  1. World Wide Video VIDEO BROADCAST • THE REAL LIVE CAST DEVICE

  2. WWV LIVE CASTER • BROADCAST YOUR LIVE

  3. Video Compression and Recording, Playback and Broadcasting MP4 (H.264/AAC) QBOX Video: H.264 base profile + filed encoding Audio: AAC Connectors: Ethernet 10/100 Mbps, WiFI (802.11a/b/g) Wibro (80216e) WIMAX, HSPA, EV-DO Rev A Streaming: QTX, QRX, RTSP Server, RTSP Reciver Netprotocolls: UDP, TCP, RTSP, RTP, HTTP, FTP Size: 110x80x27 mm Wight: 300 Gramm The system in its current version is able to deliver real time video and audio through any wireless network which supports GSM/UMTS. The real time data will be transferred to a central Server. This server will be connected with the CDN (Content delivery Network) to broadcast the streams in real time. TECHNICAL SPECIFICATION • WWV - Video broadcast system

  4. Broadcast Architecture Social Network compatible HD Camera InnoTec deliveryplatformincl. mobile payment Analogoe or digital connection Live Web Portals SD Version HD Version WWV Player

  5. YOUR LIVE EVENT Promotions Facebook Konzert Sport Event Produktvorstellung

  6. YOUR LIVE STREAM MOBILE DEVICES AND CONNECTED TV´S

  7. TRANSPORTATION CASE

  8. TRANSPORTATION CASE • Live casting case includes: • Eyebox video broadcast device • Cameras • UMTS router • Antenna for stabile WLAN • WLAN Client • Case

  9. CAMERA DEVICES • open source - for every camera device

  10. CAMERA DEVICES • open source - for every camera device

  11. It´s so EASY • open source - easy to use

  12. LIVEDRONE • Your Event, Live from the Sky

  13. HD Camera HD-MMRR Modem HEXACOPTER LIVE EVENT UAV HD-Multi Modem relay RouterLIVE in THE AIR illustration

  14. Remote maintenance eyebox • The eyeboxpublic.IP data service facilitates direct access to servers and other systems connected to the Internet via a mobile network.eyeboxpublic.IP permanently assigns a public fixed IP address to a server using a mobile network router. To this end mdex has created the transition from the public Internet to the private mdex network via its own eyeboxpublic.IP gateway. • All servers (web, E-Mail, FTP, VPN, remote access, etc.) accessed via the Internet require a fixed public IP address! • For this reason fixed public IP addresses are offered as a service option for DSL access points (e.g. fixed IP address from Arcor for business connections). • Up until now, this service option was not available for mobile network Internet access points. As a general rule the latter usually have private, dynamic IP addresses.

  15. InnoTec DATA An den Kolonaten 3926160 Bad ZwischenahnGermany
