Lecture 1: Computer security overview

1. Lecture 1:Computer security overview Aalto University, autumn 2011

2. Outline • Timeline of computer security • What is security anyway? • Summary

3. Timeline of computer security

4. 70s • Multi-user operating systems  need for protection • Access control models: multi-level security, Bell-LaPadula 1976, BIBA 1977 • DES encryption algorithm 1976  cryptanalysis, need for key distribution • Public-key cryptosystems:Diffie-Hellman 1976, RSA 1978 • Key distribution:  certificates 1978 key exchange protocols: Needham-Schroeder 1978

5. 80s • Orange Book 1985: mandatory access control • Accounting • Commercial security models from accounting and auditing rules: Clark-Wilson 1987 • X.509 PKI 1988 • IBM PC  software copy protection floppy virus 1987 • Internet Morris worm 1988

6. 90s • Methodological approach to security research:  Information flow security  Secure operating systems: SEVMS –1996  Formal analysis of key exchange protocols • Wider availability of cryptography • Cellular networks: GSM 1991 • Open-source cryptography: PGP 1991 • Password sniffers  SSH 1995 • Commercial Internet  SSL ja VeriSign CA 1995 • RSA patent expired in 2000 • Spam: Cantor and Siegel 1994 • PKI criticism  trust management • User authentication beyond passwords • Intrusion detection • Macro virus: Melissa 1999 • DRM

7. 2000s • Fast-spreading Internet worms: Code Red 2001  secure programming secure programming languages security analysis and testing tools • Botnets, spyware  malware analysis • Computer crime: phishing • Enterprise identity management • Security in mobility, Grid, ah-hoc networks, sensor networks • Social networks • Privacy concerns

8. What is security

9. What is security • When talking about security, we are concerned about bad events caused with malicious intent • Security vs. reliability • Terminology: • Threat = bad event that might happen • Attack = someone intentionally causes the bad thing to happen • Vulnerability = weakness in an information system that enables an attack • Exploit = implementation of an attack • Risk = probability of an attack × damage in dollars

10. Security Goals • CIA = confidentiality, integrity, availability • Confidentiality— protection of secrets • Integrity — only authorized modification of data and system configuration • Availability— no denial of service, business continuity • Examples: secret agent names, web server • The CIA model is a good starting point but not all: • Access control — no unauthorized use of resources • Privacy — control of personal data and space • What else?

11. Areas of IT security [Gollmann] • Computer security — security of end hosts and client/server systems • Focus: access control in operating systems • Example: access control lists for file systems • Network security — security of communication • Focus: protecting data on the wire • Example: encryption to prevent sniffing • Application security — security of services to end users and businesses • Focus: application-specific trust relations • Example: secure and legally binding bank transactions

12. Viewpoints to security • Cryptography (mathematics) • Computer security (systems research) • Network security (computer networking) • Software security (software engineering, programming languages and tools) • Formal methods for security (theoretical CS) • Hardware security (HW engineering) • Human aspects of security (usability, sociology) • Security management (information-systems management, enterprise security) • Economics of security, laws and regulation You cannot be just a security expert! Need broader understanding of the systems and applications

13. Security is a continuous process • Continuous race between attackers and defenders • Attackers are creative • No security mechanisms will stop all attacks; attackers just move to new paths and targets • Some types of attacks can be eliminated but others will take their place • Compare with crime statistics: Do locks or prison reduce crime in the long term? • Security mechanisms will fail and new threats will arise→ Monitoring and auditing for new attacks→Contingency planning: how to recover from a breach • Network security is more straightforward than application security, but difficult enough

14. Cost vs. benefit • Rational attackers compare the cost of an attack with the gains from it • Attackers look for the weakest link; thus, little is gained by strengthening the already strong bits • Rational defenders compare the risk of an attack with the cost of implementing defenses • Lampson: “Perfect security is the enemy of good security” • But human behavior is not always rational: • Attackers follow each other and flock all to the same path • Defenders buy a peace of mind; avoid personal liability by doing what everyone else does → Many events are explained better by group behavior than rational choice

15. Proactive vs. reactive security • Technical prevention: design systems to prevent, discourage and mitigate attacks • If attack cannot be prevented, increase its cost and control damage • Detection and reaction: detect attacks and take measures to stop them, or to punish the guilty • In open networks, attacks happen all the time • We can detect port scans, spam, phishing etc., yet can do little to stop it or to punish attackers → Technical prevention and mitigation must be the primary defence • However, detection is needed to monitor the effectiveness of the technical prevention

16. Who is the attacker? • We partition the world into good and bad entities • Honest parties vs. attackers • Good ones follow specification, bad ones do not • Different partitions lead to different perspectives on the security of the same system • Typical attackers: • Curious or dishonest individuals — for personal gain • Hackers, crackers, script kiddies — for challenge and reputation • Companies — for economic intelligence and marketing • Security agencies — NSA, FAPSI, GCHQ, DGSE, etc. • Military SIGINT — strategic and tactical intelligence, cyber war • Organized criminals — for money • Often, not all types of attackers matter • E.g. who would you not want to read your diary?

17. Security research • Security research often focuses on attacks • Engineers should focus on solutions BUT need to understand • how systems fail • how the attacker thinks • adversarial mindset • Security researchers spend most of their time looking for flaws in the work of others  not always welcomed by others; so be careful in how you express yourself

18. Ethical considerations • Who is allowed to attack and when? • Violations of policy • Causing damage • Are security policies for us or against us? • University policy vs. active learning • Difference between research or QA and crime? • Privacy of human subjects • Getting work done vs. following rules • Ethics and software engineering: • Security can be a tool for bad, as well as good

19. Summary

20. Goals of information security • Security goals: confidentiality and integrity of information, availability of services • Authentication, access control, accounting • Protection of services and infrastructure in a hostile environment (e.g. Internet) • Control, monitoring or privacy • Business continuity

21. Reading material • Dieter Gollmann: Computer Security, 2nd ed., chapters 1–2 • Matt Bishop: Introduction to computer security, chapter 1 (http://nob.cs.ucdavis.edu/book/book-intro/intro01.pdf) • Edward Amoroso: Fundamentals of Computer Security Technology, chapter 1 • Ross Anderson: Security Engineering, 2nd ed., chapter 1 (1st ed. http://www.cl.cam.ac.uk/~rja14/Papers/SE-01.pdf)

22. Exercises • What security threats and goals are there in the postal (paper mail) system? • What different entities are there in the postal system? • Do they have the same of different security concerns? • Who could be the attacker? Does the answer change if you think from a different entity’s viewpoint? • Can you think of attacks where it is necessary for two or more malicious parties to collude? • What is role of laws and punishment in computer security? • Can the development of information security technology be unethical, or is engineering always value neutral? Give examples. • When is it (or when could it be) ok for you to attack against IT systems? Give examples. • How do the viewpoints of security practitioners (e.g. system admin or company security officer) and academic researchers differ?
