  1. Novosti v programu Aquaterra 2013 Tadej Kodrič, dipl. inž. gradb. CGS plus d.o.o.

  2. Projekcijske točke V-2012 • Izris poljubnih točk (blokov) v situaciji, ki so vidni tudi v vzdolžnih profilih

  3. Vzdolžni profili V-2012 • Osvežitev vzdolžnih profilov • Vir podatkov • Situacija • Prečni profili • Izbor elementov • Teren • Horizontalni elementi • Presečne linije • Projekcijske točke • Projekcija nivelete

  4. Prečni profili V-2012 • 43GB Obloga brežine • Dodano izbirno okno: “Riši NPP element” Kadar želimo zaprto območje – planimetrirne količine

  5. MIKE 11 vmesnik V-2012 • Izvoz osi v MIKE 11 • V prejšnji verziji je bil prenos omejen na točke v prečnih profilih • Nova funkcija doda natančnost v območjih, kjer je vzdolžna os sestavljena iz lokov.

  6. MIKE 21 vmesnik • Izris rezultatov MIKE 21 • - dodano izbirno okno: • “Optimiziraj” • Kadar želimo, da se rezultat modela MIKE 21 izriše po stari (neoptimizirani) metodi, kljukico odstranimo.

  7. MIKE 21 vmesnik Stara metoda Nova metoda

  8. Funkcije v izdelavi – testna verzija • Delovanje Aquaterre 2013 na platformi Bricscad V12 • CGS Digitalni model reliefa – DMR • Izris glavnih elementov na osnovi pomožnih
