  1. Shape Matching and Object Recognition using Shape ContextsJitendra MalikU.C. Berkeley(joint work with S. Belongie, J. Puzicha, G. Mori)

  2. Outline • Shape matching and isolated object recognition • Scaling up to general object recognition

  3. Biological Shape • D’Arcy Thompson: On Growth and Form, 1917 • studied transformations between shapes of organisms

  4. Deformable Templates: Related Work • Fischler & Elschlager (1973) • Grenander et al. (1991) • Yuille (1991) • von der Malsburg (1993)

  5. Matching Framework ... model target • Find correspondences between points on shape • Estimate transformation • Measure similarity

  6. Comparing Pointsets

  7. Shape Context Count the number of points inside each bin, e.g.: Count = 4 ... Count = 10 • Compact representation of distribution of points relative to each point

  8. Shape Context

  9. Shape Contexts • Invariant under translation and scale • Can be made invariant to rotation by using local tangent orientation frame • Tolerant to small affine distortion • Log-polar bins make spatial blur proportional to r Cf. Spin Images (Johnson & Hebert) - range image registration

  10. Comparing Shape Contexts Compute matching costs using Chi Squared distance: Recover correspondences by solving linear assignment problem with costs Cij [Jonker & Volgenant 1987]

  11. Matching Framework ... model target • Find correspondences between points on shape • Estimate transformation • Measure similarity

  12. Thin Plate Spline Model • 2D counterpart to cubic spline: • Minimizes bending energy: • Solve by inverting linear system • Can be regularized when data is inexact Duchon (1977), Meinguet (1979), Wahba (1991)

  13. MatchingExample model target

  14. Outlier Test Example

  15. Synthetic Test Results Fish - deformation + noise Fish - deformation + outliers ICP Shape Context Chui & Rangarajan

  16. Matching Framework ... model target • Find correspondences between points on shape • Estimate transformation • Measure similarity

  17. Terms in Similarity Score • Shape Context difference • Local Image appearance difference • orientation • gray-level correlation in Gaussian window • … (many more possible) • Bending energy

  18. Object Recognition Experiments • Kimia silhouette dataset • Handwritten digits • COIL 3D objects (Nayar-Murase) • Human body configurations • Trademarks

  19. Shape Similarity: Kimia dataset

  20. Quantitative Comparison Number correct rank

  21. Handwritten Digit Recognition • MNIST 600 000 (distortions): • LeNet 5: 0.8% • SVM: 0.8% • Boosted LeNet 4: 0.7% • MNIST 60 000: • linear: 12.0% • 40 PCA+ quad: 3.3% • 1000 RBF +linear: 3.6% • K-NN: 5% • K-NN (deskewed): 2.4% • K-NN (tangent dist.): 1.1% • SVM: 1.1% • LeNet 5: 0.95% • MNIST 20 000: • K-NN, Shape Context matching: 0.63%

  22. Results: Digit Recognition 1-NN classifier using:Shape context + 0.3 * bending + 1.6 * image appearance

  23. COIL Object Database

  24. Error vs. Number of Views

  25. Prototypes Selected for 2 Categories Details in Belongie, Malik & Puzicha (NIPS2000)

  26. Editing: K-medoids • Input: similarity matrix • Select: K prototypes • Minimize: mean distance to nearest prototype • Algorithm: • iterative • split cluster with most errors • Result: Adaptive distribution of resources (cfr. aspect graphs)

  27. Error vs. Number of Views

  28. Human body configurations

  29. Automatically Locating Keypoints • User marks keypoints on exemplars • Find correspondence with test shape • Transfer keypoint position from exemplar to the test shape.

  30. Results

  31. Trademark Similarity

  32. Outline • Shape matching and isolated object recognition • Scaling up to general object recognition • Many objects (Mori, Belongie & Malik, CVPR 01) • Gray scale matching (Berg & Malik, CVPR 01) • Objects in scenes (scanning or segmentation)

  33. Mori, Belongie, Malik (CVPR 01) • Fast Pruning • Given a query shape, quickly return a shortlist of candidate matches • Database of known objects will be large: ~30000 • Detailed Matching • Perform computationally expensive comparisons on only the few shapes in the shortlist

  34. Representative Shape Contexts • Match using only a few shape contexts • Don’t need to compare every one

  35. Snodgrass Results

  36. Results

  37. Conclusion • Introduced new matching algorithm matching based on shape contexts and TPS • Robust to outliers & noise • Forms basis of object recognition technique that performs well in a variety of domains using exactly the same algorithm
