I.C. ENGINES. Practical No: 7 ( 5 May, 2014). Fuel Consumption. Objective To calculate thermal efficiency of the engine Apparatus Engine test bench Accurate measuring tank Flow meter Stop watch (min time should be not less than two minutes) . Fuel Consumption. Procedure
