Presentation Transcript
slide2

DRUTA DAHAN CHULLI(fast crematory furnace) based on the GREEN FURNACE FOR CREMATORY GROUNDS innovated by late kantiBhusanSen

Talk by:

SurajitSen

Department of Physics

Gurucharan College

Silchar

what causes global warming
What causes global warming
  • Excessive concentration of Green House Gas (GHG) is primarily responsible for Global Warming
  • Main constituents of GHG are CO2, CH4, CF4, NO2, SF6, various CFCs, …

Classification of Global Warming

  • Natural global warming
  • Anthropogenic (Man-made) global warming
contribution of natural or anthropogenic global warming
Contribution of natural or anthropogenic global warming

Man-made contribution to the Climate Change needs to be curbed.

magnitude of global warming
Magnitude of global warming

vs Time plot explains why Climate Change is a threat

slide8

Carbon contamination of our climate

  • Historically Carbon dioxide concentration is around 200 – 280ppm
  • Present concentration is 378ppm and it is rising at 1.5 ppm per year
  • Point of no return ≈ 400-450ppm? (Between 2040-2050)
  • We have 10-20 years is left to show that we can make

a difference?

three important methods to tackle global warming
Three important methods to tackle global warming
  • Promote large scale forestation
  • Reduce the `Carbon Footprint’- individual carbon contribution to climate
  • Transform `Conventional Projects’ into innovative `Clean Development Mechanism (CDM)’ Projects and get it certified by UNFCCC to generate `Carbon Credit’
  • How to integrate all three features in a single project
unep recommendation to curb carbon footprint
UNEP recommendation to curb Carbon Footprint

Since 2008 United Nations Environment Program (UNEP) recommending individual `CARBON FOOPRINT’ by changing their lifestyle

a innovative way of reducing the individual carbon footprint

`Fast Crematory Furnace or DrutaDahanChulli’ is an innovative project which reduces the `Carbon Footprint’ of every individual even beyond death !

A innovative way of reducing the individual `Carbon Footprint’
  • Hundreds of dos… and do not… exists for living persons
contents
Contents
  • 1. Traditional Crematory Furnace
    • a) Essential components
    • b) Fuel
  • 2. Structure of Traditional Furnace
  • a) Sectional view
    • b) Top view
  • 3. DrutaDahanChulli (DDC)
    • a) Essential components
    • b) Fuel
contents contd
Contents (Contd.)
  • 3. Structure of DrutaDahanChulli (DDC)
    • a) Lateral view
    • b) Sectional view
  • 4. Layout of DDC
  • 5. Technical specification
  • 6. Comparison of DDC with traditional furnace
  • 7. Why DDC is a `Green Furnace’?
  • 8. Impact of the DDC Project
  • 9. Prospect of UNFCCC Certification of the DDC as a CDM Project
  • 10. Historical notes
traditional crematory furnace
Traditional crematory Furnace

Essential components

  • 1. Brick Basement
  • 2. Rail

Fuel (Tire Derived Fuel (TDF))

1. Primary fuel:

i) Larger log of firewood

2. Secondary fuel (Supportive):

i) Kerosene (substantial)

ii) Scrap tire

HAZARDOUS

structure of traditional furnace
Structure of Traditional Furnace

Corpse Bed

Sectional & Top view

Wood

Wood

Vertical Rail

Vertical Rail

Wood

Wood

Brick

Side Stand

H Rail

Brick Side Stand

Wood

Wood

Larger log of Wood

Larger log of Wood

H Rail

H Rail

Brick

Side Stand

Brick

Side Stand

Vertical rails

Rail

Rail

Brick

Basement

Rail

H Rail

Scrap tire burning from bottom

druta dahan chulli fast crematory furnace
DrutaDahanChulli(Fast Crematory Furnace)

Essential components

  • 1. Brick Basement
  • 2. Rail
  • 3. Air tunnel with fan
  • 4. Regulators
  • 5. Cleaning arrangement

Fuel

1. Primary fuel:

Smaller & medium pieces of firewood

2. Secondary fuel (supportive):

i) Kerosene - Very less (Just to start ignition)

ii) Scrap Tire - Nil

Module-I: Furnace Unit

Module-II: Blower Unit

structure of druta dahan chulli sectional view
Structure of DrutaDahanChulli(Sectional view)

FURNACEUNIT

BLOWER UNIT

BLOWER HOUSE

Sliced Wood

Sliced Wood

Sliced Wood

Sliced Wood

Vertical Rail

Vertical Rail

Sliced Wood

Sliced Wood

Box-shaped focused Air flow duck

Sliced Wood

Sliced Wood

Air Reg-I:

Steel door

Sliced Wood

Sliced Wood

Slab cover

Wood

Wood

H Rail

Brick

Side Stand

Brick Side Stand

Air Regula-tor-II

Blower Fan

Brick

Basement

Water Pump

Movable iron doors to cover two open portions of chulli

Underground water tank

Hose Pipe

structure of druta dahan chulli top view
Structure of DrutaDahanChulli(Top View)

