gtttot rule backchaining sequence
GTTTOT Rule Backchaining Sequence

6

5

4

3

9

2

1

7

8

10

11

Goal: If action is known, Then print action and conclude consultation.

Rule 4:

If means = drive,

and location = downtown,

Then action = take cab.

Rule 5:

If means = drive,

and location = not downtown,

Then action = drive.

Rule 6:

If means = walk,

and weather = bad,

Then action = take coat & walk.

Rule 7:

If means = walk,

and weather = good,

Then action = walk.

Rule 1:

if distance > 5 miles,

Then means = drive.

Rule 2:

If distance > 1 mile,

and time < 15 minutes,

Then means = drive.

Rule 3:

If distance > 1 mile,

and time > 15 minutes,

Then means = walk.

Question:

What is distance?

Question:

How many minutes until showtime?

Question:

Is location downtown or not?

User answer: 2

User answer: 10 minutes

User answer: downtown
