ai week 17 machine learning applied to ai planning locm

AI – Week 17 Machine Learning Applied to AI Planning: LOCM

Lee McCluskey, room 2/09

Email lee@hud.ac.uk

http://scom.hud.ac.uk/scomtlm/cha2555/

will we always need to engineer knowledge bases for planners pddl pipes world e g
Will we always need to engineer knowledge bases for planners? (pddl Pipes World) E.G. ……

(:durative-action PUSH-START

:parameters( ?pipe – pipe ?batch-atom-in – batch-atom ?from-area - area

?to-area - area ?first-batch-atom – batch-atom ?product-batch-atom-in – product

?product-first-batch - product)

:duration (= ?duration (/ 1 (speed ?pipe)))

:condition (and (over all (normal ?pipe)) (at start (first ?first-batch-atom ?pipe))

(at start (connect ?from-area ?to-area ?pipe)) (at start (on ?batch-atom-in ?from-area))

(at start (not-unitary ?pipe)) (at start (is-product ?batch-atom-in ?product-batch-atom-in))

(at start (is-product ?first-batch-atom ?product-first-batch))

(at start (may-interface ?product-batch-atom-in ?product-first-batch)))

:effect (and (at end (push-updating ?pipe)) (at end (not (normal ?pipe)))

(at end (first ?batch-atom-in ?pipe)) (at start (not (first ?first-batch-atom ?pipe)))

(at end (follow ?first-batch-atom ?batch-atom-in)) (at start (not (on ?batch-atom-in ?from-area))) ) )

ENGINEERED WITH VARIABLE DOMAINS, RELATIONS, PROPERTIES, CONDITIONS ..

machine learning applied to ai planning
Machine Learning applied to AI Planning

Automated Knowledge Acquisition: learning the domain model. One Promising Direction:

Give a learning system a number of PLANS, or let it “observe” plans. Get the learning system to learn (“mine”) the details of the actions by “inducing” the operator schema

This could be termed “process mining”. Example Applications:

  • Learn effect of operating system instructions
  • Learn moves / rules in a game
  • Learn meaning of actions in a work-flow
  • Learn meaning of business processes
learning pddl domain models where would training plans come from
Learning PDDL Domain Models:Where would training plans come from?

Training plan scripts could come from several types of activity:

1. (Goal Directed) Solutions from current planners using existing domain models

2. Random plan scripts generated using existing domain models

3. Harvested plan scripts from human activities such as game playing

4. Recorded or logged plan scripts from computer or natural processes

will use tyre world as a running example
Will use “tyre world” as a running example

Trace of Changing a Car Wheel

fetch_jack jack1 boot1

remove_wheel wheel0 hub0 jack0

jack_up hub1 jack1

put_on_wheel wheel2 hub0 jack0

fetch_wrench wrench0 boot0

jack_down hub1jack1

putaway_wrench wrench1 boot0

………………..etc

(:action remove_wheel

:parameters (?Wheel1 - wheel ?Hub2 - hub ?Jack3 - jack)

:precondition (and

(wheel_state2 ?Wheel1 ?Hub2) (hub_state1 ?Hub2 ?Jack3 ?Wheel1)

(jack_state1 ?Jack3 ?Hub2))

:effect (and

(wheel_state1 ?Wheel1) (not (wheel_state2 ?Wheel1 ?Hub2))

(hub_state0 ?Hub2 ?Jack3) (not (hub_state1 ?Hub2 ?Jack3 ?Wheel1))

(jack_state0 ?Jack3 ?Hub2) (not (jack_state1 ?Jack3 ?Hub2))) )

LOCM

Meaning of “remove_wheel”

Action in Planning-ready

format

locm assumptions sort sort of means class
LOCM assumptions (‘sort’ sort of means ‘class’)

The behaviour of

objects in a sort

can be represented

by a FSM.

The output state of an object is the same as the input state of the object in the next action

fetch_jack jack1 boot1

remove_wheel wheel0 hub0 jack0

jack_up hub1 jack1

put_on_wheel wheel2 hub0 jack0

fetch_wrench wrench0 boot0

jack_down hub1jack1

putaway_wrench wrench1 boot0

Objects that occur together over 2 or more actions indicate associations between object sorts

The same name is used for the same action

Each occurrence of the same action has the same number of objects of the same sort as arguments

Inducing Action Semantics from Traces

locm assumptions
LOCM - assumptions

INPUTS: traces of “plans” e.g. one plan in the tyre world might be:

open(c1); fetchjack(j1,c1); fetchwrench(wr1,c1); close(c1); open(c2);fetchwrench(wr2,c2); fetchjack(j2, c2); close(c2); close(c3); open(c3)

OUPUTS: PDDL Domain Model

LOCM Assumptions to do with regularity:

  • Each sequence contains action names followed by a list of parameters which are objects used by that action
  • Different instances of actions have the same number of parameters in the same order, and of the same type (sort)
  • Sequences are SOUND (actions can be executed in turn)
  • The objects referred to by the training plans can thus be partitioned into a set of distinct “sorts”.

