Integrated Design Methodology:The Only Proven WayNitin DeoVice President, Product Marketing

the terabit food chain

Infrastructure

Semiconductor

Content

Applications

Enterprises

Networking Equipment

Services

  • Network processors
  • Switch fabric
  • Processors- uP- DSP- Network Proc.

Small & MediumBusinesses

  • Microprocessors
  • Memories
  • Memory access

Servers & Storage Systems

Services

  • Multi-media
  • Graphics controllers
  • Multi-media
  • Mobile electronics
  • Low power designs

Consumers

PCs, Cell Phones, TVs, Set-tops

Entertainment

The Terabit Food Chain
the eda requirements

Semiconductor

Content

  • Processors- uP- DSP- Network Proc.
  • Multi-media
  • Graphics controllers
  • Low power designs
The EDA Requirements
  • High performance designs
    • Structured custom techniques
    • Programmability
    • Reconfigurability
  • High Capacity designs
    • Exceeding 50 M gates today
    • High-end package co-design
  • Power sensitive designs
    • Multi-Vt, multi-voltage designs
    • Low power design techniques
nanometer design challenges
Nanometer Design Challenges
  • Higher frequency (100 MHz to 1GHz)
    • Consumer, Mobile applications
    • Magma customers: NEC, Nokia, Sony
  • High capacity: 1 to 10M gates
    • Base stations, gaming, graphics
    • Magma users: Cisco, Broadcom, 3DLabs
  • Power-sensitive designs:
    • Multi-vt, multi-Vdd designs
    • Magma users: IBM, NEC, Fujitsu, STMicro
  • Productivity
  • Complexity
  • Performance
  • Signal Integrity
  • Power
traditional ic design flows too complex

Timing

Constraints

RTL

LIB

Synthesis

Floorplanning

STA

Net List

Floor

plan

Physical

Synthesis

PLIB

PDEF

Net List

lef2plib

Clock,Routing

Placement

iLM

model

LEF

GDS II

(lib)

gds2lef

GDS II

Extraction

STA

SPEF

Traditional IC design flows too complex
  • Series of point tools that looks at various steps
    • Wireload models are not useful
    • Corrections at the end cause iterations
    • Standalone analysis is dead
    • Power and other manufacturing effects cannot be done as point solutions
    • Files sizes are too big
magma s integrated solution

Noise Analysis

Power Analysis

Timing Analysis

RC Extraction

Silicon Virtual Prototype

Gain-Based Synthesis

Physical Synthesis

Physical Layout

Magma’s Integrated Solution

Integrated RTL-to-GDSII System

  • Merge logical & physical EDA technology
  • Embed high accuracy, high speed analysis engines
  • Eliminates massive data handling
  • Eliminates mismatches in timing
  • Streamlines IC design flow

Timing

Constraints

GDS II

.LIB

RTL

Single executable

GDS II

Fastest Design Closure

magma meets nanometer productivity challenge
Magma Meets Nanometer Productivity Challenge

Increased productivity while achieving total design closure

INC- Incomplete

from rtl to tsmc silicon
From RTL to TSMC Silicon
  • Mutual customers: Broadcom, Vitesse, Internet Machines, PhyWorks, Sony, Hitachi, Panasonic, etc.
  • Strong partnership for 90nm integration

Customer’s

RTL and Constraints

Integrated

COT Methodology

Fab

TSMC’s Libraries

and Technology Rules

0.15 um, 0.13um, 90nm

why tsmc chose magma
Why TSMC Chose Magma
  • “Magma can integrate TSMC process-tuned libraries with their proven EDA tools to improve faster time to volume.”

- Genda Hu, VP of Marketing, TSMC

  • Magma worked closely with TSMC to:
      • Validate TSMC’s library in Magma’s design environment
      • Benchmark TSMC libraries
      • Ensure that Magma software supports TSMC manufacturing rules for 0.15m, 0.13m and 90nm
        • Complex design rules, via farm rules, metal rules, multi Vt cells
  • TSMC partnered with the industry’s best to provide high quality libraries
magma ready for ibm technology
Magma ‘Ready For IBM Technology’
  • Magma approved with validated Reference Flow for 0.13um and 0.18um technologies including Blast Create and Blast Fusion
  • Artisan libraries for 8SF and 7SF processes fully qualified
  • Joint customers include: 3DLabs, Vitesse, Intersil, Thomson Multi-Media, Clearspeed, etc.
partnership roadmap
Partnership Roadmap
  • Faraday is a close partner of UMC that provides:
    • Design services from RTL to GDS
    • Libraries and IPs
    • Tapeout services and product engineering services
    • Their own standard products using their own IP manufactured by UMC
  • Magma – Faraday/UMC partnership roadmap consists of three implementation phases
  • Mutual customers: Faraday, Intersil, AMCC, etc.

