Presentation Transcript
Slide1 l.jpg

Newport News Waterworks

Impact of Climate Change on Water Supplies of Coastal Communities

Brian L. Ramaley, P.E.

Director, Newport News Waterworks and

President, Association of Metropolitan Water Agencies (AMWA)

World Water Week

21 August 2008


Amwa leaders in water l.jpg

Comprises the largest publicly owned U.S. metropolitan water systems

Members provide drinking water to over 127 million people in the U.S.

Focus on the U.S. Congress, the Administration and Management Issues facing metropolitan water suppliers.

New focus: Climate Change and International Outreach and Knowledge Exchange.

AMWA – Leaders in Water


Amwa s international involvement l.jpg

Expand and enhance AMWA's value to US metropolitan drinking water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

International knowledge exchange on climate change matters is of greatest importance.

AMWA’s International Involvement


Presentation outline l.jpg
Presentation Outline water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

  • Background on Newport News Waterworks

  • Specific Impacts of Climate Change

  • Conclusions for the Future


Newport news waterworks l.jpg
Newport News Waterworks water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

  • Municipally owned system that serves drinking water to more than 400,000 people

  • 3 cities, two counties, many military bases

  • Mid-Atlantic location at mouth of Chesapeake Bay

  • In coastal plain, average elevation < 10 meters


Newport news climate information l.jpg

Month Avg. High Avg. Low Mean Avg. Precip water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

Jan 47°F 32°F 39°F 4.08 in.

Feb 49°F 34°F 42°F 3.60 in.

Mar 57°F 41°F 49°F 4.73 in.

Apr 66°F 49°F 57°F 3.35 in.

May 73°F 58°F 66°F 4.03 in.

Jun 81°F 67°F 74°F 3.44 in.

Jul 85°F 72°F 79°F 4.86 in.

Aug 84°F 71°F 77°F 4.74 in.

Sep 78°F 65°F 72°F 4.84 in.

Oct 68°F 53°F 61°F 3.45 in.

Nov 60°F 44°F 52°F 3.35 in.

Dec 51°F 36°F 44°F 3.43 in.

Newport News Climate Information


Slide7 l.jpg

Newport News - Location water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

Stockholm–>

Atlantic Ocean

Newport News

Virginia

North Carolina


Newport news va waterworks system and water sources l.jpg
Newport News, VA Waterworks System and Water Sources water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

  • Interconnected pumped storage reservoirs and one river intake

  • Chickahominy River is major water source

  • Surface water ----- 57 mgd safe yield based on 75-year record

  • Groundwater desalination ----- 6 mgd yield

    • 1 mgd = 3,785 cubic meters per day

    • 10,000 cubic meters per day = 2.64 mgd


Chickahominy river intake l.jpg
Chickahominy River/Intake water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.


Slide10 l.jpg

Brackish Groundwater Desalting water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.


Climate change impacts to coastal water supplies l.jpg
Climate Change Impacts to Coastal Water Supplies water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

  • Warmer temperatures

  • Changing precipitation patterns

  • Rising sea level


Warmer temperatures l.jpg
Warmer Temperatures water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

  • Higher evaporation/lower yield

  • Higher demand

  • Increased biological activity and impacts on water quality/treatability


Changing precipitation patterns l.jpg
Changing Precipitation Patterns water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

  • More intense rainfall events/storms

    • Increased turbidity/sediment/treatment required

    • Faster reservoir refill – shoreline erosion

    • Spillways must pass more water

    • Storm damage to facilities – redundancy/reliability issues?

