  1. Chapter 5 IP Routing

  2. Routing • Sending packets through network from one device to another • What must routers know? • Destination address • Neighboring routers • Possible routes to remote network • Best route to remote network • How to keep routing information current

  3. IP Routing Process • Pages 207-210 shows steps when Host A pings Host B (lots of steps!)

  4. IP Routing Process (cont.)

  5. IP Routing Process (cont.)

  6. IP Routing in Larger Network • Figure 5.2 shows diagram of network • Table 5.1 shows networks, interfaces, and addresses • Then, configure those routers!

  7. IP Routing in Our Network • Routing tables keep track of networks • If destination is not in routing table, packet is dropped! • Must build routing table and keep it current • Types of routing • Static • Default • Dynamic

  8. Static Routing • Admin manually adds routes to tables • No overhead on router CPU, no overhead traffic between routers, very secure • Big pain to add routes often, not good for large or changing networks • Adding a static route: ip route [destination_network] [mask] [next_hop_address or exitinterface] [administrative_distance] [permanent]

  9. Verify Your Routing • Ping from one end router to the other • Timeouts are common while routers add to cache • Then, connectivity should be quick

  10. Default Routing • Only one exit port out of a stub network? Can set a default route • Routers Lab_A and Lab_C qualify • Need to remove static routes and add one default route

  11. Dynamic Routing • Use protocols to automatically update tables • Types of routing protocols for Ch. 5: • Routing Information Protocol (RIP) • Interior Gateway Routing Protocol (IGRP) • Advanced protocols not covered here: • Enhanced Interior Gateway Routing Protocol (EIGRP) • Open Shortest Path First (OSPF)

  12. Administrative Distances • Rate the trustworthiness of routes

  13. Classes of Routing Protocols • Distance Vector • Distance is hops to remote network • Vector is direction to remote network • Used by RIP and IGRP • Link State and Hybrid • Keeps track of directly attached neighbors, topology of entire network, builds routing tables • OSPF and EIGRP (not covered yet)

  14. Distance-Vector Routing • Do you know where RIP has problems?

  15. Distance-Vector Start-up

  16. Distance Vector Convergence

  17. Routing Loops • What if Network 5 goes down? • Routing tables don’t converge quickly, loops can occur between remote sites

  18. Stopping Routing Loops • Maximum hop count – avoids routers sending packets infinite times • Split Horizon – routing info cannot be sent back to where it was received • Route Poisoning – send immediate message that route is down (don’t wait for normal routing broadcast timer) • Holddowns – wait longer than normal before announcing that route is back up

  19. RIP • A true distance-vector protocol • Sends updates every 30 seconds on all active interfaces • Only uses hop count • Maximum allowable hop count of 15 • Good for small networks • Inefficient on large networks or slow WAN links • RIP v1 requires same subnet mask for all devices

  20. RIP • RIP Timers • Route update timer – usually 30 seconds • Route invalid timer – no message from router for 90 seconds? Route marked as invalid • Route flush timer – 240 seconds and still no word? Remove route from table

  21. Configure RIP First, remove any static routes. Then, • Lab_A(config)# router rip • Lab_A(config)# network 192.168.10.0 • Lab_A(config)# network 192.168.20.0 • Lab_A(config)# ^Z • Lab_A#

  22. More RIP Stuff • Verifying the RIP Routing Tables • 2621A(config)#sh ip route • You don’t want RIP broadcast to Internet • Holding Down RIP Propagation • RouterA#config t • RouterA(config)#router rip • RouterA(config-router)#network 10.0.0.0 • RouterA(config-router)#passive-interface serial 0

  23. Interior Gateway Routing Protocol (IGRP) • Cisco-only protocol for larger networks • Max hop count of up to 255 • Looks at hop count, bandwidth, and delays • IGRP timers work on larger networks • Update timers – 90 seconds • Invalid timers – 270 seconds • Holddown timers – 280 seconds • Flush timers – 630 seconds

  24. Configure and Verify IGRP • Use same number for routers on same network IGRP Routing (e.g. 10) Lab_A(config)#router igrp 10 Lab_A(config-router)#network 192.168.10.0 • Check configurations (pp. 239-245) show ip route show protocols show ip protocol debug ip rip debug ip igrp events debug ip igrp transactions
