communication

Communication

Technical Sketching and Drawing

orthographic sketch
Orthographic Sketch
  • A Multi-view drawing that typically shows the front , right side and top view. (orthographic)
  • When the side view is perfectly in line with the front view, it is called Projection.
orthographic con t
Orthographic con’t
  • The top view’s width dimension is projected from which other view?
  • Front View
orthographic con t1
Orthographic Con’t
  • The Surface with the most detail is shown is which view?
  • Front View
  • Most detailed drawings are orthographic drawings
cabinet oblique
Cabinet (oblique)
  • In cabinet oblique drawings, the receding lines are shortened by one-half their true length to compensate for distortion and to approximate more closely what the human eye would see..
cavalier
Cavalier
  • In cavalier oblique drawings, all lines (including receding lines) are made to their true length.
oblique drawings
Oblique Drawings
  • A Sketch shows the front view as if a person were looking directly at it.
isometric
Isometric
  • A pictorial sketch that has been drawn as it it were viewed from one corner at a 30 º angle.
perspective
Perspective
  • A sketch that shows the object as the human eye or camera would see it.
  • 1 pt
