Information about the Magnetic Chucks

From an electro-permanent, electromagnet, or static magnet, magnetic material Magnetic Chuck uses the magnetism to realize holding or chucking action.

climemagnet
Download Presentation

Information about the Magnetic Chucks

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. Information about the Magnetic Chucks http://www.climemagnet.com/

  2. From an electro-permanent, electromagnet, or static magnet, magnetic materialMagnetic Chuck uses the magnetism to realize holding or chucking action. As an alternate to mechanically-holding work pieces, magnets have increased in popularity for holding and machining in recent years. Generally, machine shops increase access to all or any sides of the work piece and are magnets to reduce setup time. For work holding in surface grinding applications, they’re a valuable tool.

  3. There are many advantages to using magnetic chucks. There’s no variation in how loosely or tightly the workpiece is held is ensured by consistent clamping pressure; by securing its center area, full support of the workpiece surface decreases cycle time. Magnetic chucks have shorter setup and takedown times because the workpiece is often placed right the magnetic plate, and vices are often secured using the magnet. With small workpieces, Magnetic chucks make dealing and centering harder because they lack sufficient area. Vises can hold smaller parts also as non-ferrous materials, however, and easily placing several vises on a magnetic chuck and pushing a button to secure all the vises directly may be a time-saver.

  4. Operation Magnetic chucks or Magnetic Welding Holders use magnetism to carry a workpiece in situ while it's being worked on. By inducing polarity into the ferrous work material, the magnets work connecting across its south and north poles. When a workpiece is placed across the poles of the magnet, the flux flows into it. The ferrous components have poles that are opposite the polarity of the magnet in order that they attract one another. To applying magnets, controlling and amplifying this flux is the key during a metalworking operation.

  5. Closing the gap between the workpiece and therefore the magnet increases the attraction or "pull" of the magnet. Smooth-surfaced workpieces are more tightly held than rough-surfaced. The strength of the magnetism may be a function of what proportion of magnetic flux is often induced into the workpiece. Permanent magnetic chucks are manufactured from magnetized materials and exhibit a continuing magnetic flux without having to introduce an electrical current. Because these materials are highly magnetized materials, they are doing not lose their magnetism.

  6. Address: NO.1975 JIANNAN ROAD, NINGBO State: Country: CHINA Zip: 315040 Contact email id: info@climemagnet.com Phone No. : +86-574-27903196 Fax: +86-27-63499779 http://www.climemagnet.com/magnetic_welding/index.html
