Presentation Transcript
slide1

Progress Measurement for 3D CAD Projects

Martin Brooks

Chief Engineer - Plant Layout & Piping

Parsons Energy and Chemical Group, London

Discovering thePOWER

International IGUG 1999

synopsis
Synopsis

Has your office ever suffered from “black box syndrome” ? Have you ever had to explain why design progress has flat lined ? At least on the board everyone can see what’s going on, and we can issue lots of paper.

This presentation offers some simple, yet scientific ideas to help progress and control 3D CAD projects. It will show how the status of the model should be linked to key milestones and to the quality of the supporting information.

slide3

Problem - Track along flat line ?

Traditional curve

Deliverables

What’s happening here ?

Progress

Database set up

3D curve

Time

slide4

Purpose of Presentation

  • Demonstrate one proven scientific method exists, that works for us.
  • Encourage input from and build confidence for Clients, Project Management, Project Controls, and Construction.
  • Provide a forum for debate and capture other ideas on best practice in this area.
slide5

Need for such measurement

“ Now with the bulk of the time spent building the 3D model and the isos. being generated all at the end of the project, a billing mode needs to be developed that is based on progress in completing the model ”

Oil & Gas Journal, Dec.22 1997

slide6

Work Process Change

  • Database set up versus Start drawing
  • Isos before GA’s versus GA’s before isos
  • Fast track structural design

Traditional project control by drawing found to be unsatisfactory and too subjective on 3D projects

slide7

Need for new measurement tools

Tradition method hrs.

3D method hrs.

Start drawing 0

Set up/admin. DB 1000

Arrangements 100

Arrangements 10

Isometrics 20

Isometrics 2

What used to take a long time is now quick, and what used to take no time now takes some time.

slide8

3 Step methodology

Milestone weighting

Quality weighting

Complexity weighting

Choose number of steps to suit project

slide9

Basis for tracking - Step 1

Establish milestone weightings:

Manhours by discipline, to follow the 3D workflow :-

  • Database set-up - 5%.
  • Civil/Structural/Undergrounds - 23%
  • Piping - 43%
  • Isometrics - 1%

See progress log slide for full listing

slide10

Basis for tracking - Step 2

Establish quality weightings :

Progress input against estimated quantities, then apply a factors to reflect the quality of information available :-

  • Status of P&ID’s ( 10%, 50%, 75%, 95%, 100%)
  • Status of equip. data ( 10%, 50%, 75%, 95%, 100%)
  • Status of design verification: material checks, clash check, design reviews, stress analysis.

See progress log slide for full listing

slide11

3D model progress log - 1

Main tool for progress tracking

slide13

Project

Equipment

Piping

Unit / Euip. no.

Unit / Line no.

Status

Status

Status of equip. and lines

Designers enter status in accordance with Work Breakdown Structure :-

slide15

7

6

5

4

Piping

Isos

3

Civil/S/U

2

Milestone 1 Database set up

1

Solution - Progress by milestones

Progress

Time

slide16

Make progress visible

7

6

5

4

3

2

1

Display pictures, plans, and charts in project area

slide18

Additional work

Never stand still, continuously review for improvements and best practice :-

  • Measurement of C/S/A & E&I.
  • Automate into Project Control systems.
  • Cultural change to review model not paper.
  • Extend method into the construction.

Measurement is not a substitute for experience.

slide19

Final Questions

Thanks for you time

  • mbrooks@pareuo.com
  • + 44 (0) 181-326-5052
  • Parsons, Data General Tower, Great West Rd., Brentford, Middlesex, TW8 9AN
