Digital Strain Indicator - Digitech Roorkee
Digital Strain Indicator (DG-ME-DSI-Cxx), is designed for direct measurement of strain. Strain gauges are used as sensors while being arranged in the full bridge & half bridge configuration. Use of advanced electronic integrated circuitry makes it efficient to measure as accurately as 0.1% of the reading. The bridge is excited by a highly stabilized, low ripple D.C. Power Supply (5V nominal). The inherent imbalance of the bridge is initially balanced by the potentiometer provided on the board. The output of the bridge is amplified by a precise, low drift, low noise & highly stabilized D.C. amplifier and is available in analogue form on request. The instrument is calibrated to display direct micro strains for one active arm. The instrument has a very wide range of application in the industrial field of Mechanical and Civil Engineering, Mining, Spinning, Ship and Aircraft Building and various research and development Laboratories. FEATURES APPLICATIONS Microprocessor based Mechanical and Civil Direct display in Engineering engineering units. Mining Built-in 16 character Ship and Aircraft Industry intelligent LCD display. Various R&D Laboratories Analogue output Low noise SPECIFICATIONS DIGITECH Product Code DG-ME-DSI-Cxx Equipment Measuring Equipment Category Display 16 X 1 LCD display Resolution 1 micro strain Range /- 10,000 micro strain Analogue Output 0 to ± 2V Linearity 0.1% Bridge 4 ARM Configuration Strain Gauge 120 TO 350 Ohm Resistance Bridge Excitation 5.00V D.C. Nominal. Bridge Balance By Pot provided on front panel Temp. Coefficient 50 PPM ºC Power Supply 230V ac mains /- 10% Power 5 Watt (approx.) Consumption Weight 2.5 kg Dimension 300x200x100 mm Operating Temp 0º C to 55º C Range Mechanical and Civil Engg, Applications Mining, Ship and Aircraft Industry, R&D Lab Ordering Information Item: Digital Strain Indicator Category: Measuring Equipment Unique Code: DG-ME-DSI-Cxx Accessories: - Power Cord - Operating Manual Customization: Multiple Channels option available (Any customisation request to be made at the time of placing the order) Order Placement: - Via the Website - Via E-mail - Via Phone A K Goel Managing Director Digitech Roorkee info@digirke.com 9897239204 Web: www.digirke.com
