  1. DWX: Reasons to Convert

  2. DWX Applications Professional Live Sound Professional ENG/EFP Live Concert News Gathering Wide RF bandwidth provides ENG users with greater potential to find unoccupied frequencies in congested metropolitan areas. Direct slot-in makes DWX the ideal solution along with Sony’s camcorders. A V-mount attachment is also available to expand mounting options. Higher-quality wireless transmission maintains the sonic integrity of legendary microphone capsules and subtle overtones of guitar or bass instruments. Now the DWX series assists with frequency coordination and use with other wireless systems. Theater Hall Field Production Receiver DC operation, and a choice of rack mounting and portable receivers, for use on a sound cart, enables high-quality field production for movies, sports, drama, reality TV shows and commercials. As well as offering large-scale simultaneous multi-channel operation, the DWX series can be used with a wide range of popular lavalier and headset microphones to suit any theater performance. New Wireless Studio 3.0 helps with complex system integration and simplifies daily operation. Broadcast Studio Sound Shooting The compact, robust design suits production with a mixer bag. Three-way powering and three-parallel audio output from a portable receiver are features that give great flexibility to the sound engineer. Stable transmission and advanced monitor/control functions secure reliable and safe operation in the broadcast studio, and users can choose from a variety of handheld microphone capsules or lavalier microphones according to their program production needs.

  3. DWX Benefits • High Sound Quality with Sony Original Codec • Simultaneous More Multi-Channel Operation • Encrypted Transmission for Security Full Flat Frequency Precise Response Analog System Digital System 20Hz to 20kHz Analog System Digital System • DWX Supports up to approximately 1.5 timesas many systems simultaneously as current analog wireless systems 8 channel (One TV CH in USA) 12 channel (One TV CH in USA) Digital System Analog System Digitally modulated coded audio FM-modulated audio signal Risk of interception by outside system Encrypted data

  4. DWX Benefits • Remote control supporting improved workflow and easy system set-up • Receiver can control Transmitter parameters by 2.4GHz Wireless • Receiver searches vacant frequency and sends the selected frequency to Transmitter • Control software can monitor and control up to 82 transmitters simultaneously On the stage / On Air In case RF interference happens … In case microphone level adjustment is needed … Digital System Analog System Receiver Transmitter Transmitter 2.4GHz Control Software Detach Set Re-attach Transmitter Control by Wireless Remote Transmitter Control by Manual Frequency RF Power Attenuation Low cut filter Power on/ Standby Frequency RF Power Attenuation Low cut filter Remote Setting Manual Setting

  5. 10 Reasons to convert to DWX for Live Concert Application < Live Concert Package> • Superb sound quality • 24bit/48KHz full digital transmission • Choice of 3rd party capsule • Bring out real ability of capsules • More than 30 capsules are available • Higher RF reliability • 20dB stronger to interference than analog wireless • Prevent from interfere from other system • Encryption function • Prevent from interception • Quick setup • Antenna cascade output up to 8 units, 16ch • Large OLED with Clear CH Scan & Active CH Scan • Easy operation w/ Cross Remote function • Status monitor/parameter control function from Receiver by RF carrier • Flexible audio output - 5 way parallel output • 2 analog, 2 digital & 1 for headphones • Flexible powering • 100V-240V AC powering & 12V DC powering • Safety operation • Handheld microphone w/o out side switch • Bodypack transmitter w/ lock function • Lightweight, compact and rugged construction • For active performance & photogenic appealing Vocal CU-C31/F31 Capsule Units DWM-02 Handheld Transmitter Guitar/Bass GC-0.7CP Guitar Cable DWT-B01 BodypackTransmitter Receiver AN-01 UHF Antenna DWR-R02D 2ch RackmountReceiver

  6. 10 Reasons to convert to DWX for Theater Hall Application <Theater Hall Package> • More Simultaneous Multi-Channel Operation • 1.5 times as many CH than analog wireless • 8ch w/ analog -> 12ch w/ DWX in one TV CH in USA (6MHz) • Save & load setting w/ PC software • Simplifies daily operation w/ cross remote function up to 82ch from wireless studio • Superb sound quality • 24bit/48KHz full digital transmission • Choice of 3rd party headset & lavalier • Bring out real ability of capsules • Higher RF reliability • 20dB stronger to interference than analog wireless • Prevent from interfere from other system • Advanced status monitoring • Timeline RF chart graph for every channel • Encryption function • Prevent from interception • Flexible audio output - 5 way parallel output • 2 analog, 2 digital & 1 for headphones • Safety operation • Bodypack transmitter w/ lock function • Lightweight, compact and rugged construction • For active performance Performance ECM-77/FT5 LavalierMic DWT-B01 BodypackTransmitter Speech/Vocal CU-C31/F32 Capsule Units DWM-02 Handheld Transmitter Receiver Wireless Studio AN-01 UHF Antenna RMU-01 Control Unit DWR-R02D 2ch RackmountReceiver

