separation processes
SEPARATION PROCESSES
  • BASIC CONCEPTS
  • SPECIFICATIONS FOR PURITY
  • THE FRACTION NEEDS TO BE REMOVED TO MEET TARGET CONCENTRATIONS
  • THE CONCENTRATION OF THE RECOVERED BYPRODUCT
separation processes2
SEPARATION PROCESSES
  • SEPARATION FACTOR
  • WHICH IS ALSO CALLED THE DISTRIBUTION COEFFICIENT
separation factor
SEPARATION FACTOR
  • WHAT THE VALUE MEANS
separation factor1
SEPARATION FACTOR
  • THE SEPARATION IS A RESULT OF EITHER
    • CHANGE IN CHEMICAL EQUILIBRIUM
    • TRANSPORT RATE GOVERNED PROCESS
    • MECHANICAL SEPARATION
separation processes3
SEPARATION PROCESSES
  • PROCESSES CAN BE USED IN SERIES OR PARALLEL TO SEPARATE COMPLEX MIXTURES AND CAN INCLUDE RECYCLE OF STREAMS
mechanical separations
MECHANICAL SEPARATIONS
  • IMPOSE SOME FORCE ON THE SYSTEM TO OBTAIN SEPARATIONS
example of specialization filtration
EXAMPLE OF SPECIALIZATION - FILTRATION
  • CONVENTIONAL FILTRATION
    • REMOVES PARTICULATE BASED ON THE OPEN AREA IN THE FLOW CROSS-SECTION
    • CAN BE MADE OF MANY MATERIALS
    • CAN BE CONTINUOUS, LIKE BELTS, OR BATCH, LIKE A SAND FILTER
conventional filtration separation parameters2
CONVENTIONAL FILTRATION SEPARATION PARAMETERS
  • UNITS ARE DESIGNED TO MAXIMIZE FLOW PER UNIT AREA (FLUX) FOR SPECIFIED PARTICULATE SIZES IN SPECIFIED FLUID
  • CAN BE ENHANCED BY USE OF VACUUM
microfiltration
MICROFILTRATION
  • SEPARATION OF PARTICLES OF ONE SIZE FROM PARTICLES OF ANOTHER SIZE IN THE RANGE OF APPROXIMATELY 0.01 µTHROUGH 20 µ
  • THE FLUID MAY BE EITHER A LIQUID OR A GAS
microfiltration1
MICROFILTRATION
  • FLOW PATTERNS
    • CROSSFLOW SEPARATION
      • A FLUID STREAM RUNS PARALLEL TO A MEMBRANE.
      • THERE IS A PRESSURE DIFFERENTIAL ACROSS THE MEMBRANE.
      • THIS CAUSES SOME OF THE FLUID TO PASS THROUGH THE MEMBRANE, WHILE THE REMAINDER CONTINUES ACROSS THE MEMBRANE, CLEANING IT.
    • DEAD-END FILTRATION OR PERPENDICULAR FILTRATION.
      • IN DEAD-END FILTRATION, ALL OF THE FLUID PASSES THROUGH THE MEMBRANE
      • ALL OF THE PARTICLES THAT CANNOT FIT THROUGH THE PORES OF THE MEMBRANE ARE STOPPED
microfiltration2
MICROFILTRATION
  • CONSTRUCTION
    • MATERIALS OF CONSTRUCTION - MEMBRANE FILTERS CAN BE MANUFACTURED OF
      • VARIOUS POLYMERIC MATERIALS
      • METALS
      • CERAMICS
microfiltration membranes
MICROFILTRATION MEMBRANES
  • PORE STRUCTURE
    • MEMBRANES WITH CAPILLARY-TYPE PORES
      • CALLED SCREEN MEMBRANES
      • PREFERRED FOR APPLICATIONS INCLUDING OPTICAL AND ELECTRON MICROSCOPY, CHEMOTAXIS, EXFOLIATIVE CYTOLOGY, PARTICULATE ANALYSES, AEROSOL ANALYSES, GRAVIMETRIC ANALYSES AND BLOOD RHEOLOGY
microfiltration membranes1
MICROFILTRATION MEMBRANES
  • PORE STRUCTURE
    • MEMBRANES WITH TORTUOUS-TYPE PORES
      • CALLED DEPTH MEMBRANES.