FURNACEUNIT

BLOWER UNIT

Drain

Air Regulator-II

Air flow duck

Air Regulator-I

BLOWER HOUSE

Brick

Side Stand

H Rail

Brick

Side Stand

Rail

Rail

Blower Fan

V Rail

Rail

Rail

Water pump

H Rail

Hose Pipe

Air Regulator-II:

Movable iron door

Under ground Water Tank

technical specification of ddc
Technical specification of DDC

Module-I: Furnace Unit (Traditional Furnace +)

  • Two brick platforms: Each with Length 7ft, Breadth 2.6ft, Height 2.6ft from Finished Ground Level (FGL)
  • Distance between two brick platforms: 3 ft
  • Rail (Horizontal): 3 ft (6 numbers)
  • Rail (Vertical): 3.6 ft (2X6 numbers)
  • Base of the furnace: Slightly U (concave) shaped
  • Size of air flow outlet duct penetrating one side of brick platform : 13in X 13in
technical specification of ddc1
Technical specification of DDC

Module-II: Blower Unit

Air Tunnel

  • Length of air flow duct (From Blower House to base of the furnace): Approx 10 ft
  • Shape of air flow duct: Box-shaped, focused towards furnace and covered by air-tight slab
  • Inlet size of air flow duct: 2ft X 2ft
  • Outlet size of air flow duct: 13in X 13in
  • Diameter of air blower (Fan): 2 ft
  • Speed of fan: Standard RPM available in market
technical specification of ddc2
Technical specification of DDC

Air Regulation

  • Regulator-I (Optional): Movable iron plate of size 15in X 15in to control air through the duct manually
  • Regulator-II: Two movable iron doors each of size 3.4ft X 2.6ft on both open sides of furnace

Post cremation cleaning arrangement

  • Underground water reservoir
  • Water pump with hose pipe
  • Drain to flow out debris after each cremation
why ddc is a green project
Why DDC is a `Green Project’ ?

A conservative estimate:-

  • Assuming 800 corpses are burnt per year, the DDC project economizes about 10kg of firewood than the Traditional Furnace and saves at least 1 man-hour per corpse:

a) Goodbye to Tire Derived Fuel (TDF) from Silchar Cremation Ground

  • Reduces individual `CARBON FOOTPRINT’ by eliminating harmful TDF

b) In 1 year DDC saves 21 days man-hour approximately

*X-Y=10 kg

  • c) In 1 year DDC saves 80 Quintal of firewood approximately
unfccc certification of the ddc project as a cdm project a proposal

Proposed Project

Large scale implementation of the DDC project across the country

UNFCCC Certification of the DDC Project as a CDM Project : A proposal

If CDM Project is recognized

ddc project historical notes1
DDC Project: Historical Notes

An Invitation Letter of a meeting on March 8, 1988

ddc project historical notes2
DDC Project: Historical Notes

Newspaper clippings of Foundation Stone lying Ceremony, February 1, 1989

ddc project historical notes3
DDC Project: Historical Notes

Original Invitation Letter of Inaugural Program April 15, 1989

ddc project historical notes4
DDC Project: Historical Notes

Photograph of Inaugural Program April 14, 1989

ddc project historical notes5
DDC Project: Historical Notes

Photograph of Inaugural Program April 14, 1989

ddc project historical notes6
DDC Project: Historical Notes

Recognition by SRISTI & Honey Bee Network of IIMA

Innovated by

Kanti Bhusan Sen

`

`Green Living, Green Death’

“The range the innovations made by Prof Sen touched not only lives but also the deaths. He invented the DrutaDahanChullior Fast Burning Furnace in 1989 which can be called a green furnace for cremation. It is alternative to the traditional cremation among the Hindus. . . .”

“The success of the DrutaDahanChulliin the crematory ground of Silchar for last two decades is a testimony of Green Consciousness spread by Prof Sen. He was given fitting finale in this furnace after his demise on June 9, 2004.”

Honey Bee Vol 19 (2008) p16

green living green death
`Green Living, Green Death’

TAKE PLEDGE TO REDUCE

`CARBON FOOTPRINT’

TRANSFORM

TRADITIONAL CREMATORY CHULLI OF YOUR LOCALITY INTO

`DRUTA DAHAN CHULLI ’

acknowledgement
Acknowledgement
  • 1. All philanthropists who contributed directly and indirectly in making of the `Green Chulli’
  • 2. Late Dwijendra Kumar Deb and Sri Dilip Kumar Chakraborty
  • 3. Silchar Municipality Board
  • 4. Honey Bee Journal, Vol.19 (2008) p16
  • 5. AnandabazarPatrika (June 8, 2008)

* * * * *

slide41

THANK YOU

for patient listening