  • More frequent, intense or prolonged droughts

    • Higher irrigation demand

    • Reduced surface system yields during drought

    • Reduced groundwater recharge/yield


Rising sea level l.jpg
Rising Sea Level water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

  • Inundation of service area

  • Surge impacts to low lying areas during storms including water utility facilities are magnified

  • Salt water intrusion into surface supplies

  • Salt water intrusion into groundwater

  • Accelerated subsidence


Summary of historical drought studies newport news l.jpg
Summary of Historical Drought Studies: Newport News water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

  • Water supply planning in Eastern U.S. is typically based on most severe drought in 20th Century (e.g., 1930)

  • Firm Yield of 57 mgd for 78-year streamflow record estimated for surface system based on 1930-2008 record


Fort monroe constructed between 1819 and 1834 l.jpg
Fort Monroe water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.Constructed Between 1819 and 1834


Updating drought studies to include 19 th century records l.jpg
Updating Drought Studies to Include 19 water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.th Century Records

  • Monthly rainfall records extend back to 1836 for Southeastern and Central Virginia

  • Standardized Precipitation Index (SPI) method was used to compare 19th and 20th Century rainfall records

  • Synthesized streamflows developed from rainfall records

  • Performed Firm Yield modeling with a 161-year streamflow record


Slide18 l.jpg

Rain Gauge Locations water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

Powhatan Hill, 1849-1876

Fredericksburg, 1893-1998

Richmond, 1872-1998

Williamsburg, 1900-1998

Hopewell, 1888-1998

Newport News, 1899-1927

Hampton, 1869-1913

Fort Monroe, 1836-1890

Norfolk, 1871-1998


Slide19 l.jpg

20 water utilities through access and engagement with similar metropolitan utilities in other countries. Exchange experience and knowledge with utility managers abroad and to provide opportunities for peer-to-peer exchange of ideas and skills.

15

Monthly Rainfall (inches)

10

5

0

1836-1899

1900-1998

1836-1998

Monthly Rainfall Datasets

19th and 20th Century Rainfall Data Show Similar Means and Distributions


Results of firm yield modeling with 161 year streamflow record l.jpg
Results of Firm Yield Modeling with 161-Year Streamflow Record

  • Four 19th Century droughts are more severe than the worst 20th Century drought

  • Minimum Firm Yield is 42 mgd (1851-55 drought)

  • 20th Century drought of record (1930): 57-mgd Firm Yield corresponds to a 22-year return period (rather than a 75-year return period)

  • Firm Yield for a 75-year return period is 44.5 mgd


Implications for water supply planning studies l.jpg
Implications for Water Supply Planning Studies Record

Consideration of 19th Century droughts can significantly change evaluations of existing system reliability and future needs.

Recent droughts and storms indicate a return to precipitation conditions in the mid-Atlantic region more like the 1800s than the 1900s.

Are the 1800s a better model for climate change impacts with respect to yield?



Estimated sea level rise at nn 3 to 4 mm year l.jpg
Estimated Sea Level Rise at NN – 3 to 4 mm/year Record

Relative Sea Level Rise Along the

East Coast of North America

From Zhang et al. (2004) Climatic Change 64: 41–58.


Slide25 l.jpg

Hurricane Isabel Record

Sep 18-19, 2003

Reagan Washington National Airport

Chesapeake Inundation Prediction System (CIPS)

SLR 2008

SLR 2025

SLR 2050

SLR 2075

SLR 2100


Slide26 l.jpg

Hampton Roads Inundation Record

Estimates Under Different

Sea Level Rise Scenarios

  • Extent of flooding is a function of:

    - height of water

  • - land elevation

  • - land relief

  • With increasing sea level, additional

    flooding from storm surge effects will

    be greater than previously

    - smaller storms will have equivalent

    destruction potential as larger storms

    pre-SLR

  • Important implications for both human

    populations as well as living resources

    and coastal environments

From Titus and Wang (2008) EPA.


Conclusions for the future l.jpg
Conclusions for the future Record

  • Climate change will impact coastal water supplies in multiple ways

  • Regional modeling and downscaling of global models are needed to predict temperature, sea level rise, design storms and droughts

  • Combination of impacts must be considered

  • Existing yields and safety factors are almost certainly wrong – high or (more likely) low


Conclusions for the future28 l.jpg
Conclusions for the future Record

  • Diversification of water supplies will enhance reliability – Security Through Diversity

  • Looking further back in time may be a useful way of estimating the future climate

  • Integrated resource planning principles offer a roadmap

  • Redundancy/reliability concerns should be given more attention in the face of an uncertain future
