Presentation Transcript


Chapter 3


  • History of Cell Theory

  • Modern Microscopes

  • Eukaryotic and Prokaryotic Cells

  • Cell Structure and Communication

  • Cell Components

  • Cellular Reproduction

  • Higher Plant Cells Versus Animal Cells

History of cell theory
History of Cell Theory

  • 1665 - Cells discovered by Robert Hooke.

  • Cell Theory - all living organisms are composed of cells and cells form a unifying structural basis of organization.

  • 1831 - Robert Brown discovered nucleus.

  • 1858 - Rudolf Virchow argued no spontaneous generation of cells.

    • Louis Pasteur experimentally disproved in 1862.

Modern microscopes
Modern Microscopes

  • Light Microscopes - increase magnification as light passes through series of transparent lenses made of glass or calcium fluoride crystals

  • Two main types:

    • Dissecting (Stereomicroscopes)

    • Compound Microscopes

Modern microscopes1
Modern Microscopes

Dissecting Microscopes (Stereomicroscopes)

  • Allow three-dimensional viewing of opaque objects

  • Can magnify up to 30x

Modern microscopes2
Modern Microscopes

Compound Microscopes

  • Light passes through thinly sliced material

  • Can distinguish organelles 2 micrometers or larger in diameter

  • Can magnify up to 1500x

Modern microscopes3
Modern Microscopes

  • Electron Microscopes –use beam of electrons produced when high-voltage electricity is passed through wire

  • Two main types:

    • Transmission Electron Microscopes (TEMs)

    • Scanning Electron Microscopes (SEMs)

Modern microscopes4
Modern Microscopes

Transmission Electron Microscopes

  • Up to 200,000x magnification, but material must be sliced extremely thin

Modern microscopes5
Modern Microscopes

Scanning Electron Microscopes

  • Up to 10,000x magnification

  • Surface detail can be observed on thick objects.

Modern microscopes6
Modern Microscopes

Scanning Tunneling Microscope

  • Uses probe that tunnels electrons upon sample

  • Produces map of sample surface

  • Even atoms can become discernible

  • First picture of DNA segment showing helical structure

Eukaryotic versus prokaryotic cells
Eukaryotic Versus Prokaryotic Cells

  • Prokaryotic - cells lack a nucleus

    • Bacteria and archaea

  • Eukaryotic - cells contain a nucleus

    • Plants, animals, fungi and protists

    • Cell walls - Rigid boundary of cells

    • Organelles - Membrane-bound bodies found within eukaryotic cells

Cell structure and communication
Cell Structure and Communication

  • Cell wall surrounds protoplasm.

  • Protoplasm consists of all living cell components.

    • Bound by plasma membrane

Cell structure and communication1
Cell Structure and Communication

  • Cytoplasm - all cellular components between plasma membrane and nucleus

    • Cytosol - fluid within cytoplasm containing organelles

    • Organelles - persistent structures of various shapes and sizes with specialized functions

      • Most, but not all, bound by membranes

Cell structure and communication cell size
Cell Structure and CommunicationCell Size

  • Cells of higher plants vary in length between 10 and 100 micrometers

    • Smaller cells have relatively large surface to volume ratios enabling faster and more efficient cellular communication

Cell structure and communication cell wall
Cell Structure and CommunicationCell Wall

  • Main structural component of cell walls is cellulose(long chains of glucose monomers)

    • Also contain matrix of:

      • Hemicellulose - holds cellulose fibrils together

      • Pectin - gives stiffness (like in fruit jellies)

      • Glycoproteins - proteins with associated sugars

Cell structure and communication cell wall1
Cell Structure and CommunicationCell Wall

  • Middle lamella-produced when new cell walls are formed

    • Shared by two adjacent cells

    • Flexible primary walls laid down on either side of middle lamella

Cell structure and communication cell wall2
Cell Structure and CommunicationCell Wall

  • Secondary walls produced inside primary walls

    • Derived from primary walls by thickening and inclusion of lignin

    • Cellulose microfibrils embedded in lignin for strength.

