1. TYPES oF INDUSTRIAL VALVES AND THEIR USES

2. Introduction • Valves are a simple mechanical or simple electro-mechanical device that are used to control the flow of gases, liquids, powders, etc. through the pipes or the tubes from the tanks or other containers. • Mostly, the valves depend on the design of mechanical barrier i.e., a ball, a plate, a diaphragm that can be inserted and removed from the flow stream of the material that is passing by some of the valves are designed into on-off models, while others are designed to allow proper control of the path of substances.

3. Types of Valves • Ball Valves • Butterfly Valves • Gate Valves • Check Valves • Global Valves

4. Ball Valves • Ball Valves are the kind of valves that incorporate ported spheres that rotate in the pipe stream to either block, or allow, flow. They are quarter-turn valves that are used practically when the flow of the fluid must be shut off from a compressed-air line to a high-pressure, hydraulic system.

5. Butterfly Valves • Butterfly Valves are quarter-turn valves which employ centre-mounted circular flaps that swing into, and out of, the flow stream. These valves are used in wastewater plants, power plants, and process plants for shut-off and for regulating & isolating services.

6. Gate Valves • Gate Valves are the type of valves primarily used for blocking fluid flow and for flow regulation. It uses a plate-like barrier which can be lowered into the flow stream to stop the flow. The plugs usually seal both the up & downstream parts of the valve while the plates seal only on the upstream part.

7. Check Valves • Check Valves allow the fluid to flow through them in one particular direction only and are often suited for high-pressure applications rendering them highly effective in low-pressure applications. • Double door check valves use two half-circle gates or wafers that are hinged at the centreline of the valve port and open downstream in the direction of flow.

8. Global Valves • Gate Valves are the type of valves primarily used for blocking fluid flow and for flow regulation. It uses a plate-like barrier which can be lowered into the flow stream to stop the flow. The plugs usually seal both the up & downstream parts of the valve while the plates seal only on the upstream part.

9. Industrial Uses • All the above-mentioned valves can be deployed in a wide range of industries which includes food and beverage, chemical processing, gas transmission, oil and gas, mining, and power generation. • Features: • There are certain designs which are more suitable to be bubble tight than others, specifically those valves that are intended for on-off service and those that are used mainly for flow regulation processes

10. Conclusion • We Valvulasfevisa, are thevalve manufacturers and leading valve stockistin UAE , Dubai, USA. • Our primary focus is check valves and ensure that our expertise is grounded in the manufacturing of WRAS approved valves and UL FM approved valves. • Our team of designers & engineers can assist you into making the right choice of the kind of valve for your application. We have wide range of ex-stock valves with international standards
