

D

Q

Load

Sin

shiftn

Clock

N-bit shift register with parallel load (2)

ARCHITECTURE Behavior OF shiftn IS

BEGIN

PROCESS (Clock)

BEGIN

IF (Clock'EVENT AND Clock = '1' ) THEN

IF Load = '1' THEN

Q <= D ;

ELSIF Enable = ‘1’ THEN

Genbits: FOR i IN 0 TO N-2 LOOP

Q(i) <= Q(i+1) ;

END LOOP ;

Q(N-1) <= Sin ;

END IF;

END IF ;

END PROCESS ;

END Behavior ;

ECE 449 – Computer Design Lab

slide44

Input Stimuli Sources in

Testbenches

ECE 449 – Computer Design Lab

testbench block diagram
Testbench Block Diagram

Design Under Test (DUT)

Rule of Thumb: Usually ports from DUT entities are declared as signals within testbench

Testbench Environment

Stimuli All DUT Inputs

Sources of

Input

Stimuli

Simulated Outputs

ECE 449 – Computer Design Lab

testbench anatomy
Testbench Anatomy

Entity TB is

--TB entity has no ports

End TB;

Architecture arch_TB of TB is

--Local signals and constants

component TestComp --All Design Under Test component declarations

port ( );

endcomponent;

-----------------------------------------------------

for DUT:TestComp useentitywork.TestComp(archName)--Specify entity/arch pair

-- (OPTIONAL)

begin

testSequence: Process

--Main test process

end process;

DUT:TestComp portmap( --Port map all the DUTs

);

End arch_TB;

ECE 449 – Computer Design Lab

execution of statements in a process
All processes without a sensitivity list fire at least once when the code is simulated.

When the process fires, the first statement after the keyword BEGIN is executed.

The execution of statements continues sequentially till the last statement in the process.

After execution of the last statement, the control is again passed to the beginning of the process.

TESTING: process

begin

TEST_VECTOR<=“00”;

wait for 10 ns;

TEST_VECTOR<=“01”;

wait for 10 ns;

TEST_VECTOR<=“10”;

wait for 10 ns;

TEST_VECTOR<=“11”;

wait for 10 ns;

end process TESTING;

Execution of statements in a PROCESS

Order of execution

Program control is passed to the first statement after BEGIN

ECE 449 – Computer Design Lab

process with a wait statement
The last statement in the PROCESS is a WAIT instead of WAIT FOR 10 ns.

This will cause the PROCESS to suspend indefinitely when the WAIT statement is executed.

This form of WAIT can be used in a process included in a testbench when all possible combinations of inputs have been tested or a non-periodical signal has to be generated.

TESTING: process

begin

TEST_VECTOR<=“00”;

wait for 10 ns;

TEST_VECTOR<=“01”;

wait for 10 ns;

TEST_VECTOR<=“10”;

wait for 10 ns;

TEST_VECTOR<=“11”;

wait;

end process TESTING;

PROCESS with a WAIT Statement

Order of execution

Program execution stops here

ECE 449 – Computer Design Lab

wait for vs wait
Wait for vs. Wait

0

0

1

1

2

2

3

3

Wait for: waveform will keep repeating itself forever

Wait: waveform will keep its state after the last wait instruction.

ECE 449 – Computer Design Lab

anatomy of a process50
Anatomy of a Process

[label:] process[(sensitivity list)]

[declaration part]

begin

statement part

end process;

ECE 449 – Computer Design Lab

statement part
Statement Part
  • Contains Sequential Statements to be Executed Each Time the Process Is Activated
  • Analogous to Conventional Programming Languages

ECE 449 – Computer Design Lab

sequential statements 1
Sequential Statements (1)
  • If Statement
  • else and elsif Are Optional

ifboolean expression then

statements

elsif boolean expression then

statements

else boolean expression then

statements

end if;

ECE 449 – Computer Design Lab

slide53

If Statement - Example

SELECTOR: process

begin

WAIT UNTIL Clock'EVENT AND Clock = '1' ;

IF Sel = “00” THEN

f <= x1;

ELSIF Sel = “10” THEN

f <= x2;

ELSE

f <= x3;

END IF;

end process;

ECE 449 – Computer Design Lab

sequential statements 2
Sequential Statements (2)

casecondition is

when choice_1 =>

statements

when choice_2 =>

statements

when choice_n =>

statements

end case;

  • Case Statement
  • Choices Have to Cover All Possible Values of the Condition
    • Use others to specify all remaining cases

ECE 449 – Computer Design Lab

slide55

Case Statement - Example

FSM_transitions: PROCESS ( Resetn, Clock )

BEGIN

IF Resetn = '0' THEN y <= S1 ;

ELSIF (Clock'EVENT AND Clock = '1') THEN

CASE y IS

WHEN S1 =>

IF s = '0' THEN y <= S1; ELSE y <= S2 ; END IF ;

WHEN S2 =>

IF z = '0' THEN y <= S2 ; ELSE y <= S3 ; END IF ;

WHEN S3 =>

IF s = '1' THEN y <= S3 ; ELSE y <= S1 ; END IF ;

END CASE ;

END IF ;

END PROCESS ;

ECE 449 – Computer Design Lab

sequential statements 3
Sequential Statements (3)
  • Loop Statement
  • Repeats a Section of VHDL Code
    • Example: process every element in an array in the same way

fori in range loop

statements

end loop;

ECE 449 – Computer Design Lab

slide57

Loop Statement - Example

TEST_DATA_GENERATOR: process

begin

TEST_AB<="00";

TEST_SEL<="00";

for I in 0 to 3 loop

for J in 0 to 3 loop

wait for 10 ns;

TEST_AB<=TEST_AB+"01";

end loop;

TEST_SEL<=TEST_SEL+"01";

end loop;

end process;

ECE 449 – Computer Design Lab

more on architecture
More On Architecture

Concurrent Statements

architecture ARCHITECTURE_NAME of ENTITY_NAME is

  • Here you can declare signals, constants, functions, procedures…
  • Component declarations
  • No variable declarations !!

begin

Concurrent statements:

    • Concurrent simple signal assignment
    • Conditional signal assignment
    • Selected signal assignment
    • Generate statement
    • Component instantiation statement
    • Process statement
      • inside process you can use only sequential statements

end ARCHITECTURE_NAME;

ECE 449 – Computer Design Lab

slide59

Experiment 2

Introduction

ECE 449 – Computer Design Lab

slide60

Experiment 2 – Part 1

VHDL description

Block diagram

architecture MLU_DATAFLOW of MLU is

signal A1:STD_LOGIC;

signal B1:STD_LOGIC;

signal Y1:STD_LOGIC;

signal MUX_0, MUX_1, MUX_2, MUX_3: STD_LOGIC;

begin

A1<=A when (NEG_A='0') else

not A;

B1<=B when (NEG_B='0') else

not B;

Y<=Y1 when (NEG_Y='0') else

not Y1;

MUX_0<=A1 and B1;

MUX_1<=A1 or B1;

MUX_2<=A1 xor B1;

MUX_3<=A1 xnor B1;

with (L1 & L0) select

Y1<=MUX_0 when "00",

MUX_1 when "01",

MUX_2 when "10",

MUX_3 when others;

end MLU_DATAFLOW;

ECE 449 – Computer Design Lab

slide61

Experiment 2 – Part 2

Up and down counter

with a seven segment display

ECE 449 – Computer Design Lab

questions
Questions?

ECE 449 – Computer Design Lab
