  1. Cartography • Study of Mapmaking

  2. Continents

  3. Topography • The shape of the Earth’s surface • Raised area are hills or mountains • Depressed areas are valleys or craters

  4. Elevation • Height above sea level, measured in feet or meters.

  5. Relief • The difference in a region’s elevations. • Which landscape below has a greater relief?

  6. Map • Drawing showing earth’s surface on a plane (flat surface) • Map Projection • Way of showing a curved earth on a flat surface • Globe: A spherical model of earth • most accurate map is a globe • Flat maps distort features because they are not 3-D

  7. Landscape: • Physical features of • Earth’s surface

  8. Longitude • Measures East and West of the Prime Meridian • Meridians • Lines on a map running from N to S • Used to measure Longitude • Numbered 0° to 180° both east and west • Not parallel to each other

  9. Prime Meridian • Meridian that runs through Greenwich, England • This is 0° • What other countries does the Prime Meridian pass through?

  10. Latitude • Measure of distance N or S of the equator • Parallels • All lines on a map running from E to W • Used to measure latitude • Cross Meridians at right angles • Parallel to each other (concentric circles)

  11. Equator • Imaginary line around the Earth that divides it into two hemispheres • The equator is 0°

  12. Understanding Coordinates… • Each degree (1°) of latitude and longitude is equal to 60 minutes (60’) • Each minute (1’) is equal to 60 seconds (60’’) (Atlas activity) (Google Earth)

  13. Topographic Map • Map that shows the different shapes and sizes of a land surface using contour lines. Map view of hill Side view of hill

  14. Contour Line • Line that passes through all points on a map that have the same elevation

  15. Contour Line Basics • Closer lines indicate steeper terrain • Every Point on a contour line has the exact same elevation • Lines separate points of higher elevation from lower elevation • Never cross each other • Contour lines are hashed to show a depression or crater • An irregular bullseye formed by contour lines represents a hill • Lines form a ‘V’ pattern when crossing streams • The ‘V’ always points upstream

  16. Scale • Ratio of distance on a map to the distance on earth • Shows how a map compares in size to earth • Stated Verbally or graphically • Example – 1:24,000

  17. Benchmark • Location of known elevation • Is a marker set into the ground • Shown as BM on a map

  18. Topographic Profile • Shows land features from the side rather than from an overhead view • Made from a topographic map

  19. Time Zones • Longitudinal belt of Earth in which all areas have the same local time • Earth is divided into 24 time zones • Each 15 degrees wide • How many time zones are in the continental US?

  20. International Date Line (IDL) • 180 degree meridian • Not straight

  21. International Date Line • When the line is crossed going west, one day is added • When the line is crossed going east, one day is subtracted • This line is NOT straight so that countries are not divided and have different dates