      • LABYRINTH OF INTERCONNECTING ISOTROPIC PORES
      • RECOMMENDED FOR GENERAL PRECISION FILTRATIONS, ELECTROPHORESIS, STERILIZATION OF FLUIDS, CULTURING OF MICROORGANISMS
ultrafiltration 3
ULTRAFILTRATION3
  • ALSO CALLED MOLECULAR FILTRATION
    • USED TO SEGREGATE SUBSTANCES ACCORDING TO MOLECULAR WEIGHT (MW) AND SIZE
    • BASED ON A PRESSURE DIFFERENTIAL ACROSS THE SEMIPERMEABLE MEMBRANE TO DRIVE PERMEABLE MATERIALS THROUGH THE MEMBRANE
    • MEMBRANES USED IN MOLECULAR FILTRATION HAVE PORE DIAMETERS RANGING FROM 1 TO 1,000 ANGSTROMS (Å).
ultrafiltration
ULTRAFILTRATION
  • WILL SEPARATE PARTICLES RANGING FROM 100 TO 106 DALTONS
  • PARTICLES WITH MW OR SIZE LESS THAN THE MEMBRANE MOLECULAR WEIGHT CUT OFF (MWCO)PASS THROUGH THE MEMBRANE AND EMERGE AS PERMEATE
  • SOLUTES WITH GREATER MW OR SIZE ARE RETAINED BY THE MEMBRANE AS RETENTATE AND ARE CONCENTRATED DURING THE MOLECULAR FILTRATION PROCESS.
ultrafiltration1
ULTRAFILTRATION
  • TYPICAL SEPARATION CAPABILITY
reverse osmosis
REVERSE OSMOSIS
  • HYPERFILTRATION, IS THE FINEST FILTRATION KNOWN
  • PROCESS WILL ALLOW THE REMOVAL OF PARTICLES AS SMALL AS IONS FROM A SOLUTION
  • USED TO PURIFY WATER AND REMOVE SALTS AND OTHER IMPURITIES IN ORDER TO IMPROVE THE COLOR, TASTE OR PROPERTIES OF THE FLUID
  • CAN BE USED TO PURIFY FLUIDS SUCH AS ETHANOL AND GLYCOL, WHICH WILL PASS THROUGH THE REVERSE OSMOSIS MEMBRANE, WHILE REJECTING OTHER IONS AND CONTAMINANTS
reverse osmosis1
REVERSE OSMOSIS
  • USES A MEMBRANE THAT IS SEMI-PERMEABLE
  • CAPABLE OF REJECTING BACTERIA, SALTS, SUGARS, PROTEINS, PARTICLES, DYES, AND OTHER CONSTITUENTS THAT HAVE A MOLECULAR WEIGHT OF GREATER THAN 150-250 DALTONS
reverse osmosis3
REVERSE OSMOSIS
  • SEPARATION OF IONS WITH REVERSE OSMOSIS IS AIDED BY CHARGED PARTICLES
    • DISSOLVED IONS THAT CARRY A CHARGE, SUCH AS SALTS, ARE MORE LIKELY TO BE REJECTED BY THE MEMBRANE THAN THOSE THAT ARE NOT CHARGED, LIKE ORGANICS
    • THE LARGER THE CHARGE AND THE LARGER THE PARTICLE, THE MORE LIKELY IT WILL BE REJECTED
nanofiltration
NANOFILTRATION
  • FORM OF FILTRATION THAT USES MEMBRANES TO PREFERENTIALLY SEPARATE DIFFERENT FLUIDS OR IONS
  • NOT AS FINE A FILTRATION PROCESS AS REVERSE OSMOSIS, BUT IT ALSO DOES NOT REQUIRE THE SAME ENERGY TO PERFORM THE SEPARATION
nanofiltration1
NANOFILTRATION
  • USES A MEMBRANE THAT IS PARTIALLY PERMEABLE TO PERFORM THE SEPARATION, BUT THE MEMBRANE'S PORES ARE TYPICALLY MUCH LARGER THAN THE MEMBRANE PORES THAT ARE USED IN REVERSE OSMOSIS.