Cresswell, S.N., McCluskey, T.L. and West, Margaret M. (2013) Acquiring planning domain models using LOCM. Knowledge Engineering Review. ISSN 0269-8889 , http://eprints.hud.ac.uk/9052/

locm more assumptions
LOCM- more assumptions

open(c1); fetchjack(j1,c1); fetchwrench(wr1,c1); close(c1); open(c2);fetch wrench(wr2,c2); fetchjack(j2, c2); close(c2); close(c3); open(c3)

LOCM Assumptions to do with behaviour:

  • All objects of the same sort behave in the same way and states of an object can be described by an FSM
  • For every specific object: the output state of one action is the SAME as the input state of the next action affecting it
  • For each action instance, an object it is applied to always starts and finishes in the same state (transitions are 1-1)

INDUCED STATES OF

CAR “BOOT”

SO RT

fetch_jack.2

open.1

fetch_wrench.2

boot1 (open)

boot0 (closed)

close.1

locm create state machines
LOCM- create state machines

open(c1); fetchjack(j1,c1); fetchwrench(wr1,c1); close(c1); open(c2);fetchwrench(wr2,c2); fetchjack(j2, c2); close(c2); close(c3); open(c3)

From first 4 actions – there are 8 possible states of a boot (e.g. c1) :S1- S8

S1 => open.1 => S2

S3 => close.1 => S4

S5 => fetch jack.2 => S6

S7 => fetch wrench.2 => S8

These collapse to 2 STATES when applying behaviour assumption 2&3.

INDUCED STATES OF

CAR “BOOT”

SO RT

fetch_jack.2

open.1

fetch_wrench.2

boot1 (open)

boot0 (closed)

close.1

locm inductive generalisation
LOCM – inductive generalisation
  • New example: open(c1); putawayjack(j1, c1); close(c1); open(c2); putawayjack(j2, c2); open(1); fetchjack(j1,c1); fetchwrench(wr1, c1); fetchjack(j2, c2); close(c1);

Consider one action A taking an object x of sort S1 into a state T and another action B taking object x out of that state. Assume that A and B both also refer to some other sort S2.

If *every time* in training it is observed that when A and then B are executed on the same object of sort S1, the SAME object of sort S2 is recorded, then we induce that state T has an association with objects of sort S2

Example above: putawayjack(j2; c2) …. fetchjack(j2,c2): same object c2 is referred to, hence induce association with sort “boot”. Not so for egfetchjack(j2,c1) .. putaway(j1,c1) – can’t say that boot is associated with jack.

Cresswell, S.N., McCluskey, T.L. and West, Margaret M. (2013) Acquiring planning domain models using LOCM. Knowledge Engineering Review. ISSN 0269-8889 , http://eprints.hud.ac.uk/9052/

locm parameterised fsm pddl
LOCM – Parameterised FSM => PDDL

(:action open_container

:parameters (?Boot1 - boot)

:precondition

(and (zero_state0)

(boot_state1 ?Boot1))

:effect

(and (boot_state0 ?Boot1)

(not (boot_state1 ?Boot1))) )) )

(:action fetch_jack

:parameters (?Jack1 - jack ?Boot2 - boot)

:precondition

(and (zero_state0)

(jack_state4 ?Jack1 ?Boot2)

(boot_state0 ?Boot2))

:effect

(and (jack_state3 ?Jack1)

(not (jack_state4 ?Jack1 ?Boot2))) )

INDUCED STATES OF

EVERY SORT – BOOT, JACK,

WHEEL, HUB, NUTS, WRENCH …

fetch_jack.2

open.1

fetch_wrench.2

boot0 (open)

boot1 (closed)

close.1

inducing domain models game example
Inducing Domain Models - Game Example

Trace of FreeCell Game

Send to home ..

Move to Free cell ....

Move to Free Cell ....

Move to column ....

Send to home ...

(:action sendtohome

: parameters (?card - card ?suit - suitsort ?vcard - denomination ?homecard - card ?vhomecard ?cols ?ncols - denomination)

:precondition (and (clear ?card)

(bottomcol ?card) (home ?homecard) (suit ?card ?suit) (suit ?homecard ?suit)

(value ?card ?vcard) (value ?homecard ?vhomecard) (successor ?vcard ?vhomecard) (colspace ?cols)

(successor ?ncols ?cols))

: effect (and (home ?card) (colspace ?ncols) (not (home ?homecard)) (not (clear ?card))

(not (bottomcol ?card)) (not (colspace ?cols))))

Induction

Meaning of “Send to home”

Action in Planning-ready

format

problems future work
Problems/Future Work:
  • When is the induction finished – how big have the training sequences to be?
  • LOCM can’t (yet) induce static knowledge
  • Need to find “naturally occurring” sources of planning traces
  • What are the theoretical limits to the expressiveness of the induced language?
conclusion
Conclusion
  • KE is hard and inflexible – techniques that can learn knowledge are important
  • Learning mechanisms like LOCM can exploit

- regularity in training examples

- physical constraints

- inductive generalisations about associations between objects

- assumptions about the form of actions

- assumptions about the state change behaviour of groups of objects

in order to learn structures such as PDDL
