PA Turnpike, Quakertown Approx. Mile Marker 44.3 North. VENEZIA Tanker Accident. As it sits before starting but after off-loading over 40,000 lbs. of powder concrete mixture. Trailer is straddling a drainage ditch and still connected to the tractor.

loader
I am the owner, or an agent authorized to act on behalf of the owner, of the copyrighted work described.
capcha
Download Presentation

PowerPoint Slideshow about 'PA Turnpike, Quakertown Approx. Mile Marker 44.3 North' - mac


An Image/Link below is provided (as is) to download presentation

Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.


- - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - -
Presentation Transcript
slide5

Trailer still had residual product inside and was fighting to lay on its side. Strap was used high off forward wrecker (Holmes 750) to keep tanker level and on its wheels.

slide6

The forward wrecker (Holmes 750) connected to the pivot point at the 5th wheel and the upper strap holding the trailer level. A medium wrecker was connected to the front of the tractor to guide it along.

slide7

The rearward wrecker (NRC 35 ton) was connected to the rear of the trailer. The boom was raised to help the underside valves on the trailer clear the shoulder.

slide8
MPI’s loader was used to stabilize at pivot point. Note: entire area was excavated due to diesel contamination.
slide9
Overall view of scene just before starting the pull. Only the shoulder and one lane were blocked, traffic still going in passing lane.
5 lines pulling in unison in different directions and 1 loader pushing slowly but surely
5 lines pulling in unison in different directions and 1 loader pushing. Slowly but surely…..
slide11
As a unit, the wreck was pulled across the drainage ditch and onto the shoulder, ending up parked straight in the shoulder.
slide13
The product inside had to be shoveled down to the bottom and centered to keep the trailer from leaning.
slide14
The trucks were repositioned so the trailer could be separated from the tractor. The tractor was being readied to place on the carrier.
the 5 th wheel was cut from the tractor frame then cut away from the trailer to prepare for towing
The 5th wheel was cut from the tractor frame then cut away from the trailer to prepare for towing.
slide17
The tractor was placed on the carrier and tied down…the only thing over the 13’6” limit was a CB antenna.