Cell structure and communication communication between cells
Cell Structure and CommunicationCommunication Between Cells

  • Fluids and dissolved substances pass through primary walls of adjacent cells via plasmodesmata

    • Plasmodesmata - cytoplasmic strands that extend between cells through minute openings

Two adjacent cells connected by plasmodesmata

Cell components plasma membrane
Cell ComponentsPlasma Membrane

  • Plasma Membrane - semipermeableouter boundary of living part of cell

    • Regulates movement of substances into and out of cell

Model of plasma membrane

Cell components nucleus
Cell ComponentsNucleus

  • Nucleus-control center of cell and contains DNA

    • Sends coded messages from DNA to be used in other parts of cell

    • Bound by two membranes constituting nuclear envelope

    • Structurally complex pores occupy up to one-third of total surface area

      • Permit only certain kinds of molecules to pass between nucleus and cytoplasm

Cell components nucleus1
Cell ComponentsNucleus

  • Contains fluid nucleoplasm in which are:

    • Nucleoli - composed primarily of RNA

    • Chromatin strands

      • Composed of DNA and proteins

      • Coil and become chromosomes

Cell components endoplasmic reticulum
Cell ComponentsEndoplasmic Reticulum

  • Endoplasmic reticulum - enclosed space consisting of network of flattened sacs and tubes forming channels throughout cytoplasm

    • Facilitates cellular communication and channeling of materials

    • Synthesizes membranes for other organelles and modifies proteins

Cell components endoplasmic reticulum1
Cell ComponentsEndoplasmic Reticulum

  • Rough ER -ribosomesdistributed on outer surface of ER

    • Associated with protein synthesis and storage

  • Smooth ER -devoid of ribosomes and associated with lipid secretion

Endoplasmic reticulum and ribosomes

Cell components ribosomes
Cell ComponentsRibosomes

  • Ribosomes - consist of two subunits composed of RNA and proteins

    • Link amino acids to construct complex proteins

    • Subunits assembled in nucleolus

    • May occur on outside of rough ER, or in cytoplasm, chloroplasts or other organelles

    • No bounding membranes

Cell components dictyosomes
Cell ComponentsDictyosomes

  • Dictyosomes -(Golgi bodies in animals) - stacks of flattened discs or vesicles


Cell components dictyosomes1
Cell ComponentsDictyosomes

  • Dictyosomes function:

    • To modify carbohydrates attached to proteins synthesized and packaged in ER

    • To assemble polysaccharides and collect them in small vesicles

      • Vesicles pinched off from margins of dictyosomes

      • Vesicles migrate to plasma membrane, fuse with it, and secrete contents to outside of cell

        • Contents may include cell wall polysaccharides, floral nectars, and essential oils in herbs

Cell components plastids
Cell ComponentsPlastids

  • Chloroplasts - most conspicuous plastids

    • Bound by double membrane and contain:

      • Granamade up ofthylakoids

        • Thylakoid membranes contain chlorophyll

        • First steps of photosynthesis occur in thylakoidmembranes

      • Stroma -matrix of enzymes involved in photosynthesis

      • Small circular DNA molecule

        • Encodes for production of certain proteins for photosynthesis

Cell components plastids1
Cell ComponentsPlastids

TEM and drawing of chloroplast structure

Cell components plastids2
Cell ComponentsPlastids

  • Other types of plastids include:

    • Chromoplasts

      • Synthesize and accumulate carotenoids (yellow, orange, red)

    • Leucoplasts

      • Colorless

      • May synthesize starches (amyloplasts)

      • Or oils (elaioplasts)

Chromoplasts in red pepper cells

Cell components mitochondria
Cell ComponentsMitochondria

  • Mitochondria - release energy produced from cellular respiration

    • Bound by two membranes

    • Inward membrane forms numerous folds = cristae

    • Increase surface area available to enzymes in matrix

    • Matrix also includes DNA and RNA

Cell components microbodies
Cell ComponentsMicrobodies

  • Microbodies- small, spherical bodies distributed throughout cytoplasm containing specialized enzymes