  • USED TO SEPARATE A SOLUTION THAT HAS A MIXTURE OF SOME DESIRABLE COMPONENTS AND SOME THAT ARE NOT DESIRABLE
nanofiltration2
NANOFILTRATION
  • EXAMPLE IS THE CONCENTRATION OF CORN SYRUP
  • NANOFILTRATION MEMBRANE ALLOWS THE WATER TO PASS THROUGH THE MEMBRANE WHILE HOLDING THE SUGAR BACK, CONCENTRATING THE SOLUTION
nanofiltration3
NANOFILTRATION
  • CAPABLE OF CONCENTRATING SUGARS, DIVALENT SALTS, BACTERIA, PROTEINS, PARTICLES, DYES, AND OTHER CONSTITUENTS THAT HAVE A MOLECULAR WEIGHT GREATER THAN 1000 DALTONS.
  • NANOFILTRATION IS AFFECTED BY THE CHARGE OF THE PARTICLES BEING REJECTED
    • PARTICLES WITH LARGER CHARGES ARE MORE LIKELY TO BE REJECTED THAN OTHERS
    • NOT EFFECTIVE ON SMALL MOLECULAR WEIGHT ORGANICS, SUCH AS METHANOL.
nanofiltration4
NANOFILTRATION
  • COMPARISON OF ULTRAFILTRATION, NANOFILTRATION AND REVERSE OSMOSIS5
electrodyalysis 6 7
ELECTRODYALYSIS6,7
  • ELECTROMEMBRANE PROCESS
    • IONS ARE TRANSPORTED THROUGH ION PERMEABLE MEMBRANES FROM ONE SOLUTION TO ANOTHER UNDER THE INFLUENCE OF A POTENTIAL GRADIENT
    • ELECTRICAL CHARGES ON THE IONS ALLOW THEM TO BE DRIVEN THROUGH THE MEMBRANES FABRICATED FROM ION EXCHANGE POLYMERS
    • APPLYING A VOLTAGE BETWEEN TWO END ELECTRODES GENERATES THE POTENTIAL FIELD REQUIRED FOR THIS
electrodyalysis1
ELECTRODYALYSIS
  • GENERAL APPLICATIONS
    • MEMBRANES USED IN ELECTRODIALYSIS HAVE THE ABILITY TO
      • SELECTIVELY TRANSPORT IONS HAVING POSITIVE OR NEGATIVE CHARGE
      • REJECT IONS OF THE OPPOSITE CHARGE
      • CONCENTRATION, REMOVAL, OR SEPARATION OF ELECTROLYTES
electrodyalysis2
ELECTRODYALYSIS
  • SPECIFIC APPLICATIONS
    • DESALINATION AND WATER TREATMENT
    • PROCESSING FOOD
    • CHEMICAL AND PHARMACEUTICAL PRODUCTS.
