Presentation Transcript
zavojne pumpe

ZAVOJNE PUMPE

Obrtne pumpe

clanovi grupe
Clanovi grupe
  • Matija Jakovljević
  • Veljko Radojičić
  • Marko Đurović
  • Aleksandar Maksimović
sadr aj
Sadržaj
  • Opis
  • Delovi
  • Princip rada
  • Kraj
o zavojnim pumpama back
O ZAVOJNIM PUMPAMA (back)
  • Obrtne pumpe.
  • Rade na niskim i srednjim pritiscima.
  • Imaju veliki protok.
  • Primenjuju se kod masina radilica, prehrambenoj indusriji, naftnoj industriji itd.
  • Pouzdan i bešumni rad sa ravnomernim protokom.
delovi zavojne pumpe back
DELOVI ZAVOJNE PUMPE (back)
  • Kućište
  • Radno vratilo
  • Srednje navojno vratilo
  • Bocno navojno vratilo
princip rada back
PRINCIP RADA (back)

Srednje navojno vratilo sa d. navojem

Obrtno kretanje

Bočna krila levog navoja

prenos

slide7
KRAJ

Hvala na pažnji.