    • Bound by a single membrane

    • Peroxisomes -serve in photorespiration

    • Glyoxisomes -aid in conversion of fat to carbohydrates

Cell components vacuoles
Cell ComponentsVacuoles

  • In mature cells, 90% of volume may be taken up by central vacuoles

    • Bounded by vacuolar membranes, tonoplasts

    • Filled with cell sap - helps maintain pressure within cell

      • Contains dissolved substances i.e., salts, sugars, organic acids, and small proteins

      • Frequently contains water-soluble pigments called anthocyanins (red, blue, purple)

Cell components cytoskeleton
Cell ComponentsCytoskeleton

  • Cytoskeleton -involved in movement within cell and in cell’s architecture

    • Network of microtubules and microfilaments

    • Microtubules:

      • Control addition of cellulose to cell wall

      • Involved in movement of flagella and cilia

      • Found in fibers of spindles and phragmoplasts in dividing cells

      • Are thin, hollow, tubelike and composed of tubulins (proteins)

    • Microfilaments -role in cytoplasmic streaming

Cellular reproduction cell cycle
Cellular ReproductionCell Cycle

  • Cell cycle -orderly series of events when cells divide

    • Divided into interphase and mitosis

  • Interphase

    • Occupies up to 90% of cell cycle

    • Period when cells are not dividing

      • G1 -cell increases in size

      • S - DNA replication takes place

      • G2 -mitochondria and other organelles divide, and microtubules produced

Cellular reproduction mitosis
Cellular ReproductionMitosis

  • Mitosis- process of cellular division

    • Produces two daughter cells with equal amounts of DNA and other substances duplicated during interphase

    • Each daughter cell exact copy of parent cell

    • Occurs in meristems

    • Although a continuous process, divided into 4 phases: prophase, metaphase, anaphase and telophase

Cellular reproduction mitosis1
Cellular ReproductionMitosis

  • Prophase

    • Chromosomes condense by coiling and tightening to become shorter and thicker.

      • Chromosomes made of two identical chromatids held together by centromeres

        • Kinetochore (protein complex) located on outer surface of each centromere

        • Spindle fibers (microtubules) attach to kinetochoreand anchored to two poles of cell

  • Nuclear envelope fragments and nucleolus disintegrates

Cellular reproduction mitosis2
Cellular ReproductionMitosis


  • Metaphase

    • Chromosomes align between poles around circumference of spindle at cell’s equator

      • Spindle fibers collectively referred to asspindle

      • At end of metaphase, centromeres holding each sister chromatid separate lengthwise.


Cellular reproduction mitosis3
Cellular ReproductionMitosis

  • Anaphase

    • Sister chromatids separate and pulled to opposite poles, with centromeres leading the way

      • Spindle fibers shorten as material is continuously removed from polar ends

      • Chromatids after separation are called daughter chromosomes


Cellular reproduction mitosis4
Cellular ReproductionMitosis

  • Telophase

    • Each group of daughter chromosomes become surrounded by nuclear envelope

    • Daughter chromosomes become longer and thinner and eventually, indistinguishable

    • Nucleoli reappear

    • Spindle fibers disintegrate

    • Phragmoplast and cell plate form at equator


Cellular reproduction mitosis5
Cellular ReproductionMitosis

  • Cell Plate Formation:

    • Phragmoplast develops between daughter cell nuclei

      • Phragmoplast - complex of microtubules and ER

    • Microtubules trap dictyosome-derived vesicles

    • Vesicles fuse to form cell plate

      • Cell plate grows outward toward mother cell walls

Cell plate formation

  • Portions of ER trapped between vesicles, forming plasmodesmata

Higher plant cells versus animal cells
Higher Plant Cells Versus Animal Cells

  • Plants:

    • Cell walls

    • Cell plate and plasmodesmata

    • Plastids and vacuoles

  • Animals:

    • Internal or external skeletons; no cell walls

    • Plasma membrane called cell membrane

    • Divide by pinching in two; no cell plate nor plasmodesmata

    • Centrioles present during cell division

    • No plastids nor vacuoles


  • History of Cell Theory

  • Modern Microscopes

  • Eukaryotic and Prokaryotic Cells

  • Cell Structure and Communication

  • Cell Components

  • Cellular Reproduction

  • Higher Plant Cells Versus Animal Cells
