  1. G5 HVIC: Next Generation HVIC Platform As part of the natural progression in IC evolution, International Rectifier is investing in the new G5 HVIC process to support the continued improvement of its HVICs, while keeping price under control. The G5 HVIC process allows for improvements in device capabilities, tighter specifications, temperature stability, functions/$, and the integration of previously unavailable features at an attractive price point. This new technology results in two categories of products: New G5 HVIC products, and G5 HVIC replacement products (G5 HVIC replacement products are pin-to-pin compatible with their predecessors). G5 HVIC Home Page G5 HVIC for Appliances • Features • Integrated bootstrap functionality • Integrated PFC driver • Integrated brake drive • Improved input filter • Lower pulse distortion • Reliable spike noise detection • Short pulse rejection • Higher output sink/source capability • UVLO protection for VCC and VBS • Over-voltage protection • Improved UVLO hysteresis • Improved matching times • Improved propagation delays • Faster tON & tOFF • Increased blanking time • - To increase over-current detection reliability • - Reduces the need for external noise filters at the ITRIP pin • Allows higher PWM control G5 HVIC for Lighting G5 HVIC for Motion Control G5 HVIC for Audio • Benefits • Higher signal to noise rejection at input and improved logic threshold values • Increased reliability/ruggedness • - Improved temperature stability • - Advanced high voltage level-shifting technology • Improved DC operation under negative VS conditions • Improved clamping structure provides additional spike protection • Packaging improvements • - Bonding wire • - Molding compound (compliant with future ROHS roadmap) • All G5 HVIC products are lead-free All G5 HVIC Products
