development of reliable simple rate expressions from a microkinetic model of fts on cobalt

Development of Reliable, Simple Rate Expressions from a Microkinetic Model of FTS on Cobalt

Calvin H. Bartholomew, George Huber, and Hu Zou

Brigham Young University

And

George Huber, Rahul Nabar,

Peter Ferrin, Manos Mavrikakis, and James Dumesic

University of Wisconsin, Madison

background
Background
  • Fischer-Tropsch Synthesis (FTS), is a key step in processes being developed and commercialized in the new GTL industry.
  • Improvements to GTL and FTS processes are facilitated by development of accurate, comprehensive reactor and kinetic models.
  • Rates and reactant/product compositions in a commercial FTS SBCR cover wide ranges; rates may vary 10-20 fold, H2/CO ratios 2 to 100.
  • Microkinetic models (MKMs) and/or Langmuir-Hinshelwood models (LHMs) are needed for reliable prediction of rates over the full range of conditions.
  • While MKMs are the most powerful predictors, given large computational requirements of a comprehensive FTS reactor model, a reliable LHM may be the best compromise.
kinetic models for fts on cobalt
Kinetic Models for FTS on Cobalt
  • A dozen previous macrokinetic studies; each covers a narrow range of conditions.
  • Power law (PL) and LH rate expressions reported in previous studies may not be statistically valid since too many parameters were fitted to too few data.
  • Two microkinetic models for FTS on cobalt have been previously published. They have limited utility and have not been validated with a representative set of data.
  • Use of kinetic/thermo parameters from MCMs in building rate laws has been limited—hasn’t been done with Co FTS.
issues addressed in this talk
Issues Addressed in This Talk
  • What is a viable approach to microkinetic model and rate-law development?
  • How can we use microkinetic models to develop better rate laws?
  • What factors limit the validity of previously reported rate laws and how might they be overcome?
microkinetic model development
Microkinetic Model Development

Detailed Kinetics

Activity, Selectivity,

Stability

Isotopic Studies

SSITKA and kinetics of elementary steps

DFT

Electronic structure of stable species, intermediates and

transition states

IR

Surface species

Surface Reaction

Schemes and Kinetic

Models

Microscopy

Surface morphology

and composition

Adsorption

And Microcalorimetry

Heats, Coverages

XPS, XRD, Mössbauer

Alloy formation, oxidation

states, surface composition

information from mkm
Information from MKM
  • Kinetic parameters for each elementary step
  • Site requirements
  • Predictions of rate over a wide range of conditions from solution of the differential equations
slide7

UWM

Microkinetic Model for Fischer Tropsch Synthesis on Co(0001)

On Wisconsin

slide8

Preferred Adsorption Sites and Binding Energies for Intermediates in CH4 Formation on Fe(110) and Co(0001)(Gokhale and Mavrikakis, 2005; courtesy of the American Chemical Society)

slide9

Kinetic Study: Statistical Design

(H&B, BYU; Temperature 200C, Pressure Total = 20 atm.)

slide10

Rate Expression Derived

from Original Carbide Mechanism

(Huber, 2000)

slide11

Calculated and measured values are in reasonable agreement.

NSSE = 4-8 x 10-5for several sets of data.

Rate calculated vs. rate measured in this study for rate expressions derived from Carbide Theory, Power Law and rate expressions proposed by Yates and Satterfield.

slide12

Deviations are within + or – 5%.

Normalized deviation from average value (%) versus run number.(Normalized deviation from average value = (value – average value) /average value x 100) [Huber and Bartholomew, 2005].

slide13

Results of Nonlinear Regression

a = 81.1 ± 43

b = 1.0 ± 0.4

Conclusion: A and B (a and b) in rate equation cannot be specified!

Correlation between A and B for Model 1 derived from Carbide Theory. Ellipse indicates 95 % confidence limit for each constant.

solution to dilemma
Solution to Dilemma?
  • Use MKM to specify all variables except one
  • Use nonlinear regression to determine the unspecified parameter
slide16

UWM

Microkinetic Model for Fischer Tropsch Synthesis on Co(0001)

On Wisconsin

conclusions
Conclusions
  • Dilemma: Typical approach to fitting kinetic data to LHE may lead to highly correlated constants; standard errors are large and constants are unspecified.
  • Solution: use constants from theory or MKM to specify all but one constant, which can be fitted by nonlinear regression.
  • For Co(0001) CO dissociation is rds and CO is masi. On stepped sites C + H could be rds.
slide23

Representative Simple Reaction Rate Equations for

CO Consumption in FTS on Co Catalysts
