ComAp PROTECTION RELAYS AND GENERATOR CONTROLLERS. Protection Relays Australia. COMAP INTELIGEN NT BASEBOX. Comprehensive gen-set controller for both single and multiple gensets operating in standby or paralleling modes.
E N D
ComApPROTECTION RELAYS AND GENERATOR CONTROLLERS Protection Relays Australia
COMAP INTELIGEN NT BASEBOX • Comprehensive gen-set controller for both single and multiple gensets operating in standby or paralleling modes. • To be used in conjunction with detachable colour displays InteliVision 5 or InteliVision 8 Support of engines with ECU (Electronic Control Unit). • Complete integrated gen-set solution and signal sharing via CAN bus – minimum external components needed. • Many communication options – easy remote supervising and servicing. • Gen-set performance log for easy problem tracingAutomatic synchronizing and power control (via speed governor or ECU). • AMF function, Base load, Import / Export, Peak shaving, Voltage and PF control (AVR).
COMAP INTELIMAINS NT BASEBOX • For multiple up to 31 gen-sets operating in parallel to mains (or isolated parallel). • To be used in conjunction with detachable colour displays InteliVision 5, InteliVision 5 RD or InteliVision 8. • Import/export power control of the gen-set group; many different power control modes available. • Reverse synchronization of the loaded gen-set group to mains. • Coupling of several synchronized mains to a common bus. Allows to build complex applications with more mains incomers, bus-tie breakers etc.
COMAP INTELIMAINS NTC BASEBOX • For multiple up to 31 gen-sets operating in parallel to mains (or isolated parallel). • To be used in conjunction with detachable colour displays InteliVision 5, InteliVision 5 RD or InteliVision 8 • Many different power control modes availableSystem Baseload with limited export or minimal import • Import/Export power control of gen-set group • Temperature of the system by power control • Dynamic changes of required system power via analog input • Reverse synchronization of the loaded gen-set group to mains • Forward synchronization of Mains to gen-set groupCoupling of several synchronized mains to a common bus • Allows to build complex applications with more mains incomers, bus-tie breakers, load management etc.
COMAP INTELIPRO • The ComAp InteliPro is often used as a Zero-Export Relay for solar applications. • InteliPro is highly flexible mains decoupling relay with extensive range of protective functions to meet the strictest utility interconnection requirements. It can be used in various distributed generation applications, cogeneration units, renewable energy sources or as a redundant/back-up protection for gen-sets.
COMAP INTELISYS NTC BASEBOX • Premium gen-set controller for both single and multiple gensets operating in standby or parallel modes • Support of cogeneration (CHP) and other complex applications • To be used in conjunction with detachable colour displays InteliVision 8 or InteliVision 5 • Support of engines with ECU (Electronic Control Unit) • Complete integrated gen-set solution and signal sharing via CAN bus – minimum external components needed • Many communication options – easy remote supervising and servicing • Gen-set performance log for easy problem tracingAutomatic synchronizing and power control (via speed governor or ECU) • Baseload, Import / Export, Temp By Power, Peak shaving, Voltage and PF control (AVR)
COMAP INTELISYS NTC GAS GENSET CONTROLLER • The InteliSys Gas is an industrial grade controller for gas generating sets mainly used in CHP (Cogeneration) and power generation applications. The InteliSys Gas controls, monitors and protects the generator set according defined set points and its configuration. • Preconfigured functions, scalable and configurable I/Os, large built-in PLC interpreter, broad communication capabilities and an easy-to-change software allows to adapt the controller to various applications with minimum effort. • The InteliSys Gas and its accessories gives you the perfect solution for your Gas generating set application. You will get the products and related services out of one hand.
