  1. 未经作者允许，请勿发布该文档！yingqichen@sjtu.edu.cn未经作者允许，请勿发布该文档！yingqichen@sjtu.edu.cn

  2. VHDL Simulation & Synthesis

  3. FSM • 状态机分类 • Moore型状态机设计 • 状态机复位 • Moore型状态机信号输出方法 • Mealy型状态机 • 状态机容错设计

  4. FSM应用 • FSM通过状态图描述状态转换过程 • FSM：数字系统控制单元的建模 • 数字系统： • 受控模块：功能模块，设计较易 • 控制模块实现 • CPU • FSM • 执行耗费时间，执行时间的确定性方面，FSM优于CPU

  5. FSM 构成 FSM用来解决一般时序逻辑电路问题，包括同步/异步时序逻辑 • 状态寄存器 • 当前状态（现态）寄存器 • 组合逻辑电路 • 下一状态（次态）组合逻辑 • 输出组合逻辑

  6. FSM分类 • Moore型：输出信号仅与现态相关 • Mealy型：输出信号与现态和输入相关 输出 输出 OutputComb. Logic OutputComb. Logic 现态 现态 DFFs FeedbackComb. Logic DFFs FeedbackComb. Logic 次态 输入 次态 Moore Mealy 输入

  7. vhdl语言描述FSM的建立过程 跟据具体要求分析控制过程，建立状态转移图后： • 1。定义枚举类型的信号描述状态 • 2。建立第1个进程，描述次态组合逻辑，现态和输入信号作为敏感量， • 3。在进程中定义状态转移 • CASE WHEN语句的一条表示一个状态，状态转移通过IF THEN ELSE语句实现 • 4。对于双进程FSM，建立第2个进程，现态寄存器描述进程，CLK，RST为敏感量；对于单进程FSM，则在一个进程中完成同步状态转移。

  8. process (state, in1)begin -- set defaults for output and state out1 <= '0'; next_state <= sx; -- catch missing -- assignments to -- next_statecase state iswhen s0 => if in1 = '0' then out1 <='1'; next_state <= s1; else out1 <= '0'; next_state <= s0;end if; when s1 =>if in1 = '0' then out1 <='0'; next_state <= s0; else out1 <= '1'; next_state <= s1;end if; when sx => next_state <= sx;end case;endprocess;end behave; Stmch1.vhd library ieee; use ieee.std_logic_1164.all; entity stmch1 is port(clk, in1, rst: in std_logic; out1: out std_logic); end stmch1; architecture behave of stmch1 is type state_values is (sx, s0, s1); signal state, next_state: state_values; begin process (clk, rst) begin if rst = '1' then state <= s0; elsif rising_edge(clk) then state <= next_state; end if; endprocess; input=1 s0/0 Reset=1 input=0 s1/1 input=0 input=1 in1stateclkrst out1next_state Comb Logic DFFs

  9. ARCHITECTURE a OF statmach IS TYPE STATE_TYPE IS (s0, s1); SIGNAL state : STATE_TYPE; BEGIN PROCESS (clk,reset) BEGIN IF reset = '1' THEN state <= s0; ELSIF (clk'EVENT AND clk = '1') THEN CASE state IS WHEN s0 => state <= s1; WHEN s1=> IF input = '1' THEN state <= s0; ELSE state <= s1; END IF; END CASE; END IF; END PROCESS; output <= '1' WHEN state = s1 ELSE '0'; END a; statmach.vhd Library IEEE ; use IEEE.std_logic_1164.all ; ENTITY statmach IS PORT( clk : IN BIT; input : IN BIT; reset : IN BIT; output : OUT BIT); END statmach; s0/0 Reset=1 s1/1 input=1 input=0

  10. Fsm2.vhd WAIT UNTIL (clock'EVENT AND clock = '1'); CASE state IS WHEN s0 => IF x = '0' THEN state := s0; z <= '0'; ELSE state := s2; z <= '1'; END IF; WHEN s2 => IF x = '0' THEN state := s2; z <= '1'; ELSE state := s3; z <= '0'; END IF; WHEN s3 => IF x = '0' THEN state := s3; z <= '0'; ELSE state := s1; z <= '1'; END IF; WHEN s1 => IF x = '0' THEN state := s0; z <= '0'; ELSE state := s2; z <= '0'; END IF; END CASE;END PROCESS;END using_wait; library ieee; use ieee.std_logic_1164.all; ENTITY fsm2 IS PORT(clock,x : IN BIT; z : OUT BIT); END fsm2; ------------------------------------------------- ARCHITECTURE using_wait OF fsm2 IS TYPE state_type IS (s0,s1,s2,s3); BEGIN PROCESS VARIABLE state : state_type := s0; BEGIN 0/0 0/0 s1 s0 1/0 0/1 1/1 s2 1/1 s3 1/0 0/0

  11. FSM的复位 • 同步复位 • 双进程状态机 • 在第1个进程的开始处用IF THEN 语句判断RESET，在其后的ELSE语句里用CASE语句定义状态转换 • 或者在第2个进程里定义同步复位 • 单进程状态机 • 进程里定义同步复位 • 异步复位 • 双进程状态机 • 在第2个进程里定义异步复位 • 单进程状态机 • 进程里定义异步复位 输入 输出 CASE_WHEN IF …THEN ELSE PROCESS 1 CLK’EVENT AND CLK=‘1’ PROCESS 2 次态 现态