  7. 10 Reasons to convert to DWX for BC Studio Application <BC Studio Package> • Higher RF reliability • 20dB stronger to interference than analog wireless • Prevent from interfere form other system • Advanced status monitoring • Timeline RF chart graph for every channel • Save & load setting w/ PC software • Simplifies daily operation w/ cross remote function up to 82ch from wireless studio • More Simultaneous Multi-Channel Operation • 1.5 times as many CH than analog wireless • 8ch w/ analog -> 12ch w/ DWX in one TV CH in USA (6MHz) • Superb sound quality • 24bit/48KHz full digital transmission • Choice of 3rd party headset & lavalier & Capsules • Bring out real ability of capsules • Encryption function • Prevent from interception • Flexible audio output - 5 way parallel output • 2 analog, 2 digital & 1 for headphones • Safety operation • Handheld microphone w/o out side switch • Bodypack transmitter w/ lock function • Lightweight, compact and rugged construction • For active performance & photogenic appealing Announce ECM-77/FT5 LavalierMic DWT-B01 BodypackTransmitter Speech/Vocal/Interview CU-C31/F31/F32 Capsule Units DWM-02 Handheld Transmitter Receiver Wireless Studio AN-820A UHF Antenna RMU-01 Control Unit DWR-R02D 2ch RackmountReceiver

  8. 10 Reasons to convert to DWX for News Gathering Application <ENG Package> • The only 2ch solt-in receiver in the world • The only digital wireless receiver w/ slot-in & portable style in the world • The only slot-in receiver w/ 2ch reception & 2ch connection via internal bus in the world • Cross Remote function • Status monitor/parameter control function from Receiver & Camcorder* • Wider bandwidth up to 72MHz • Greater potential to find unoccupied frequencies • Higher RF reliability • 20dB stronger to interference than analog wireless • Prevent from interfere form other system • Encryption function • Prevent from interception • Superb sound quality • 24bit/48KHz full digital transmission • Choice of 3rd party Capsules • Bring out real ability of capsules • Safety operation • Plug-on transmitter w/ lock function • Handheld microphone w/o out side switch • Lightweight, compact and rugged construction • For active production • Flexible mounting & integration • Slot-in or V-mount or G-mount w/ mount plate Report/Interview F-112 Dynamic Mic DWT-P01 Plug-on Transmitter Report/Interview CU-C31/F32 Capsule Units DWM-02 Handheld Transmitter Receiver DWA-01D Adapter for V-mount DWR-S02D 2ch Slot-in Receiver *HDW-650//PDW-700/F800//PMW-500/350/320/TD300

  9. 10 Reasons to convert to DWX for Field Production Application <Shooting Package> • More Simultaneous Multi-Channel Operation • 1.5 times as many CH than analog wireless • 8ch w/ analog -> 12ch w/ DWX in one TV CH in USA (6MHz) • Superb sound quality • 24bit/48KHz full digital transmission • Higher RF reliability • 20dB stronger to interference than analog wireless • Prevent from interfere form other system • Wider bandwidth up to 72MHz • Greater potential to find unoccupied frequencies • Easy operation w/ Cross Remote function • Status monitor/parameter control function from Receiver by RF carrier • Choice of 3rd party lavaliermics • Bring out real ability of capsules • Flexible powering • Multiple Powering for both receiver • Flexible Audio output • Multiple Audio output expand • Safety operation • Plug-on transmitter w/ lock function • Lightweight, compact and rugged construction • For active performance & production Play/Performance ECM-77/FT5 LavalierMic DWT-B01 BodypackTransmitter Mixer Bag DWA-F01D Adapter for Mixer Bag DWR-S02D w/DWA-F01D 2ch Slot-in Receiver Sound Cart DWR-R02D 2ch RackmountReceiver *HDW-650//PDW-700/F800//PMW-500/350/320/TD300

  10. 10 Reasons to convert to DWX for Sound Shooting Application <EFP Package> • Superb sound quality • 24bit/48KHz full digital transmission • Higher RF reliability • 20dB stronger to interference than analog wireless • Prevent from interfere form other system • Wider bandwidth up to 72MHz • Greater potential to find unoccupied frequencies • Easy operation with Cross Remote function • Status monitor/parameter control function from Receiver by RF carrier • Encryption function • Prevent from interception • Choice of 3rd party lavaliermics • Bring out real ability of capsules • Flexible powering • Multiple Powering for both receiver • Flexible Audio output • Multiple Audio output expand • Safety operation • Plug-on transmitter w/ lock function • Lightweight, compact and rugged construction • For active production Play/Performance ECM-77/FT5 LavalierMic DWT-B01 BodypackTransmitter Sound Gathering ECM-678 Shotgun Mic DWT-P01 Plug-on Transmitter Mixer Bag DWA-F01D Adapter for Mixer Bag DWR-S02D w/DWA-F01D 2ch Slot-in Receiver *HDW-650//PDW-700/F800//PMW-500/350/320/TD300
