  1. Additional light source type headlamp Requirements for the amendments to ECE-R53 and R113 for motorcycle Presented by International Motorcycle Manufacturer’s Association (IMMA) The 65th GRE session March 30, 2011

  2. Purpose This system is intended to improve the night-time cornering visibility for motorcycle riders. • Functions This system automatically provides an illuminated area produced by an additional light source in accordance with the bank angle of the motorcycle to the illumination area produced by principal headlamp.

  3. Cut-off-line by conventional headlamp Cut-off-line by HIAS Illuminated area by HIAS Illuminated area by conventional headlamp Fig.1 Horizontal inclination adjustment system (HIAS) Cut-off-line by additional light source Cut-off-line by principal headlamp Illuminated area by principal headlamp Illuminated area by additional light source Fig.2 Additional light source type headlamp

  4. Headlamp unit Additional lighting unit (right) Principal headlamp unit ECU bank angle sensor Additional lighting unit (left) Fig.3 System block diagram (example)

  5. Illuminated area by principal headlamp Illuminated area by additional light source

  6. Thank you very much for your kind attention.
