Thermal Conductivity 열전도도 2011011467 Kim Hyunwoo 2011011489 Sung Jonghyun 2011011532 Je Changsu
Thermal Conductivity ? k = mass of thermal conductivity (열전도도)A= Area (면적) L= Thickness (두께) ΔT= Temperature Difference (온도차) P= A(ΔT/L) k
ThermalConductivity • Experiment P=kA(ΔT/L)

Thermal Conductivity ? HIGH Thermal conductivity • GOLD • SILVER • COOPER • POLYESTER • HEMP
Thermal Conductivity ? LOW Thermal conductivity • STYROPOAM • WOOL • CERAMIC • PLASTIC • AIR
Application & Development
Application & Development • GRAPHENE • THERMAL PLASTIC • GORE -TEX • ICE PIPE • AEROGEL
Q & A
THANKYOU !