Library

Qualification

LAVA Flow Adoption

LAVA Flow Rollout

IP Qualification

IP Promotion

Advanced Technology Support

magma the fastest path complete soc for implementation

Library data (.lib, LEF/GDS), Process Rules

IP data (RTL, Timing, GDS)

Hard IP Preparation

Constraints

Library Preparation

RTL

RTL Optimization

Library

Volcano

Glassbox

Check Timing

ESP for

Soft IP

Physical Optimization

Confirm Timing

Physical Design

GDSII

Magma: The Fastest Path Complete SOC For Implementation
complex ip integration with glassbox model
Logic Abstraction: Easy and AccurateComplex IP Integration with Glassbox Model
  • Physical Abstraction: Easy and Accurate

Abstract

  • ‘True’ Timing Abstraction = Logic + Physical
  • Glassbox Model can be exported through IP-Lava
original arm946 compared with glassbox model
Original ARM946 Compared With Glassbox Model

Original

Glassbox

Volcano Size: 58 MB

Volcano Size: 148 MB

production use of mips cores using magma
Production Use of MIPS Cores Using Magma
  • Soft IP Implementation with ESP
  • Recent Silicon-proven Implementations:
    • NEC: CB12 (0.13um), 275 MHz
    • NEC: CB11 (0.18um), 234 Mhz
    • Infineon: C10 (0.18um), 150 MHz
    • TI: SR40 (0.13um), 285 MHz
    • Silverback: Artisan-TSMC 0.18um, 160 MHz
magma fastest growing eda company
Magma: Fastest Growing EDA Company
  • Strong Financial Momentum
    • Cumulative quarterly growth over 33%
    • Most successful IPO of 2001
    • Profitable with positive cash flows
    • $208M in cash
  • Strong market acceptance
    • 400+ tapeouts
    • More than 50 customers worldwide
    • 8 out of top 10 IC companies use Magma
  • Strong team
    • 285 employees worldwide
    • 40+ PhD’s
    • Large patent portfolio
    • R&D centers worldwide
key innovations
Key Innovations
  • Patented Architecture
    • Unified data model enables concurrent analysis, thereby eliminating iterations
    • Eliminates file transfers; simplifies data management
    • Extensible architecture enables addition of new tools seamlessly
  • Patented Methodology
    • FixedTiming approach eliminates iterations between synthesis and P&R
    • Provides early predictability of achievable performance
    • Glassbox abstraction enables accurate modeling for hierarchical designs
  • Open system
    • Supports standard interfaces with other tools
    • TcL-based API enables easy access to design information
the fastest growing market

Cadence 10%

Other 2%

Cadence 24%

Synopsys 64%

24%

Synopsys 41%

31%

The Fastest Growing Market

IC Implementation Market Share

  • IC Implementation is RTL-to-GDSII tools
    • SNPS: DC + PC + Apollo
    • CDN: SPC + Plato
    • LAVA: B-RTL + B-Fusion
  • “This market will be one of the highest-growing markets in the next 2 years” – expected to be $483M in 2006
  • Magma market share currently at 31% and growing rapidly – “grew at a staggering 343% last year”

2000

2001

Other 4%

Source: Gartner Dataquest (October 2002)

magma advantage
Magma Advantage
  • Fast, predictable, high-capacity front end
  • Timing, Signal and Power Integrity solution within Implementation flow
  • Open system for seamless fit in your design flow
  • Proven to reduce TAT by 50% - 90% and development costs by 30% to 50%
summary
Summary
  • Magma: The fastest path from RTL to Silicon
    • Early predictability, best QoR
    • Reduces TAT by 50-90%
    • Reduces cost by 30-50% per project
  • Sustained technology leadership
    • Clear leader at 0.18 mm and below
    • Ready to deliver 90 nm designs - now
  • Fastest growing EDA company
    • Strong, profitable public corporation
