SPOC Automation a nd BECI- who are we?. Pump Focused VFD company Specialists in Optimizing Pump Control SPOC 15+ Years in business BECI 16+ Years in business Both Family Owned SPOC Based in Trussville, AL BECI – Based in Conway, AR. Efficiency using Automation VFDs.

Download Presentation
## SPOC Automation a nd BECI- who are we?

**An Image/Link below is provided (as is) to download presentation**
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

**SPOC Automation**and BECI- who are we? • Pump Focused VFD company • Specialists in Optimizing Pump Control • SPOC 15+ Years in business • BECI 16+ Years in business • Both Family Owned • SPOC Based in Trussville, AL • BECI – Based in Conway, AR**Efficiency using Automation VFDs**• “Power” Basics • AC Motor Basics • AFD Basics • Energy Savings Basics • Discrete Automation Advantages**POWER**Basics**The Basics**HP is the measurement of the work that the motor can perform. 33,000 ft/lbs per minute or 746 Watts 1 HP = Note: 5250 comes from (33,000 ft·lbf/min)/(2π rad/rev)**The Basics**Torque is: • directly proportional to HP • indirectly proportional to speed • related to current demand – so, the higher the torque, the higher the HP – the higher the current demand. To understand Horsepower and Torque better, we need to understand how a motor works……..**AC Motor**Basics**The Basics**Electric motors convert electrical energy to mechanical energy**The Basics**The motor stator is made up of a series of windings wound to create a series of magnetic poles when energized**The Basics**When 3 phase AC power is applied to the stator winding a rotating magnetic field is created.**The Basics**Induction causes Rotor rotation The rotor tries to align itself with the rotating magnetic field. With no losses, the rotor would rotate at the synchronous speed.**The Basics**An induction motor is basically a constant speed device because the stator field rotates based on the frequency of the AC power system Looking at the equation differently: what would happen to the speed of the AC Motor if the frequency to the stator changed?**The Basics**The Basics 300 10 Hz 900 30 Hz 1800 60 Hz**VFD**Basics**VARIABLE FREQUENCY DRIVES**How does a Variable Frequency Drive Work? THREE SECTIONS 1. CONVERTER - Transforms (Converts) AC Line Power to DC Voltage 2. DC FILTER - The DC Voltage is Cleaned 3. INVERTER - Tranforms (Inverts) the DC Voltage to Synthetic AC Voltage**DRIVE TERMS**Pulse Width Modulation (output) Definition - DC current is switched on and off quickly to appoximate an AC sine wave**Energy Savings**Basics**Energy savings**• 50HP Motor running full speed for a year…How much does it cost to run? • @ 10 Cents per kwh, about $30k**Typical Variable Torque Loads**• Most Pumps • Supply and Exhaust Fans • Aerators**This is THE $$$$**Equation!!! Variable Torque Application HP = K(Operating speed/nameplate speed)3 Max Volts 230/460/575 Variable Torque Constant HP V/Hz Ratio V/Hz Ratio Output Voltage V/Hz Ratio 0 Extended Frequency 60 Hz Frequency**Variable Torque Application**HP = K(Operating speed/nameplate speed)3 • Why is this considered to be THE $$$$ Equation? Energy Savings! • HP equals cube of the speed, so • ½ speed = (1/2) x (1/2) x (1/2) = 1/8 HP • ¼ speed = 1/64 HP • A 100HP motor at ½ speed requires 12.5 HP • HP is directly proportional to $**Savings Example-oversized fan**• If a zoo runs a 10HP Motor for 24 hours a day at full speed: • 10HP x (1)3 x 0.746 KW/HP = 7.46KW • 7.46KW x 24 hours = 179 KWhrs • If a zoo runs a 10HP motor for 24 hours a day at 3/4 speed: • 100HP x (3/4)3 x 0.746 KW/HP = 3.14 KW • 3.14 KW x 24 hours = 75.36 KWhrs • 58% Savings simply by slowing the fan down by 25%. • New Reduced airflow through fan is 75% of original**Savings Example--**• If a zoo runs a 100HP Pump for 12 hours a day at full speed: • 100HP x (1)3 x 0.746 KW/HP = 74.6KW • 74.6KW x 12 hours = 895 KWhrs • If a zoo runs a 100HP Pump for 24 hours a day at ½ speed: • 100HP x (1/2)3 x 0.746 KW/HP = 9.4 KW • 24 hour day: 9.4 KW x 24 hours = 225 KWhrs 75% energy savings to move the same amount of fluid**VFD “Myth Buster” #1**• Myth: VFD’s are rated VT and CT • Fact: VFD’s are rated based on over-current capabilites. Typically, drives are rated at • 110% overload for 1 minute, or • 150% overload for 1 minute.**AFD “Myth Buster” #2**• Myth: AFD’s are inefficient at low speeds. • Fact: The AFD is typically >96% efficient throughout the speed range. • The concern is the AC Motor: • It is self-cooled • The slower the motor is going, the less cooling from the fan • Most modern motors have specifications for what is allowed**AFD “Myth Buster” #3**• Myth: I’ll burn up motors if I connect more than one to an AFD • Fact: One of the biggest benefits of an AFD is that more than one motor can be controlled by one drive. All motors will receive the same voltage and frequency.**Automation VFD**Basics**Pump Automation**+ VFD Controls**Pump Automation**• Control process • Safety interlocks • Eliminate manual adjustments to hit targets • Variable Capacity • Flexibility for rate of flow or compression • Energy Savings +**Pump Automation**Easy, right? …..but we forgot a couple things**Pump Automation**+ VFD startup technician PLC startup technician**Pump Automation**PLC VFD Automation VFD PLC Technician SCADA**Typical Controls**• Branch of Electrical Contractor • Usually 1 or 2 techs • Exists to support contractor business • Dedicated Controls Company • Typically small company • Can do anything approach • Customized solutions**Automation VFD**……..It’s In There • Simple Operation • Operator Friendly Startup • Standard Product • Standard Support**Automation Drives**……..It’s In There • Reduce Electrical Costs • Reduce On-off Cycles • Eliminate Bypass Valves • Simplified Startup • Single Vendor responsibility • Easy System Troubleshooting**Automation Drives**• Typical savings $10-$15k installed cost advantage of traditional PLC based approach • Optimized for smaller systems with a few pumps or fans per system • Simple setpoint changes • Flow • Pressure • Temperature
