遺 傳 學 Chapter 13

遺 傳 學 Chapter 13. 授課教師 賴伯琦. 基因表現. 轉錄 Transcription 轉譯 Translation. 基因表現. 轉錄 Transcription 由 DNA 的遺傳密碼轉換成 RNA 的含氮鹽基序列 轉譯 Translation. 原核生物的基因轉錄. 只有 RNA polymerase 參與. 原核生物的基因轉錄. 只有 RNA polymerase 參與 結束時是由於終結子 (Rho) 與終結序列結合 (terminator sequences) 作用，稱為 Rho-dependent terminator.

hang
Download Presentation

遺 傳 學 Chapter 13

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 遺 傳 學Chapter 13 授課教師 賴伯琦

  2. 基因表現 • 轉錄Transcription • 轉譯Translation

  3. 基因表現 • 轉錄Transcription • 由DNA的遺傳密碼轉換成RNA的含氮鹽基序列 • 轉譯Translation

  4. 原核生物的基因轉錄 • 只有RNA polymerase參與

  5. 原核生物的基因轉錄 • 只有RNA polymerase參與 • 結束時是由於終結子(Rho)與終結序列結合(terminator sequences)作用，稱為Rho-dependent terminator

  6. 原核生物的基因轉錄 • 只有RNA polymerase參與 • 結束時是由於終結子(Rho)與終結序列結合(terminator sequences)作用，稱為Rho-dependent terminator (type II) • 有些是沒有Rho，而是RNA上的一段序列，稱為Rho-independent terminator (type I)

  7. 4-8 AT base pairs

  8. 真核生物的基因轉錄 • 有3種RNA polymerase參與 • RNA polymerase I：轉錄 ribosome RNAs (rRNAs)，28S、18S、5.8S(S是指在離心時分子大小沈澱粗略值) • RNA polymerase II：轉錄messenger RNAs及一些small nuclear RNAs (snRNAs) • RNA polymerase III：轉錄transfer RNAs (tRNAs)、5s rRNA、及一些snRNAs

  9. RNA polymerase II from yeast

  10. TFIID 接合到 TATA box 形成 initial committed complex. 複合的multisubunit TFIID 有一個次單體(subunit)稱為 TATA-binding protein (TBP), 可以辨認TATA box sequence 還有一些蛋白質稱為TBP-associated factors (TAFs). TFIID–TATA box complex 就像一個可以和其他轉錄因子接合的位置

  11. TFIIA 和 TFIIB 接合

  12. 然後，RNA polymerase II 和 TFIIF 接合 產生 minimal transcription initiation complex. (RNA polymerase II, 如同所有真核生物 RNA polymerases, 無法直接辨認promoter elements並接合)

  13. 然後 TFIIE 和 TFIIH 接合產生complete transcription initiation complex,又稱為 preinitiation complex (PIC). TFIIH 的類解旋酶 (helicase-like) 解開promoter DNA的雙股螺旋，轉錄開始進行。

  14. Chapter 14

  15. 基因表現 • 轉錄Transcription • 由DNA的遺傳密碼轉換成RNA的含氮鹽基序列 • 轉譯Translation • 由DNA轉錄而來的RNA為Messenger RNA，由mRNA轉換成氨基酸序列 • 轉譯進行處為Ribosome RNA • 參與轉譯還有Transfer RNA

  16. Ribosome RNA

  17. E. coli核醣體(ribosome) 的模型 (70S)，包括一個小的次單體 (30S，黃色) 和一個大的次單體(50S，紅色)

  18. Transfer RNA

  19. Transfer RNA

  20. Transfer RNA

  21. Transfer RNA

  22. Amino Acid

  23. Inosine • From Wikipedia, the free encyclopedia. • Inosine is a molecule (known as a nucleoside) that is formed when hypoxanthine is attached to a ribose ring (also known as a ribofuranose) via a β-N9-glycosidic bond. This is a very common modified nucleoside found in tRNAs and is essential for proper translation of the genetic code in Wobble base pairs. • Inosine is a nucleic acid important for RNA editing. A (Adenine) is converted to I (Inosine), which pairs with G (Guanine). • Inosine is also an intermediate in a chain of purine nucleotides reactions required for muscle movements. It is currently being tested as a treatment for multiple sclerosis.

  24. Transfer RNA 如何攜帶特定氨基酸？

  25. 原核生物蛋白質合成的開始 • 在起始密碼之前有一段特殊的序列

  26. 又稱為RBS ribosome-binding site

  27. 原核生物蛋白質合成的開始 • 在起始密碼之前有一段特殊的序列 • 帶有起始密碼Methionine 的tRNA被修飾為帶有甲醛基的 fMet (formylmethionine)
