  1. Product Overview April. 2014

  2. Overview • Based on over 10 years of industry experience, MCC System provides you with a full series of Digital Security Products. • Full Series of Embedded DVR • HD NVR & HD-SDI DVR • Full Series of Camera • : HD IP Camera & HD-SDI Camera & HD Hybrid Camera • IP Encoder & IP Camera Module • Integrated Network & Mobile Solution

  3. DVR Products

  4. DVR Series Product Line • 960H Analog DVR Series • HD-SDI DVR Series • HD NVR Series * PoE : Optional

  5. DVR Series Key Features(1) • ezP2PTM Cloud Service(www.ezp2p.com) ezP2PTM Cloud Service is a cloud-based video management system without any complicated network setting. You can preview the thumbnail image of each registered device and enjoy instant live monitoring by log-in at ezP2PTMCloud Server(www.ezp2p.com) with your e-mail address. [Preview] [Main Screen] • PUSH Function Below 3 PUSH functions provide effective monitoring & control of DVR. It allows user to be free from constant attention to the event that may or may not happen. [PUSH Network Connection] [PUSH Video Call] [PUSH Notice] Automatic Connection under Event iPhone/iPad & Android Phone Easy F/W Upgrade

  6. DVR Series Key Features(2) • Startup Wizard Startup Wizard will guide you through the whole process of system startup. Major setting of DVR can be made by simply following the steps in Startup Wizard. And you can reconfigure these setting at any time by accessing to main menu. [HDD] [Date/Time] [Network] [Language] [Recording] • Integrated Network Solution Guarantee unlimited scalability and seamless integration of all MCC products such as DVR, NVR & IP Camera over unique network. [SmartViewerPro] [CMS]

  7. DVR Series 960H DVR(Entry Grade) • HE-4000 Series Price-Affordable Economic Grade DVR • ezP2P™ Cloud Service without any complicated network setting • ezLink™ for Instant Live Monitoring with Mac Address input • 3 Typical PUSH Functions • PUSH Video Call(iPhone/iPad & Android Phone) • PUSH Notice for Auto F/W Upgrade • PUSH Network Connection under Sensor Event • POS Function up to 4 sets of POS Devices • Startup Wizard for Easy Configuration • Remote Monitoring by Remote S/W(CMS) & Smart Phone • Talk-Back Function for 2-way communication with Smart Phone [HE-4004/4008AX] [HE-4016CX]

  8. DVR Series 960H DVR(Standard Grade) • HE-4100 Series User Friendly Standard Grade DVR • ezP2P™ Cloud Service without any complicated network setting • ezLink™ for Instant Live Monitoring with Mac Address input • 3 Typical PUSH Functions • PUSH Video Call(iPhone/iPad & Android Phone) • PUSH Notice for Auto F/W Upgrade • PUSH Network Connection under Sensor Event • POS Function up to 4 sets of POS Devices • Startup Wizard for Easy Configuration • Remote Monitoring by Remote S/W(CMS) & Smart Phone • Talk-Back Function for 2-way communication with Smart Phone [HE-4104/8/16CX]

  9. DVR Series 960H DVR(Premium Grade) • HE-4200 Series Premium Grade DVR with Powerful CPU & Hardware • ezP2P™ Cloud Service without any complicated network setting • ezLink™ for Instant Live Monitoring with Mac Address input • 3 Typical PUSH Functions • PUSH Video Call(iPhone/iPad & Android Phone) • PUSH Notice for Auto F/W Upgrade • PUSH Network Connection under Sensor Event • POS Function up to 4 sets of POS Devices • Startup Wizard for Easy Configuration • Remote Monitoring by Remote S/W(CMS) & Smart Phone • Talk-Back Function for 2-way communication with Smart Phone [HE-4208/16DX]

  10. DVR Series HD-SDI DVR • HH-5100 Series Full HD Real-Time HD-SDI DVR with Universal Hybrid Input(8/16ch) • ezP2P™ Cloud Service without any complicated network setting • ezLink™ for Instant Live Monitoring with Mac Address input • 3 Typical PUSH Functions • PUSH Video Call(iPhone/iPad & Android Phone) • PUSH Notice for Auto F/W Upgrade • PUSH Network Connection under Sensor Event • Universal Hybrid DVR(HH-5108/HH-5116) • POS Function up to 4 sets of POS Devices • Startup Wizard for Easy Configuration • Remote Monitoring by Remote S/W(CMS) & Smart Phone • Talk-Back Function for 2-way communication with Smart Phone [HH-5104CX] [HH-5108/16DX]

  11. DVR Series HD NVR • HN-5100 Series Easy but Powerful operational HD NVR • ezP2P™ Cloud Service without any complicated network setting • ezLink™ for Instant Live Monitoring with Mac Address input • 3 Typical PUSH Functions • PUSH Video Call(iPhone/iPad & Android Phone) • PUSH Notice for Auto F/W Upgrade • PUSH Network Connection under Sensor Event • POS Function up to 4 sets of POS Devices • Startup Wizard for Easy Configuration • Remote Monitoring by Remote S/W(CMS) & Smart Phone • Talk-Back Function for 2-way communication with Smart Phone [HN-5104/8/16CX]

  12. Camera Products

  13. Camera Series Product Line • HC Series IP Camera • KC Series IP Camera • KC Series Hybrid Camera • KC Series HD-SDI Camera • KC & HC IP Camera Module

  14. Camera Series Key Features • ezP2PTM클라우드 서비스 (www.ezp2p.com) ezP2PTM Cloud Service is a cloud-based video management system without any complicated network setting. You can preview the thumbnail image of each registered device and enjoy instant live monitoring by log-in at ezP2PTMCloud Server(www.ezp2p.com) with your e-mail address. [Preview] [Main Screen] • FocusAssist Function When the [FocusADJ] menu in the Camera OSD menu is turned on, three-bar graph appear. Adjust Lens and minimize Green Color in the bar to match focus.

