  1. Multimedia Systems &Interfaces Karrie G. KarahaliosSpring 2007

  2. Overview • Filters • Edge Detection • Non Photo-realistic Rendering

  3. Image Filtering Overview http://www.courses.fas.harvard.edu/~ext12559/lectures/2005-11-29-Filtering.pdfby Chris Wren

  4. Spatial domain refers to planar region of intensity values Frequency domain think of each color plane as a sinusoidal function of changing intensity values apply DFT to subsets of pixels for compression Spatial and Frequency Domains

  5. Convolution Filters • Filter an image by replacing each pixel in the source with a weighted sum of its neighbors • Define the filter using a convolution mask, also referred to as a kernel • non-zero values in small neighborhood, typically centered around a central pixel • generally have odd number of rows/columns

  6. 20 12 14 23 45 15 19 33 55 34 81 22 8 64 49 95 Mean Filter Subset of image Convolution filter

  7. Mean Filter 20 12 14 23 45 15 19 33 55 34 81 22 8 64 49 95 Subset of image Convolution filter

  8. Common 3x3 Filters • Low/High pass filter • Blur operator • H/V Edge detector

  9. Edge Detection • Identify areas of strong intensity contrast • filter unecessary data; preserve important properties • Fundamental technique • object recognition, orientation • image segmentation • e.g., use gestures as input • identify shapes, match to templates, invoke commands

  10. Identify high slope in first derivative Pixel is on an edge if value of the gradient exceeds a threshold Characteristics of Edges http://www.pages.drexel.edu/~weg22/edge.html

  11. Basic Method • Step 1: filter noise using mean filter • Step 2: compute spatial gradient • Step 3: mark points > threshold as edges

  12. Compute partials Compute gradient Compute length Divide by length Compute Spatial Gradient

  13. Compute Partials P3 – P1 + 2*P6 – 2*P4+ P9 – P7 P7 – P1 + 2*P8 – 2*P2+ P9 – P3

  14. Given gradient at each pixel and threshold mark pixels where gradient > threshold as edges Canny algorithm extends basic method Mark Edge Points http://www.cee.hw.ac.uk/hipr/html/sobel.html

  15. Compute direction of maximum change Compute Edge Direction

  16. For each pixel If G(x,y) < either neighbor along Normal direction, then set G(x,y) = 0 Suppress local change when larger change nearby helps reduce false positives Apply Non-Max Suppression

  17. Hysteresis • Oscillation of gradient at threshold • Use two thresholds • T1 and T2 with T2 > T1 • Mark pixel as edge pixel if G(x,y) > T2 • keep pixels along normal direction withG(x,y) > T1