equilibrium separation methods
EQUILIBRIUM SEPARATION METHODS
  • THESE INCLUDE ALL THE PROCESSES THAT CHANGE PROCESS CONDITIONS TO AFFECT A CHANGE IN THE CHEMICAL EQUILIBRIUM IN THE SYSTEM
    • THEY INVOLVE THE MIXING OF TWO PHASES AT AN INTERFACE
    • THE SEPARATION RESULTS IN A TARGET COMPONENT INCREASING IN AMOUNT (CONCENTRATION) IN ONE PHASE AND DECREASING IN AMOUNT IN THE OTHER PHASE
equilibrium separation methods1
EQUILIBRIUM SEPARATION METHODS
  • THE NUMBER OF PROCESSES IN EACH GROUP IS IN THE HUNDREDS
examples of separation processes
EXAMPLES OF SEPARATION PROCESSES
  • EVAPORATION
    • INDUCES A PHASE CHANGE BY HEATING
    • MORE VOLATILE COMPONENTS GO TO THE VAPOR PHASE
    • LESS VOLATILE COMPONENTS GO TO THE LIQUID PHASE
evaporation1
EVAPORATION
  • TYPICAL EQUILIBRIUM DIAGRAM
liquid liquid extraction
LIQUID-LIQUID EXTRACTION
  • MIXING OF TWO IMMISCIBLE LIQUID PHASES
  • MOBILE COMPONENT DISTRIBUTES BETWEEN THE TWO PHASES
liquid liquid extraction1
LIQUID-LIQUID EXTRACTION
  • TYPICAL EQUILIBRIUM DIAGRAMS
  • TAKEN FROM: Treybal, R. E., Mass-Transfer Operations, 2nd Ed., McGraw-Hill, 1968
liquid liquid extraction2
LIQUID-LIQUID EXTRACTION
  • TYPICAL PROCESS FLOWSHEET
crystallization
CRYSTALLIZATION
  • SOLUTIONS ARE SUPERSATURATED SO THAT CRYSTALLIZATION CAN OCCUR
  • TYPICAL METHOD IS A COMBINATION OF HEATING AND VACUUM
  • AS THE SOLUTION IS COOLED, THE CRYSTAL WILL PRECIPITATE OUT ON SEED NUCLEI OR EXISTING CRYSTALS
crystallization1
CRYSTALLIZATION
  • TYPICAL EQUILIBRIUM DIAGRAM
crystallization2
CRYSTALLIZATION
  • USING THE EQUILIBRIUM DIAGRAM
      • IT HAS 11 REGIONS WHICH REPRESENT DIFFERENT COMBINATIONS OF SOLIDS, LIQUIDS, AND COMPOSITIONS
      • THE UPPER LEFT "LIQUID SOLUTION" REGION REPRESENTS MAGNESIUM SULFATE DISSOLVED IN WATER
      • AT ANY TEMPERATURE, A VARIETY OF COMPOSITIONS ARE POSSIBLE
crystallization3
CRYSTALLIZATION
  • USING THE EQUILIBRIUM DIAGRAM
    • THE MAIN CURVED LINE (E, P1, P2, P3) IS THE SATURATION CURVE
    • AT 300 K, A SATURATED SOLUTION WILL HAVE ABOUT 0.3 G SULFATE/G SOLUTION.