  15. Camera Series HC Series IP Camera(1) • 1.3 Megapixel

  16. Camera Series HC Series IP Camera(2) • 2.1 Megapixel

  17. Camera Series KC Series IP Camera • 2.1 Megapixel

  18. Camera Series KC Series Hybrid Camera • 2.1 Megapixel & 1080P

  19. Camera Series KC Series HD-SDI Camera • 1080P

  20. Camera Series IP Camera Module(1) • KC Module & HC Module Dut to its tiny size (42 x 42 mm), MCC IP Camera Module can be installed inside most of the analog camera from small box camera up to speed dome, just switching into Megapixel IP Camera. • KC-Module which adopts Ti DSP & Eyenix solution • HC-Module which adopts Hisilicon solution • 30 fps @ D1 & 720P & 1080P • ONViF & RTSP Protocol • Wi-Fi Transmission through USB Wi-Fi Module • Network-failed recording by USB Media • ezP2P™ Cloud Service • Remote monitoring through CMS & Smart Phone • PUSH Video Call to iPhone & iPad • 64ChSMS(NVR Software) included

  21. Camera Series IP Camera Module(2) • Implementation Example Here are few implementation examples. MCC is ready to provide full technical support. [Zoom Camera] [Box Camera] [Dome Camera] [Speed Dome Camera]

  22. Integrated Network Solution

  23. Integrated Network Solution Product Line All MCC products, such as DVR, NVR & IP Camera, have the optimized compatibility with the following software. • ezP2PTM Cloud Service • CMS • SmartViewerPro • SMS • Utility Software

  24. Integrated Network Solution ezP2PTM Cloud Service(1) ezP2PTM Cloud Service is a cloud-based video management system without any complicated network setting. You can preview the thumbnail image of each registered device and enjoy instant live monitoring by log-in at ezP2PTMCloud Server(www.ezp2p.com) with your e-mail address. • Steps • Step 1 : Create your own account at ezP2PTM Cloud Server(www.ezp2p.com). • Step 2 : Turn on “USE P2P CLOUD” in the menu of DVR, NVR or IP Camera and input e-mail • address & password which is registered at ezP2PTM Cloud Server. • Step 3 : Log in at ezP2PTM Cloud Server and select Preview to see all registered devices’ • information with thumbnail image. You can monitor live image by clicking thumbnail • image. And you can also connect to the device through webpage and change • configuration as well as monitor live/playback image. [Main Screen] [Preview]

  25. Integrated Network Solution ezP2PTM Cloud Service(2) [Live Monitoring] [Web Viewer]

  26. Integrated Network Solution CMS CMS(Centeral Management Software) is a powerful centralized management solution that offers users full flexibility to control the entire system(DVR, NVR & IP Camera) over the network. Users can set automatic back schedule for effective handling of massive volume of video data, and also get full monitoring on system status. • Max. 180 Channel Real-Time Monitoring • Up to 5 Monitors on a Single PC Workstation • Cloning Features to Create the Separate Windows • Automatic Connection and Image Pop-up under Event • Schedule Backup over Network • Multi-Layer E-Map Editor • Many More… [Schedule Backup] [Live Monitoring] [Cloning Feature]

  27. Integrated Network Solution SmartViewerPro SmartViewerPro provides you with efficient LIVE/VOD monitoring of all MCC products(DVR, NVR & IP Camera) with your iPhone/iPad & Android Phone. PUSH Video Call function helps you to check any event occurs in your system at anytime and anywhere. • VODMode • Live Mode • Menu : • PTZ, Digital Zoom, Snap Shot, Relay, • Frame(Main/Sub), Full Screen, Talk-Back • Menu : • Time Search, Digital Zoom, Snap Shot, • Frame(Main/Sub), Full Screen • PUSH Video Call • Event : Motion Event, Sensor Event, Video Loss

  28. Integrated Network Solution SMS SMS(Storage Management Software) is the Windows based storage software that provides data recording of all MCC’s IP products over network. User can build up perfect total management system for recording & monitoring under effective combination with CMS. • Records up to 64 x IP Cameras • Perfect Compatibility with CMS • Live Image Relay Server • Live Monitoring of Recording Status • Instant Image Search • Multi-HDDs Management

  29. Integrated Network Solution Utility Software • Web Viewer With built-in web server, user always can connect to the device(DVR, NVR & IP Camera) by ordinary web browser for live monitoring, VOD playback and system configuration without installing any software. [System Configuration] [VOD] [Log In] [Live] • 16Ch Backup Player • IP Installer It is automatically transferred and saved at the backup media together with the selected video clips, and thus user can playback the backup data just by one mouse click. Once executed on the PC, IP Installer discovers and displays the device list on your network and then user can manually assign the IP address.

  30. Thank You MCC System Co., Ltd.