  12. Moore型FSM信号输出方法 • 由状态编码位经组合译码后输出 • 并行输出寄存器的译码输出 • 状态位里的编码输出 • 一位有效编码方式

  13. FSM输出方法1 • 由状态编码位经组合译码后输出 delay

  14. FSM输出方法2 • 并行输出寄存器的译码输出

  15. FSM输出方法3 • 状态位里的编码输出 • 缩短输出延时 • 要求状态位编码与输出信号要求的值相结合

  16. moore: process (clk, rst) --this process defines the next state only begin if rst='1' then state <= state0; elsif (clk'event and clk='1') then case state is when state0 => if id = x"3" then state <= state1; else state <= state0; end if; when state1 => state <= state2; when state2 => if id = x"7" then state <= state3; else state <= state2; end if; when state3 => if id < x"7" then state <= state0; elsif id = x"9" then state <= state4; else state <= state3; end if; when state4 => if id = x"b" then state <= state0; else state <= state4; end if; end case; end if; end process; Moore1.vhd library ieee; use ieee.std_logic_1164.all; entity moore1 is port( clk, rst: in std_logic; id: in std_logic_vector(3 downto 0); y: out std_logic_vector(1 downto 0)); end moore1; architecture archmoore1 of moore1 is type states is (state0, state1, state2, state3, state4); signal state: states; begin moore: process (clk, rst)… … End process --assign state outputs concurrently; y <= "00" when (state=state0) else "10" when (state=state1 or state=state3) else "11"; end archmoore1; OutputComb. Logic DFFs FeedbackComb. Logic

  17. moore: process (clk, rst) begin if rst='1' then state <= state0; elsif (clk'event and clk='1') then case state is when state0 => if id = x"3" then state <= state1; else state <= state0; end if; when state1 => state <= state2; when state2 => if id = x"7" then state <= state3; else state <= state2; end if; when state3 => if id < x"7" then state <= state0; elsif id = x"9" then state <= state4; else state <= state3; end if; when state4 => if id = x"b" then state <= state0; else state <= state4; end if; when others => state <= state0; end case; end if; end process; Moore2.vhd library ieee; use ieee.std_logic_1164.all; entity moore2 is port( clk, rst: in std_logic; id: in std_logic_vector(3 downto 0); y: out std_logic_vector(1 downto 0)); end moore2; architecture archmoore2 of moore2 is signal state: std_logic_vector(2 downto 0); -- State assignment is such that 2 LSBs are outputs constant state0: std_logic_vector(2 downto 0) := "000"; constant state1: std_logic_vector(2 downto 0) := "010"; constant state2: std_logic_vector(2 downto 0) := "011"; constant state3: std_logic_vector(2 downto 0) := "110"; constant state4: std_logic_vector(2 downto 0) := "111"; begin moore: process (clk, rst) … end process; --assign state outputs (equal to state std_logics) y <= state(1 downto 0); end archmoore2; No output comb. Logic, no race or hazard DFFs FeedbackComb. Logic

  18. FSM输出方法4 • ONE HOT编码 • 使用N位状态寄存器表达具有Ng 状态的FSM，每个状态具有独立的寄存器位。任意时刻只有1位寄存器为1，即hot point。此为one hot。 • One hot 编码方程用简单的次态方程驱动，减少了状态寄存器之间的组合逻辑级数，因此提高了运行速度。同时是以牺牲寄存器逻辑资源和提高成本为代价的。 • 目标器件具有较多寄存器资源，寄存器之间组合逻辑较少时比较适用。

  19. FSM的容错设计 • 枚举型数据状态编码在综合时转换为矢量信号，状态位数目=log2N，N：状态数 • 若log2N不为整数，存在未定义状态，非法状态。 • 不考虑非法状态则可减少设计的逻辑数目，考虑非法状态则可降低系统容错性 • 原因：干扰，噪声，电源变化等引起触发器翻转误入非法状态，造成死锁。 • 处理：转入空闲态；转入指定态；转入预定义的错误处理告警状态 • When others => State<= idle; ---转入空闲态； • When others => State <=“XXXXX”; ---忽略； • 对one hot型FSM，可编写检错程序，判断是否同时又多个状态寄存器为1，，若有做相应出错处理。

  20. Mealy型FSM 输出 OutputComb. Logic 现态 DFFs FeedbackComb. Logic 次态 Mealy 输入

  21. Mealy_proc: process (clk, rst) begin if rst='1' then state <= state0; y <= "00"; elsif (clk'event and clk='1') then case state iswhen state0 => if id = x"3" then state <= state1; y <= "10"; else state <= state0; y <= "00"; end if; when state1 => state <= state2; y <= "11"; when state2 => if id = x"7" then state <= state3; y <= "10"; else state <= state2; y <= "11"; end if; when state3 => if id < x"7" then state <= state0; y <= "00"; elsif id = x"9" then state <= state4; y <= "11"; else state <= state3; y <= "10"; end if; when state4 => if id = x"b" then state <= state0; y <= "00"; else state <= state4; y <= "11"; end if; end case; end if; end process; Mealy1.vhd library ieee; use ieee.std_logic_1164.all; entity mealy1 is port( clk, rst: in std_logic; id: in std_logic_vector(3 downto 0); y: out std_logic_vector(1 downto 0)); end mealy1; architecture archmealy of mealy1 is type states is (state0, state1, state2, state3, state4); signal state: states; begin Mealy_proc: process (clk, rst) … … end process; end archmealy; OutputComb. Logic DFFs FeedbackComb. Logic