    • RIGHT OF THE MINIMUM, THE CURVE REPRESENTS THE SOLUBILITY OF SULFATE IN WATER
    • LEFT OF THE MINIMUM REPRESENTS THE SOLUBILITY OF WATER IN SULFATE
using the equilibrium diagram
USING THE EQUILIBRIUM DIAGRAM
  • REGIONS THE RIGHT OF THE SATURATION CURVE REPRESENT SOLID-LIQUID AND SOLID-SOLID MIXTURES
    • THERE ARE ONLY TWO POSSIBLE SOLID COMPOSITION FOR CRYSTALS AND COMPOSITIONS OF THESE REGIONS ARE READ AT THE SIDES
    • EITHER ANHYDROUS MAGNESIUM SULFATE
    • OR MAGNESIUM SULFATE HEPTAHYDRATE
using the equilibrium diagram1
USING THE EQUILIBRIUM DIAGRAM
  • REGIONS AT THE BOTTOM AND THE FAR RIGHT REPRESENT COMPLETE SOLIDIFICATION TO FORM VARIOUS SOLID PHASES
  • THE TRIANGLE AT THE LOWER LEFT REPRESENTS MIXTURES OF (WATER) ICE AND SATURATED SOLUTION
using the equilibrium diagram2
USING THE EQUILIBRIUM DIAGRAM
  • THE MINIMUM POINT ON THE SOLUBILITY CURVE (PT. E) IS CALLED THE EUTECTIC AND IT IS UNIQUE IN THE SYSTEM
    • THIS POINT, THE LIQUID AND SOLID PHASES HAVE THE SAME COMPOSITION
    • COORDINATES OF THE EUTECTIC POINT ARE THE EUTECTIC TEMPERATURE AND THE EUTECTIC COMPOSITUSING THE EQUILIBRIUM DIAGRAM
    • BOTH
    • ION
leaching
LEACHING
  • A PROCESS SIMILAR TO LIQUID-LIQUID EXTRACTION EXCEPT THE SOLUTE (COMPOUND OF INTEREST) DISTRIBUTES BETWEEN AN IMMISCIBLE SOLID AND LIQUID PHASE
  • LIQUID SOLVENT LEACHES THE SOLUTE OUT OF THE SOLID
adsorption
ADSORPTION
  • PROCESS THAT IS THE OPPOSITE OF LEACHING BECAUSE THE SOLUTE IS TRANSFERRED TO THE SOLID PHASE
  • TYPICAL PROCESS IS BATCH WITH PARALLEL UNITS
    • ONE UNIT IS ADSORBING SOLUTE
    • THE OTHER IS BEING REGENERATED
adsorption1
ADSORPTION
  • CAN BE USED FOR REMOVING MATERIALS FROM LIQUIDS OR GASES
    • FOR GASES IT IS POSSIBLE TO REGENERATE USING REDUCED PRESSURE
    • FOR LIQUIDS OR GASES, REGENERATION CAN BE OBTAINED BY HEATING
adsorption2
ADSORPTION
  • MODEL OF THE PROCESS
adsorption3
ADSORPTION
  • CHROMATOGRAPHY IS A VARIATION ON ADSORPTION
  • TYPICAL EXAMPLE SHOWING CFC’S MEASURED IN THE AIR AT UPPER ELEVATIONS8
rate based separation processes
RATE BASED SEPARATION PROCESSES
  • PROCESSES THAT USE THE RELATIVE RATE OF PERMEATION OF COMPONENTS THROUGH A MEMBRANE AS A BASIS FOR SEPARATION
    • TYPICALLY ONE COMPONENT HAS A HIGHER LEVEL OF SOLUBILITY IN THE MEMBRANE THAN THE OTHER, SO IT IS MORE READILY ABSORBED
    • DIFFUSIVITY IS ALSO A FACTOR, AS THE COMPONENTS NEED TO MOVE THROUGH THE MEMBRANE
rate based separation processes1
RATE BASED SEPARATION PROCESSES
  • TOTAL FLUX IS GENERALLY AFFECTED BY SYSTEM PRESSURES
  • MANY OF THESE PROCESSES WERE DISCUSSED IN THE FILTRATION SECTION I.
rate based separation processes2
RATE BASED SEPARATION PROCESSES
  • SUMMARY OF TYPICAL PROCESSES
example of extreme concentration
EXAMPLE OF EXTREME CONCENTRATION
  • FOR RECOVERY OF t-Pa (TISSUE PLASMINOGEN ACTIVATOR)
  • INCLUDES FOUR STEPS TO CONCENTRATE BY 1800 TIMES
example of concentrations in natural materials
EXAMPLE OF CONCENTRATIONS IN NATURAL MATERIALS
  • DATA ON THE FOLLOWING TABLE INDICATES COMPONENTS FOUND IN GRAPES9
example of concentrations in natural materials1
EXAMPLE OF CONCENTRATIONS IN NATURAL MATERIALS
  • SIMILAR DATA IS ALSO AVAILABLE FOR STRAWBERRIES10
