plasma polymers formed in radio frequency sustained non equilibrium plasma

Plasma polymers formed in radio frequency sustained non-equilibrium plasma

Morgan Alexander

plasma

Different flame types of a Bunsen burner depend on oxygen supply. On the left a rich fuel mixture with no premixed oxygen produces a yellow sooty diffusion flame, and on the right a lean fully oxygen premixed flame produces no soot and the flame color bob produced by molecular radical band emission.

The Earth's "plasma fountain", showing oxygen, helium, and hydrogen ions that gush into space from regions near the Earth's poles. The faint yellow area shown above the north pole represents gas lost from Earth into space; the green area is the aurora borealis-or plasma energy pouring back into the atmosphere.

An example of a plasma displayComposition of plasma display panel

Plasma

A fluorescent lamp is a gas-discharge lamp that uses electricity to excite mercuryvapor in argon or neon gas, resulting in a plasma that produces short-wave ultraviolet light. This light then causes a phosphor to fluoresce, producing visible light.0

plasma components
Plasma components
  • Electrons
  • Monomer
  • Radical monomer molecules and molecular and atomic fragments
  • Positive molecules
  • Negative molecules
  • Radiation, including visible and vacuum UV
  • Substrate-sheath
examples of reactions which can occur in the plasma phase of a di atomic gas
Reactions of electrons

Ionization

e- + X-X → X-X+ + 2 e-

e- + X → X+ + 2 e-

Dissociative ionization

e- + X-X → X+ + X+ + 2 e-

Dissociation

e- + X-X → 2X + e-

Dissociative attachment

e- + X-X → X- + X

X- + X+ + e-

Attachment

e- + X-X → X-X-

e- + X → X-

Recombination

e- + X+ → X

e- + X-X+ → X-X

Reactions of ions

Charge transfer

X+ + X-X → X-X+ + X

X-X+ + X → X-X + X

X- + X-X → X-X- + X

X-X- + X → X-X + X-

Detachment

X- + X → X-X + e-

X- + X-X → X-X + X + e-

X-X- + X → X+X X-X + e-

X-X- + X-X → 2 X-X + e-

Ion-ion recombination

X- + X+ → X-X

X- + X-X+ → X-X+X

X-X- + X+ → X-X + X

X-X- + X-X+ → 2 X-X

Atom recombination

2 X → X-X

3 X → X+ X-X

X → WALL ½ X-X

Examples of reactions which can occur in the plasma phase of a di-atomic gas

A.T. Bell, Chapter 1 in: Techniques and Applications of Plasma Chemistry, Eds.: J.R. Hollahan and A.T. Bell, Johan Wiley, New York, (1974).

a new positive ion mechanism
A new positive ion mechanism

O'Toole, L.; Beck, A. J.; Ameen, A. P.; Jones, F. R.; Short, R. D., Radiofrequency-Induced Plasma Polymerization of Propenoic Acid and Propanoic Acid. Journal of the Chemical Society-Faraday Transactions 1995, 91, (21), 3907-3912.

more positive ion mechanisms
More positive ion mechanisms

Alexander, M. R.; Jones, F. R.; Short, R. D., Mass spectral investigation of the radio-frequency plasma deposition of hexamethyldisiloxane. Journal of Physical Chemistry B 1997, 101, (18), 3614-3619.

summary
Summary
  • A large range of reactions are possible in plasma.
  • Initial plasma polymerisation mechanisms were speculative based on conventional chemistry.
  • Much subsequent work has sought to measure the species in organic plasmas, revealing other potential mechanisms.
  • Plasma polymers are often unstable due to a high concentration of trapped free radicals. [T Gengenback ]
