  1. Tektronix Oscilloscope Case Study Garlan & Shaw 1994

  2. Challenge:  Product Family • Little reuse of sw between oscilliscopes • Each product division did their own thing:  programming language, tools, conventions, etc. • SW couldn't even be reused between two oscilliscopes from the same product division: rewrite for new HW • Lack of reuse was slowing down the business process • too long to release new oscilliscopes • too hard to adapt to specialized markets • Performance problems: • switching modes on the scope require loading all new sw • because of limited reuse, loading the sw took too long Can CMU save the day?

  3. Design 1: OO

  4. Pros: greater clarity about the domain / data types Unresolved: how do the types fit together? how should functionality be partitioned? with type of data being measured? externally? which objects should the UI interact with? Design 1: OO

  5. Design 2: Layers

  6. Pros: intuitively appealing Unresolved: strict layer model not appropriate for domain: users need to interact with functions at all levels Design 2: Layers

  7. Design 3: Pipe & Filter

  8. Pros: easy to compose functions in different ways similar to EE view of signal processing as a dataflow problem Unresolved: how do users interact with the system?  unclear. Design 3: Pipe & Filter

  9. Design 4: Modified Pipe & Filter

  10. Pros: benefits of Design 3 clear interface between UI and signal processing can think of filters as higher-order functions parameters determine which transformation is performed Unresolved: poor performance waveforms are large copying between filters is expensive filters run at different speeds Design 4: Modified Pipe & Filter

  11. "Coloured Pipes": may allow data to be processed without copying may allow data to be ignored by slow filters All issues resolved. Design 5: Coloured, Modified P&F

  12. A Fresh View of Compilers your independent reading
