Presentation Transcript
basic concepts in tracking filtering
Basic concepts in tracking/filtering
  • State variables x; observation y: both are vectors
  • Discrete time: x(t), y(t), x(t+1), y(t+1)
  • Probability P
  • pdf [density] p(v) of vector variable v :

p(v*) = lim P(v* < v < v*+dv) / dv

dv->0 .

basic concepts gaussian pdf
Basic concepts:Gaussian pdf

A Gaussian pdf is completely characterized by 2 parameters:

  • its mean vector
  • its covariance matrix
basic concepts prior and likelihood
Basic concepts: prior and likelihood
  • Prior pdf of variable v: in tracking, this is usually the probability conditional on the previous estimate: p[ v(t) | v(t-1) ]
  • Likelihood: pdf of the observation, given the state variables: p[ y(t) | x(t) ]
basic concepts bayes theorem
Basic concepts:Bayes’ theorem
  • Posterior pdf is proportional to prior pdf times likelihood:

p[ x(t) | x(t-1), y(t) ] =

p[ x(t) | x(t-1) ] p[ y(t) | x(t) ] / Z

where

Z = p[ y(t) ]

basic concepts recursive bayesian estimation
Basic concepts:recursive Bayesian estimation

Posterior pdf given the set y(1:t) ofall observations up to time t:

p[ x(t) | y(1:t) ] =

p[ y(t) | x(t) ] . p[ x(t) | x(t-1) ] .

p[ x(t-1) | y(1:t-1) ] / Z1

basic concepts recursive bayesian estimation1
Basic concepts:recursive Bayesian estimation

p[ x(t) | y(1:t) ] =

p[ y(t) | x(t) ] . p[ x(t) | x(t-1) ] .

p[ y(t-1) | x(t-1) ] . p[ x(t-1) | x(t-2) ] .

p[ x(t-2) | y(1:t-2) ] / Z2

basic concepts recursive bayesian estimation2
Basic concepts:recursive Bayesian estimation

p[ x(t) | y(1:t) ] =

p[ y(t) | x(t) ] . p[ x(t) | x(t-1) ] .

p[ y(t-1) | x(t-1) ] . p[ x(t-1) | x(t-2) ] .

p[ y(t-2) | x(t-2) ] . p[ x(t-2) | x(t-3) ] .

… / Z*

kalman model in words
Kalman model in words
  • Dynamical model: the current state x(t) is a linear (vector) function of the previous state x(t-1) plus additive Gaussian noise
  • Observation model: the observation y(t) is a linear (vector) function of the state x(t)plus additive Gaussian noise
problems in visual tracking
Problems in visual tracking
  • Dynamics is nonlinear, non-Gaussian
  • Pose and shape are nonlinear, non-Gaussian functions of the system state
  • Most important: what is observed is not image coordinates, but pixel grey-level values: a nonlinear function of object shape and pose, with non-additive, non-Gaussian noise
back to kalman
Back to Kalman
  • A Gaussian pdf, propagated through a linear system, remains Gaussian
  • If Gaussian noise is added to a variable with Gaussian pdf, the resulting pdf is still Gaussian (sum of covariances)

---> The predicted state pdf is Gaussian if the previous state pdf was Gaussian

---> The observation pdf is Gaussian if the state pdf is Gaussian

kalman posterior pdf
Kalman posterior pdf
  • The product of 2 Gaussian densities is still Gaussian (sum of inverse covariances)

---> the posterior pdf of the state is Gaussian if prior pdf and likelihood are Gaussian

kalman filter
Kalman filter
  • Operates in two steps: prediction and update
  • Prediction: propagate mean and covariance of the state through the dynamical model
  • Update: combine prediction and innovation (defined below) to obtain the state estimate with maximum posterior pdf
note on the symbols
Note on the symbols
  • From now on, the symbol x represents no longer the ”real” state (which we cannot know) but the mean of the posterior Gaussian pdf
  • The symbol A represents the covariance of the posterior Gaussian pdf
  • xand A represent mean and covariance of the prior Gaussian pdf
kalman prediction
Kalman prediction
  • Prior mean: previous mean vector times dynamical matrix:

x(t) = Dx(t-1)

  • Prior covariance matrix: previous covariance matrix pre- AND post-multiplied by dynamical matrix PLUS noise covariance:

A(t) = DT A(t-1) D + N

kalman update
Kalman update

In the update step, we must reason backwards, from effect (observation) to cause (state): we must ”invert” the generative process.

Hence the update is more complicated than the prediction.

kalman update continued
Kalman update (continued)

Basic scheme:

  • Predict the observation from the current state estimate
  • Take the difference between predicted and actual observation (innovation)
  • Project the innovation back to update the state
kalman innovation
Kalman innovation

Observation matrix F

The innovation v is given by:

v = y - F x

Observation-noise covariance R

The innovation has covariance W:

W = F TA F + R

kalman update state mean vector
Kalman update: state mean vector
  • Posterior mean vector: add weighted innovation to predicted mean vector
  • weigh the innovation by the relative covariances of state and innovation:

larger covariance of the innovation

--> larger uncertainty of the innovation

--> smaller weight of the innovation

kalman gain
Kalman gain
  • Predicted state covariance A
  • Innovation covariance W
  • Observation matrix F
  • Kalman gain K = A F TW-1
  • Posterior state mean:

s = s + K v

kalman update state covariance matrix
Kalman update: state covariance matrix
  • Posterior covariance matrix: subtract weighted covariance of the innovation
  • weigh the covariance of the innovation by the Kalman gain:

A = A- K T W K

  • Why subtract? Look carefully at the equation:

larger innovation covariance

--> smaller Kalman gain K

--> smaller amount subtracted!

kalman update state covariance matrix continued
Kalman update: state covariance matrix (continued)
  • Another equivalent formulation requires matrix inversion (sum of inverse covariances)

Advanced note:

  • The equations given here are for the usual covariance form of the Kalman filter
  • It is possible to work with inverse covariance matrices all the time (in prediction and update): this is called the information form of the Kalman filter
summary of kalman equations
Summary of Kalman equations
  • Prediction :

x(t) = Dx(t-1)

A(t) = DT A(t-1) D + N

  • Update:

innovation: v = y - F x

innov. cov: W = F TA F + R

Kalman gain: K = A F TW-1

posterior mean:s = s + K v

posterior cov: A = A - K T W K

kalman equations with control input u
Kalman equationswith control inputu
  • Prediction :

x(t) = Dx(t-1) + Cu(t-1)

A(t) = DT A(t-1) D + N

  • Update:

innovation: v = y - F x

innov. cov: W = F TA F + R

Kalman gain: K = A F TW-1

posterior mean:s = s + K v

posterior cov: A = A - K T W K
