Presentation Transcript
slide1
INFRASTRUCTURE INTEGRATION IN THE
  • WAPP REGION
  • CEE-UT Workshop
  • Abuja, May 1st & 2nd 2008
presentation outline
Presentation Outline
  • Present situation
  • WAPP organisation
  • WAPP Master Plan
  • WAPP Transmission Priority Projects
  • WAPP Generation Priority Projects
  • The way forward
current power supply situation in the west african sub region
Current Power Supply Situation in the West African Sub-Region
  • Inadequate/Non Existent Transmission Interconnections in ECOWAS Member States and also between ECOWAS Member States;
  • Inadequate Generation Capacity in ECOWAS Member States resulting in Power Shortages;
  • Inability of ECOWAS Member States to raise the necessary financing to implement the projects required to alleviate the situation.
ecowas addresses the needs
ECOWAS ADDRESSES THE NEEDS
  • To address this situation of need, the Economic Community of Western African States (ECOWAS) created a new organization: the West African Power Pool (WAPP)
wapp vision
WAPP VISION
  • The vision of the West African Power Pool (WAPP) Organization is to integrate the operations of the national power systems into a unified, sustainable regional electricity market, with the ultimate goal of providing the ECOWAS Member States with stable and reliable electricity supply at affordable cost
wapp organization
WAPP ORGANIZATION
  • Formed January 2006 by decision of the Heads of State and of Government
    • Articles of Agreement approved
    • WAPP = Specialised Institution of ECOWAS
    • Headquarters Agreement with the Republic of Benin
  • Articles of Agreement
    • Utility association
    • Defines governance/operation structure and roles
    • Operation funded by Members’ contributions
wapp mission
WAPP MISSION
  • Improve supply of reliable, stable, sustainable, affordable electricity
  • Develop integrated regional electricity market
    • Least cost development
    • Economies of scale
    • Access to primary energy resources
    • Increased coverage
    • Maximum benefits through trade
wapp objectives
WAPP OBJECTIVES
  • Facilitate Infrastructure development
    • Transmission interconnections
    • Exploit primary energy resources (Natural Gas; Hydro)
  • Capacity-Building for Secretariat and Member Utilities
  • Develop harmonised Codes & standards to facilitate operation, trade and development, e.g.
    • Operation Manual (OSMP)
    • Planning & design criteria
  • Develop and improve energy Trading
    • System monitoring & coordination
    • Standard agreements (trading, wheeling, power purchase)
    • Electricity market (rules, governance, metering, settlement)
the challenge integrating fragmented national power systems
THE CHALLENGE: Integrating Fragmented National Power Systems

MALI

SENEGAL

GAMBIA

NIGER

BURKINA FASO

GUINEA

GUINEABISSAU

BENIN

  • NIGERIA

SIERRALEONE

TOGO

CÔTED’IVOIRE

GHANA

LIBERIA

master plan for infrastructure development
Master Plan for Infrastructure Development

In line with WAPP Mission and Objectives,the ECOWAS Council of Ministers adopted in 1999 a Master Plan to develop electricity generation and transmission infrastructure, and to interconnect the national electrical power systems

master plan for infrastructure development1
Master Plan for Infrastructure Development

Revised in 2004, the Master Plan

  • Defines the long-term vision and implementation strategy for the regional transmission system
  • Identifies the capital costs of the regional transmission investment program over the next 17 years (2020 horizon)
  • Identifies requirements for the stability, reliability and operability of the regional systems
slide19
WAPP IMPLEMENTATION STRATEGY
  • Coastal Transmission Backbone Subprogram(Cote d’Ivoire, Ghana, Benin/Togo, Nigeria).
  • Inter-zonal Transmission Hub Sub-program(Burkina Faso, OMVS via Mali, LSG via Cote d’Ivoire).
  • North-core Transmission Sub-program(Nigeria, Niger, Burkina Faso, Benin).
  • OMVG/OMVS Power System Development Subprogram(The Gambia, Guinea, Guinea Bissau, Mali, Senegal)
  • Cote d’Ivoire-Liberia-Sierra Leone-Guinea Power System Re-development Subprogram(Cote d’Ivoire, Liberia, Sierra Leone, Guinea).
slide20

