Final Project 指導老師：潘仁義報告者：曹琴雅
Outline • Topology • 說明
Topology ID_2 ID_1 BS1 BS2 BS3 USER USER USER Time
說明(1/2) • 概念 • LTETracking Area Update • Agent/BCID • BS廣播一個獨特的ID • 位於相同區域的BS具有相同的ID
說明(2/2) • Agent/USUP • 判斷是否位於相同的區域 • 流程圖是否位於相同ID區域顯示訊息並改自己ID NO YES
The End Thank You
