  1. Memory in FPGAs مرتضي صاحب الزماني

  2. Inferring Memory • Inferring Memory in XST: • Distributed or block memory? • XST implements small RAM components on distributed resources to achieve better performance. • Small? • The threshold varies depending on: • The device family • memory depth • The total number of memory bits

  3. Criteria for BRAM inferring • Use RAM Style to override these criteria and force implementation of small RAM and ROM components on Block RAMs.

  4. RAM Style attribute ram_style: string; … attribute ram_style of {signal_name|entity_name}: {signal|entity} is "{auto|block|distributed|block_power1|block_power2}";

  5. RAM Style • auto (default): • Looks for the best implementation for each inferred RAM, based on: • Whether the description style allows block RAM implementation (synchronous data read) • Available block RAM resources • distributed: • Manually forces to distributed RAM resources • block: • Manually forces to block RAM

  6. RAM Style • block_power1: • Minimally impacts performance • block_power2: • Provides more significant power reduction. • Can significantly impact area and speed •  Use block_power2 if: • Your primary concern is power reduction, and • You are willing to give up some degree of speed and area optimization.

  7. BRAM Incorporation • Three ways to incorporate BRAMs: • Instantiate directly using primitives: • Example: RAMB36E1 or RAMB18E1 in Virtex-6and Virtex-7 • Enables low-level access to all BRAM features • CoreGen tool: • to generate a customizable core, such as a FIFO, which includes BRAMs • BRAM contents can be initialized from a file

  8. BRAM Incorporation • Three ways to incorporate BRAMs: • RTL inference: • You must follow the synthesis tool coding style • Advantage: code portability to other chips (but not to other tools)

  9. Modeling RAM in VHDL • Single write port • Two write ports type ram_type is array (0 to 255) of std_logic_vector(15 downto 0); signal RAM : ram_type; type ram_type is array (0 to 255) of std_logic_vector(15 downto 0); shared variable RAM : ram_type;

  10. Modeling RAM in VHDL • Write access (single write): • use IEEE.std_logic_unsigned.all • signal addr : std_logic_vector(ADDR_WIDTH-1 downto 0); • process (clk) • begin • if rising_edge(clk) then • if we = ‘1’ then • RAM(conv_integer(addr)) <= di; • end if; • end if; • end process;

  11. Modeling RAM in VHDL • Write access (two write): use IEEE.std_logic_unsigned.all process (clk) begin if rising_edge(clk) then if we = ‘1’ then RAM(conv_integer(addr)) := di; end if; end if; end process; • Other forms in: • XST User Guide for Virtex-6, Spartan-6, and 7 Series Devices

  12. RAM Initialization • Example 1: type ram_type is array (0 to 31) of std_logic_vector(19 downto 0); signal RAM : ram_type := ( X"0200A", X"00300", X"08101", X"04000", X"08601", X"0233A", X"00300", X"08602", X"02310", X"0203B", X"08300", X"04002", X"08201", X"00500", X"04001", X"02500", X"00340", X"00241", X"04002", X"08300", X"08201", X"00500", X"08101", X"00602", X"04003", X"0241E", X"00301", X"00102", X"02122", X"02021", X"0030D", X"08201" );

  13. RAM Initialization • Example 2: • type ram_type is array (0 to 127) of std_logic_vector (15 downto 0); • signal RAM : ram_type := (others => "0000111100110101"); • Example 3: • type ram_type is array (255 downto 0) of std_logic_vector (15 downto 0); • signal RAM : ram_type:= ( • 196 downto 110 => X"B8B8", • 100 => X"FEFC" • 99 downto 0 => X"8282", • others => X"3344");

  14. RAM Initialization • Example 4: • Read from a file • type RamType is array(0 to 127) of bit_vector(31 downto 0); • impure function InitRamFromFile (RamFileName : in string) • return RamType is • FILE RamFile : text is in RamFileName; • variable RamFileLine : line; • variable RAM : RamType; • begin • for I in RamType'range loop • readline (RamFile, RamFileLine); • read (RamFileLine, RAM(I)); • end loop; • return RAM; • end function; • signal RAM : RamType := InitRamFromFile("rams_20c.data");

  15. Implementing General Logic with BRAM • If you cannot fit the design onto the device, place some of the logic into unused block RAM. • XST does not automatically decide which logic can be placed into block RAM

  16. Logic on BRAM • To implement logic on BRAM • Isolate the part of RTL code to be placed into BRAM in a separate block. • Apply BRAM_MAP to the block • directly in HDL, or • In Constraint File (XCF) attribute bram_map: string; attribute bram_map of component_name: component is "{yes|no}";

  17. Logic on BRAM • The logic must satisfy the following criteria: • All outputs are registered. • The block contains only one level of Registers (Output Registers). • All Output Registers have the same control signals. • The Output Registers have a synchronous reset signal.