MALI

SENEGAL

NIGER

GAMBIA

GUINEABISSAU

GUINEA

  • NIGERIA

BURKINA FASO

BENIN

SIERRALEONE

CÔTED’IVOIRE

TOGO

GHANA

LIBERIA

Coastal Trans Backbone Sub-program

Inter-Zonal Trans Sub-program

North-core Trans Sub-program

OMVG/OMVS Development Sub-program

LSG System Redevelopment Sub-program

Implementation Road Map

interconnected countries 2006
Interconnected Countries 2006

MALI

SENEGAL

NIGER

GAMBIA

GUINEA

BURKINA FASO

GUINEABISSAU

BENIN

NIGERIA

SIERRALEONE

TOGO

CÔTED’IVOIRE

GHANA

LIBERIA

interconnected countries 2007

NIGER

NIGERIA

Lagos

Cotonou

Lomé

Tema

Takoradi

Interconnected Countries 2007

MALI

SENEGAL

GAMBIA

BURKINA FASO

GUINEABISSAU

GUINEA

BENIN

TOGO

CÔTED’IVOIRE

SIERRALEONE

GHANA

LIBERIA

West Africa Gas Pipeline

(WAGP) Project

WAPP 330 kV Coastal

Transmission Backbone

interconnected countries 2010

MALI

SENEGAL

NIGER

BURKINA FASO

BENIN

TOGO

NIGERIA

CÔTED’IVOIRE

GHANA

Lagos

Cotonou

Lomé

Tema

Takoradi

Interconnected Countries 2010

WAPP 225 kV WAPP Zone A/B “Hub”

GAMBIA

GUINEABISSAU

GUINEA

SIERRALEONE

LIBERIA

interconnected countries 2011 12

NIGER

BURKINA FASO

GUINEABISSAU

GUINEA

BENIN

TOGO

NIGERIA

CÔTED’IVOIRE

GHANA

Lagos

Cotonou

Lomé

Tema

Takoradi

Interconnected Countries 2011-12

WAPP 225 kV OMVG Ph.I

MALI

SENEGAL

GAMBIA

SIERRALEONE

LIBERIA

WAPP 225 kV LSG Interconnection

transmission projects to 2011
Transmission Projects to 2011
  • Ikeja West-Sakété (Nigeria-Benin) 2007
  • Bobo Dioulasso-Ouagadougou (Burkina Faso) 2008
  • Aboadze-Volta (Ghana) 2008
  • Volta-Momé Hagou-Sakété (Ghana-Togo-Benin) 2009
  • Aboadze-Prestea-Kumasi (Ghana) 2009
  • Bolgatanga-Ouagadougou (Ghana- Burkina Faso) 2010
  • Han-Bobo Dioulasso-Sikasso-Bamako (Ghana-Burkina Faso-Mali) 2010
  • OMVG (Guinea-Guinea-Bissau-The Gambia-Senegal) 2011
transmission projects 2011 20
Transmission Projects 2011-20
  • Côte d’Ivoire-Liberia/Guinée Forestière-Sierra Leone-Guinée Maritime
  • OMVG Phase II (loop via Sambangalou, Tambacounda)
  • OMVS Kayes-Tambacounda Line (Mali-Senegal)
  • Nigeria-Niger-Benin, Burkina Faso (North Core)
  • Côte d’Ivoire-Mali
  • Côte d’Ivoire-Guinea-Mali
wapp zone a priority projects

