Vcnano 3DLaser Triangulation


Vc nano 3d serie

VC nano 3D Serie

Dx Max 120 mm

Dy +/- 55 mm 110 mm

Working Distance

150 mm

Dx Min 60 mm

Example xr830

Sensor


Automatic salmon portioning

Quelle:

Automatic Salmon portioning

IBN Ingenieurbüro Bernd Neumann GmbH


Vcnano 3d laser triangulation

3D BGA Inspection

  • Max. 1 p.p. Sec.

  • Accuracy +/- 0,1 mmAngle +/- 5°

  • Position

  • Orientation

  • Height


Solder paste inspection

Solder paste Inspection

  • Same height of solder paste

  • Objects with same height


Micro bumps flip chip inspection

Micro-Bumps Flip-Chip Inspection

  • 3D Image

  • Height Profile


Solderpaste inspection

Solderpaste Inspection


3d applications

3D Applications


Lumber measurement

Lumber Measurement


Inner thread measurement

Quelle:

Inner thread measurement