Existing 161 kV

330/161 kV line under construction

Under dev’t 330 kV

WAPP Zone APriority Projects

GHANA

GHANA

TOGO

TOGO

BENIN

BENIN

NIGERIA

NIGERIA

2006

2009

Momé Hagou

Sakété

Sakété

Momé

Kumasi

Kumasi

Hague

Akosombo

Akosombo

Obuasi

Obuasi

Cotonou

Cotonou

2009

Lomé

Lomé

2008

Volta

Volta

C

C

Ô

Ô

TE

TE

Prestea

Prestea

2009

D’IVOIRE

D’IVOIRE

Existing 161 kV

Accra

Accra

Committed 330 kV line

Committed 161 kV line

Proposed 330 kV operated at 161 kV

Aboadze

Aboadze

330kV WAPP Coastal Transmission Backbone

wapp zone a priority projects1
WAPP Zone APriority Projects

Interconnection in service

Committed interconnection

Under development

NIGER

MALI

BURKINA FASO

Niamey

2008

Ouagadougou

B. Kebbi

BENIN

GUINEA

Bembèrèkè

NIGERIA

TOGO

CÔTED’IVOIRE

GHANA

LIBERIA

330kV WAPP Northern Transmission Corridor (North Core)

wapp zone b priority projects
WAPP Zone B Priority Projects

OMVS

MAURITANIA

SENEGAL

Dakar

Kayes

Kaolack

Felou

Gouina

MALI

Tambacounda

Brikama

THE GAMBIA

Bamako

Sambangalou

GUINEA-BISSAU

Bissau

GUINEA

Proposed Hydro

Substation

Kaléta

Transmission Line

“OMVS Power System”

- 2nd Generation Projects

Existing 225 kV

Linsan

Under dev’t 225 kV

Canakry

wapp zone b priority projects1
WAPP Zone B Priority Projects

OMVS

MAURITANIA

SENEGAL

Dakar

Felou

Kaolack

Gouina

MALI

Tambacounda

THE GAMBIA

Brikama

Soma

Bamako

Tanaf

Sambangalou

GUINEA-BISSAU

Mali

Bissau

Labe

GUINEA

Proposed Hydro

Pita

Substation

Boke

Kaléta

Transmission Line

“OMVG Power System”

Existing 225 kV

Linsan

Under dev’t 225 kV

wapp zone b priority projects2

Existing 225kV

225kV under construction

WAPP Zone B Priority Projects

MAURITANIA

OMVS

MALI

SENEGAL

NIGER

Ségou

BURKINA FASO

Manantali

Bamako

GUINEABISSAU

BURKINA FASO

Ouagadougou

2008

Sikasso

GUINEA

Bobo Dioulasso

GUINEA

Bolgatanga

Kindia

Han

CÔTED’IVOIRE

Bumbuna

Ferkéssedougou

Laboa

CÔTE D’IVOIRE

SIERRALEONE

Freetown

Nzérékoré

Man

GHANA

Sanniquellie

LIBERIA

Monrovia

Buchanan

LIBERIA

Abidjan

Under dev’t 225kV

225kV WAPP Zone A/B “Hub”

generation projects
Generation Projects
  • Hydro :
    • OMVS - Félou 2012
    • OMVG - Kaléta 2012
    • OMVS - Gouina
    • OMVG - Sambangalou
    • OMVG - Souapiti
    • Liberia - St.Paul River, Mt.Coffee
    • Sierra Leone – Bumbuna, Benkongor, Yben
    • Guinea – Kassa
    • Nigeria - Zungeru, Mambila, Lokoja, Onitsha, Ikom, Gurara, Makurdi, Dyondyonga, Gambou, Kandadji
  • Thermal:
    • Nigeria –Okitipupa, Papalanto, Ibom Power, Alaoji, Geregu, Afam VI
    • Ghana - Takoradi steam turbine, Tema CCGT
    • Senegal – Kahone
regional energy development generation projects

NIGER

GUINEABISSAU

GUINEA

NIGERIA

Under construction or financing closed

Under development

Regional energy development – generation projects

MALI

SENEGAL

GAMBIA

BURKINA FASO

BENIN

TOGO

CÔTED’IVOIRE

SIERRALEONE

GHANA

LIBERIA

Lagos

Cotonou

Lomé

Tema

Takoradi

the way forward
THE WAY FORWARD
  • Realizing WAPP vision - the integration of the presently fragmented national power systems into a unified, sustainable regional electricity market – requires a long and complex process which cannot be fully predicted at this stage. We may, however, attempt to anticipate the series of steps which need to be taken for the creation of a regional electricity market
what is a regional electricity market
WHAT IS A “REGIONAL ELECTRICITY MARKET”
  • Today, there are cross-border exchanges of electricity without competition among sellers, or among buyers
    • A market would require some kind of competition
    • A regional market is different from a national market
  • We recommend the following definition: a regional electricity market exists, when
  • Producers are able to export energy on a competitive basis, or sell to a regional power exchange, and
  • Distribution companies and large end users are able to import energy on a competitive basis, or buy from a regional power exchange
creation of wapp electricity market medium term objective 2011

Genco-transco

Genco-transco

Production

Production

Transmission

Transmission

Power producer

Power producer

System operator

Distribution

Distribution

Distribution

All customers

CREATION OF WAPP ELECTRICITY MARKET MEDIUM TERM OBJECTIVE (2011)
suggested phases for medium term objective 2011
SUGGESTED PHASES FORMEDIUM TERM OBJECTIVE (2011)
  • Phase 1: Bilateral trading
  • Measurement of Net Transfer Capacity (NTC)
  • Unbundling of accounts for the regional network
  • Phase 2: Bilateral trading, with a few transit flows
  • Allocation of NTC on the basis of contract priority
  • Calculation of transmission tariffs for regional network
suggested steps for medium term objective 2011
SUGGESTED STEPS FOR MEDIUM TERM OBJECTIVE (2011)
  • WAPP member utilities should -
    • Establish clear rules on who has the right to use cross-border interconnection capacity
      • Should the importing country claim 100 percent for its own national power company, or genco-transco?
      • How much capacity is available for transit? When?
    • Separate the regional network from the national network
      • Best solution: separate ownership
      • Next best solution: separate accounts
    • Agree on who will pay a transmission tariff for use of the new 330kV and 225kV lines
      • How much capacity will be “reserved” for IPP deals?
    • Develop a standard transmission service contract
long term objective transition from regulated prices to wholesale market prices

Power producer

Power producer

Power producer

Market operator

System operator

Power exchange,or trading system managed by a Market Operator

Distribution

Distribution

Distribution

Eligible customers

Non-eligible customers

LONG TERM OBJECTIVE: TRANSITION FROM REGULATED PRICES TO WHOLESALE MARKET PRICES
suggested phases for long term objective 2020
SUGGESTED PHASES FORLONG TERM OBJECTIVE (2020)
  • Phase 3: Merging of selected zones in the regional network
    • In each zone there is a regional transmission company or the network is operated as one transmission company
  • Phase 4: Start of the regional electricity market
    • Competition among buyers and sellers
    • Each market participant gets access to the whole WAPP regional network by paying only one transmission tariff
    • Transit tariffs and export tariffs are eliminated
  • Phase 5: Start of a regional power exchange
    • Congestion management approach
long term objective transition from regulated prices to wholesale market prices1
LONG TERM OBJECTIVE: TRANSITION FROM REGULATED PRICES TO WHOLESALE MARKET PRICES
  • Given a political choice between:
    • Low electricity prices set by the government, resulting in blackouts and shortages of generating capacity
    • High electricity prices set by a well-designed market, with no blackouts and no generating capacity shortages

… many governments would opt for the 1st alternative

  • Electricity prices must not be too low, or power shortages will follow, nor too high, or social unrest will follow. Finding a balance absorbs most political attention, causing to loose sight of the longer-term objective of creating a regional electricity market which, with help from Adam Smith’s invisible hand, will automatically find the correct price levels.
